Adorama Flashpoint Monolight FP1220A Quick Start Manual

Safety Precautions:

1.
Before using the light, make sure that the electrical outlet of your local power supplier matches the power regulation
indicated on your lighting equipment.
2.
Do not use any power supply other than the AC specification indicated on your equipment.
3.
Do not expose your lighting equipment to sunshine, moisture, dust, dirt, rain, or water.
4.
Any exposure to chemical solutions, gasoline, grease, oil, paint, or detergents can result in permanent damage to your equipment.
5.
Do not insert metal parts into any lighting equipment.
6.
Dry your hands before handling the equipment, as touching your equipment with wet hands is dangerous to both the equipment and to
you.
7.
Do not keep the power on when the light is not in use.
8.
Do not attempt repairs to your lighting equipment personally. If a problem arises, contact the store from which you purchased the light.
9.
If the beeper buzzs for a long time or there is no response from your flash,please turn off the strobe and restart it again.
10.
This flash has an overfrequency protection circuit,rapid continuous firing of your flash will cause an audible alert.continued rapid firing
after audible alert will cause the flash to cease operation and trigger a "cool down" period of approximately of 10 seconds.after this
period,the flash will resume operation.you may also reboot the flash by cycling the power off and then on.

Specifications:

Model
Power Supply
Strobe output
Guide No. (ISO100)
Cooling Fan
Power Setting
Recycle Time
Flash Duration
Recycle Indication
Flash Beam Width
Slave Sensitivity
Modeling Lamp Output
Color Temperature
Synch Cord Voltage
Triggering
Fuse
Housing Size
Body Weight
Light Body &
Rearward
Control Panel
(1) Socket: AC Power Supply
(2) Safety Fuse
(3) Socket: Synch Cord
(4) On/off switch: general power supply
(5) On/off switch: modeling Lamp
(6) On/off switch for Beeper
(7) Recharge Ready-Light
(8) Slave Sensor
(9) Handle Grip
(10) On/off switch for sensor
MONOLIGHT 1220A/1820A/2420A
FP1220A FP1220A
600WS 600WS
76m 76m
<5s <5s
Ready Light & Audio Signal & Modeling Lamp Ready Light & Audio Signal & Modeling Lamp Ready Light & Audio Signal & Modeling Lamp Ready Light & Audio Signal & Modeling Lamp
Synch Cord & Test Button & Slave Senor & Radio Trigger Synch Cord & Test Button & Slave Senor & Radio Trigger Synch Cord & Test Button & Slave Senor & Radio Trigger Synch Cord & Test Button & Slave Senor & Radio Trigger
136×127×300mm 136×127×300mm
2.4kg
(11) Locking/Releasing Bolt for Reflector& Soft Box Connector (16) Stand Mounting Bolt
(12) Test Button
(13) Output Power Setting: flash/ modeling lamp
(14) Handle for Angle Adjustable
(15) Stand Mounting
-1-
FP1820A
AC100−130volt 60Hz AC100−130volt 60Hz AC100−130volt 60Hz AC100−130volt 60Hz
900WS
90m
Built-in Mini Fan Cooler Built-in Mini Fan Cooler Built-in Mini Fan Cooler Built-in Mini Fan Cooler
1/16 to 1/1 continuously 1/16 to 1/1 continuously 1/16 to 1/1 continuously 1/16 to 1/1 continuously
1/1500–1/800s 1/1500–1/800s 1/1500–1/800s 1/1500–1/800s
Over 55 Degree Over 55 Degree Over 55 Degree Over 55 Degree
Over 33ft. Radius,360 Degree Over 33ft. Radius,360 Degree Over 33ft. Radius,360 Degree Over 33ft. Radius,360 Degree
Halogen E27/250W Halogen E27/250W Halogen E27/250W Halogen E27/250W
5600K 5600K 5600K 5600K
6V DC 6V DC 6V DC 6V DC
10A 10A 10A 10A
136×127×400mm 136×127×400mm
3.2kg
FP2420A
1200WS
115m
<6.5s <6.5s
3.4kg
(17) Umbrella Holder
(18) Modeling Lamp
(19) Replaceable Flash Tube
