Walker – User Manual
(3/2/2015)
CONTROLS
For Magstripe
Card Reading
SPECIFICATIONS
Power & Battery
Charging
Software Support
Battery Life
Light Indicator
Communication Channel
In The Box
For EMV Card Reading
3.5mm Audio Jack
Built-in Lithium Polymer Rechargeable Battery,
125 mAH, 3.7V
Via Micro USB to computer system or power
adapter. Charge for 2 hours for full charge
Android 2.1 or above, IOS 6.0 or above,
Windows Phone 8, Windows XP or above
Approximately 100 EMV transactions
Light ON
• Green – Battery Full Charge
• Red – Charging
Light Flashing
• Green – During Transaction
• Red – Low battery during transaction
Micro USB
Walker, USB cable, User manual
Micro USB Port for
Charging & Operation
LED Indicator
Lanyard Hole
Advertisement
Related Manuals for AnywhereCommerce Walker
Summary of Contents for AnywhereCommerce Walker
- Page 1 Light Indicator Light ON • Green – Battery Full Charge • Red – Charging Light Flashing • Green – During Transaction • Red – Low battery during transaction Communication Channel Micro USB In The Box Walker, USB cable, User manual...
- Page 2 Download and install the merchant payment application on your smartphone or tablet Step 3 Plug Walker into the audio jack of your smartphone or tablet. You may need to remove the protective case from your phone or tablet if it prevents Walker from being properly plugged into the audio jack.
-
Page 3: Troubleshooting
Don’t remove a chip card until prompted by your payment application. WARRANTY Walker has a six month warranty for manufacturing defects. The warranty is void if the serial number has been tampered with or removed. Please contact your merchant services provider for support. - Page 5 376 Victoria Ave. Suite 418 Montreal, Quebec, QC H3Z 1C3, Canada...
