Summary of Contents for Safelincs XFP
- Page 1 16 ZONE REPEATER PANEL installation manual approved document no. DFU1200502 Rev 1...
- Page 2 Connecting the Repeater wiring ........................8 Technical specifications ......................8 Please refer to the Installation & Maintenance Manual and User Guide / Log Book supplied with the main XFP panel for details of the repeater’s indicators, controls and programming options. Disclaimer © 2005-2007. No responsibility can be accepted by the manufacturer or distributors of this range of fire panels for any misinterpretation of an instruction or guidance note or for the compliance of the system as a whole.
- Page 3 Anti-static handling guidelines Always observe appropriate electro-static handling precautions prior to handling the panel’s PCBs or any other static-sensitive components. XFP ENGINEERING MANUAL • Approved Document No. DFU1200502 Rev 1 • Page 3 of 8...
- Page 4 The total network length for a repeater network must not exceed 500m. Each repeater offers all the functions and controls of an XFP main panel (access levels 1, 2 and 3). Repeaters do not include an RS232 PC programming connector. System programming must be carried out at the XFP main panel using the panel’s upload/download programming tools and a Windows PC.
- Page 5 Always ensure if a knockout is removed, the hole is filled with a good quality 20mm cable gland. Any unused knockouts must be securely blanked off. XFP ENGINEERING MANUAL • Approved Document No. DFU1200502 Rev 1 • Page 5 of 8...
- Page 6 PLK2 AUX 24V Battery I Black refer to page 7. connector socket BAT1 (connect other end of lead to the rear of Main Control PCB). XFP ENGINEERING MANUAL • Approved Document No. DFU1200502 Rev 1 • Page 6 of 8...
- Page 7 ELECTRICITY - OBSERVE DISPOSE OF USED BATTERIES ACCORDING VOLTAGES - PLEASE REFER TO PRECAUTIONS BEFORE INSTALLATION INSTRUCTIONS HANDLING TO THE MANUFACTURERS INSTRUCTIONS. FOR OPERATIO CONSULT THE XFP ENGINEERING MANUAL • Approved Document No. DFU1200502 Rev 1 • Page 7 of 8...
- Page 8 380 x 235 x 77mm (back box); 380 x 235 x 16m (lid) Approx weight: 1.9kg (without batteries) Cabling requirements: 1.5mm two core fire resistant, screened Max. no. of repeaters: Max. cable length per repeater network: 500m XFP ENGINEERING MANUAL • Approved Document No. DFU1200502 Rev 1 • Page 8 of 8...
