Model:EACHINE TXC23 VTX
Input voltage:DC 6-36V
Output voltage:5V/1A
12V/PIT@30mA
12V/25mW@140mA/16dBm
12V/200mW@1 90mA/24.5dBm
12V/600mW@280mA/28dBm
12V/800mW@330mA/30dBm
Antenna interface:MMCX
Output power:PIT / 25mW / 200mW / 600mW / 800mW switchable
Frequency:5.8GHz 6 bands, 48 channels
Size:VTX（28mm x 28mm x 1.6mm）
Externai Expansion Board（36mm x 36mm x 1.6mm）
Product dimensions:
2
Advertisement
Table of Contents
Summary of Contents for Eachine TXC23 VTX
- Page 1 EACHINE TXC23 VTX Product specifications Model:EACHINE TXC23 VTX Input voltage:DC 6-36V Output voltage:5V/1A 12V/PIT@30mA 12V/25mW@140mA/16dBm 12V/200mW@1 90mA/24.5dBm 12V/600mW@280mA/28dBm 12V/800mW@330mA/30dBm Antenna interface:MMCX Output power:PIT / 25mW / 200mW / 600mW / 800mW switchable Frequency:5.8GHz 6 bands, 48 channels Size:VTX（28mm x 28mm x 1.6mm）...
- Page 2 EACHINE TXC23 VTX 1. Make sure the antenna is already installed at output before powering up, to avoid damaging the internal components. 2. Please note that the input voltage is within the specified range and wiring is correct, to avoid damaging the internal components.
- Page 3 EACHINE TXC23 VTX Power button settings: 1. Click the button to switch power. The power of this VTX is switched and cycled in the order of PIT→25mw→200mw→600mw→800mw. 2. Press and hold the button for more than 2 seconds to switch directly to PIT from the current transmit power;...
- Page 4 EACHINE TXC23 VTX...
