Summary of Contents for AquaIOT Aquaeegg
-
Page 2: What's Included
What’s Included Waterproof Plugs Aquaeegg Device Charging Cable Tether... - Page 3 1. Get the App Download the AquaIOT app for your smart phone by scanning this QR code or search AquaIOT in the app store.
- Page 4 2. Turn on Sensor Remove the Aquaeegg from the box and confirm the black mark on the sensor is aligned with the "OFF" position (as shown below, left). Rotate the sensor clockwise by 45° and align the black mark on the sensor with the "ON" position (as shown...
- Page 5 3. Charge your Aquaeegg Use the charging cable to connect Aquaeegg device and USB power port. Pay attention to the protruding surface of the charging cable is on the outer flank. During charging, the Aquaeegg flashes red light. The green light flashes when charging is completed (Aquaeegg can be charged in ON or OFF state).
- Page 6 Secure the sensor of Aquaeegg with a fixed coil, please ensure that the rope loop does not slip off. Tie the other end of the tether to some objects on the shore, preventing Aquaeegg from drifting away. Use tether wire to fetch Aquabot when needed.
- Page 7 Importantly, first insert the waterproof cover into the charging port before the Aquaeegg is put into the water. Tilt the Aquaeegg for 45-degree with the gas outlet of the sensor facing up (as shown below), and slowly place it into water or pool, to avoid trapping air bubbles inside the sensor. Slowly shake a few times in water to release air bubble if necessary.
- Page 8 6. Connect Aquaeegg Make sure your phone is within a range of 50 meters to the Aquaeegg and Bluetooth is ON. Start the AquaIOT APP on your phone. It will automatically search and connect Aquaeegg device. The message of “Connection Successful” will show on the screen if Aquaeegg connection is successful. If the connection fails, please...
- Page 9 7. Activate Aquaeegg Sensor When Aquaeegg is used for the first time or reuse after a long time, please activate Aquaeegg on App (Aquaeegg will automatically analyze the test environment and complete calibration). The calibration method is shown below. Click the "Calibration" button in App settings, the Aquaeegg will flash blue light, which takes about 10 minutes.
-
Page 10: You're Done
You’re Done! Congratulations! Your Aquaeegg has been set up and ready to go. Srcoll down the screen To query the historical the App displays the water data, click Data icon at quality data of the hourly the bottom right automatic tests between corner of the screen. - Page 11 You Can Set Light Modes! You can set the light mode in the menu by scrolling the screen right. Mode 1- Lights Up: LED is always on and changes color according to water quality. Red indicates poor water quality. Green indicates good water quality. Yellow indicates fair water quality.This mode uses power quickly.
- Page 12 Enter Pool Volume to Get Chemical Recommendations You need to enter the amount of water in your pool in our app settings interface so that the APP can provide recommendations for chemical dosage.
-
Page 13: Replace Sensor
Align the top of the sensor module with Aquaeegg plug-in hole. Pay attention to align the small protrusion on the sensor to the alignment nut on the Aquaeegg device.Then press in and hold the sensor module, and rotate it clock- wise for 90 degree until no further rotation can be made. -
Page 14: Quick Tips
When Aquaeegg is used for the first time or used after being idle for a long time, Aquaeegg needs to be calibrated at the App client, which takes about 10... - Page 15 Water Quality Guide For water quality of swimming pool Illustration of pH（Acidity and Temperature （Oxidation- (Residue （Total dissolved solids） light colour alkalinity） Reduction （℃） Chlorine) Potential） Green indicates ≥650mV good water quality 7.2≤pH≤7.8 0≤TDS≤2000ppm 1≤RC≤3ppm 23≤T≤28 respectively Yellow indicates 20≤T＜23 7.0≤pH＜7.2 0.5≤RC＜1ppm 600 ≤...
-
Page 16: Product Specification
Product Specification Product Specification Wireless communication Bluetooth4.2 ( Bluetooth Low Energy ) Wireless range 50 meters (outdoor) Dimensions( HxD ) 100 *84 mm Swimming pool(mainly for pool using clorine/bromine chemicals. Please note that Test Environment salt pool may reduce lifetime of sensor due to severe erosion) Safe Environment Sunshade, room temperature, keep ventilation, dry. -
Page 17: Important Safety And Compliance Information
· Do NOT drop this product from a high place. If the product is found cracked, it cannot be placed in water. · Although Aquaeegg is a fun device, it is a tool, not a toy. Do NOT throw the product into water. -
Page 18: Fcc Warning
This equipment should be installed and operated with minimum 20cm distance between the radiator your body: Use only the supplied antenna. Regardless of whether it is during the warranty period, Aquaeegg is not responsible for any damage or injury caused by using the product. Aquaeegg only bears the compensation up to the product payment limit.
