Summary of Contents for ACTii AC8386
- Page 1 Coaxial HD Integrated ZOOM CAMERA AC8386 Factory Default : Address Code :1 Protocol :Pelco-D Baud Rate :9600...
- Page 2 ●FEATURES High Resolution This camera use a high performance megapixel CCD or CMOS,which provides high resolution, clear, noiseless and reliable image; Effective pixels can reach 700TVL,800TVL,1000TVL and 1.3/2 megapixel.18X/22X/30X/36X Optional; OSD Menu/Line control/RS-485 Control Remote control operations are possible through RS-485 signal interface, also can control the lens by external control line. Day/Night Camera will auto switch to color at daytime and B/W at night according to the environment illumination to ensure a high sensitivity and clear image.
- Page 3 Connect the video output jack on the back of the product to the DVR. * The method of connecting the camera to a DVR varies depending on the cable model. Please refer to the instruction of the physical cable. * Please powered off before connecting. Connecting Power line and control line DC power pack output and camera power supply input connecting as follow: ATTENTION...
- Page 4 SAVE AND EXIT 700TVL camera menu setting LANGUAGE CHINESE/ENGLISH CAMERA ID ON/OFF HIGH/MIDDE/LOW DAY&NIGHT CDS/COLOR/BK/AGC FOCUS KAUTO/MANUL/AUTO BAUD RATE 2400/4800/9600 BRIGHTNESS 0-24 SHARDNESS 0-15 MIRROR ON/OFF ON/OFF LEVEL 800TVL camera menu setting LANGUAGE CHINESE/ENGLISH CAMERA ID 0--255 Z DISPLAY ON/OFF DAY&NIGHT CDS/COLOR/BK/AGC FOCUS...
- Page 5 (2) If beyond 12 months from you getting the camera, our company promises that we will provide a payment that if customer needs maintenance service for life. 2. Repair response time (1) When the camera arrives at our company, the response service is within 24 hours. (2) The customer need contact our company staff before sending camera back;...
