IBC Brand Cleaner SC Instruction Manual

Thank you for choosing the IBC Brand Cleaner SC. The IBC Brand Cleaner SC is a high-performance device
designed for cleaning the ferrule end faces of SC, ST and FC connectors with UPC and APC polishes. Please
carefully read these instructions before using this device. Please keep the instructions for future reference.
1. Safety Precautions
Though our device is deemed safe, improper usage or handling can still inflict injury to others.
IBC Brand Cleaner SC is designed to clean SC connectors, ST connectors and FC connectors only.
US Conec is not liable for damage caused in attempt to apply this device to other applications.
2. Notes on Usage
Do NOT attempt to disassemble as this can cause damage to the device and void the warranty.
Do NOT try to re-use the cleaning cloth as this will eliminate the cleaner's effectiveness and void warranty.
Do NOT touch the cleaning cloth as this will cause contamination.
Do NOT pull the cleaning cloth, use only the device body.
Do NOT use this cleaner when the cloth is empty. This may can cause damage to the connector.
3. Notes on Storage for Extended Periods
Do not leave the cleaner exposed to direct sunlight, high temperature or high humidity over an extended period.
The dust cap should be closed at all times when device is not in use.
4. Cleaner construction
C. Lock Button
D. Outer Shell
B. Nozzle
F. Indicator
E. Guide Cap
Standard Mode
No. Part Name
Tip
A
Nozzle
B
C Lock Button
D Outer Shell
Guide Cap
E
Indicator
F
TM
IBC Brand Cleaner SC Instruction Manual
Push Lock Button
Pull Nozzle
A. Tip
Pull Nozzle while
pushing lock button.
Extended Mode
Lead the cleaning cloth to the optical connecter end face.
Lead tip to the optical connecter end face.
Push the button to extend and contract the nozzle.
Push the outer shell to clean the connector.
Acts as dust cap or cleaning adapter for connector plug.
Provides indication of remaining cleaning cloth.
残量 残量確認窓外観
View of Indicator
Cloth
多
(White)
Full
Cloth
少
(White)
Little
Red
無
Empty
Red
Identification of remaining cloth
Function
先端部外観
View of the Nozzle end
Tip (Black)
Cloth (White)
Tip (Black)
No Cloth
(Black)
