MICROSOFT SURFACE HUB 2S
Screen Size:
Max Weight:
50"
60kg
Please carefully inspect the product before assembling. If you notice any apparent damage, call your carrier claims agent and
do not continue the installation until it has been reviewed. Please watch for pinch points. Do not put your fingers between
moveable parts. Do not tamper with or disassemble any spring loaded parts. Before installing, make sure that the supporting
surface will support five times the combined load of the solution and the hardware. Never exceed the maximum load
capacity. Please also layout all components to ensure that you have all of the required parts before proceeding (see BOM list
on following page). Use of this product for anything other than its specified use may result in failure or personal injury. This
product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or
lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676.
AVECTA TROLLEY
WARNING
01865 767676
sales@unicol.com
www.unicol.com
Revised 08/11/19
Advertisement
Table of Contents
Summary of Contents for Unicol AVECTA TROLLEY
- Page 1 01865 767676 sales@unicol.com www.unicol.com MICROSOFT SURFACE HUB 2S AVECTA TROLLEY Screen Size: Max Weight: 50” 60kg WARNING Please carefully inspect the product before assembling. If you notice any apparent damage, call your carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch points. Do not put your fingers between moveable parts.
- Page 2 610mm Column - Split Top 30cm Mast Front In-Fill Panel 760mm Column - Split Lower 30cm Mast Rear In-Fill Panel Avecta Trolley Base 15cm Mast Front In-Fill Panel 15cm Mast Front In-Fill Panels 15cm Mast Rear In-Fill Panel Set Screws (Grub Screws)
- Page 3 01865 767676 sales@unicol.com www.unicol.com STEP 1 STEP 2 Turn the base upside down and push each castor All columns have a half-moon notch at one end until it clicks into place. Please ensure that the and 2 of the columns will have holes at 75mm from castors with brakes are located at the front.
- Page 4 01865 767676 sales@unicol.com www.unicol.com STEP 5 STEP 6 Place top columns over the column couplers Gently tighten. STEP 8 STEP 7 Tighten all column assembly grub screws including Place twin column mount adapter assembly over those located near the base.
- Page 5 01865 767676 sales@unicol.com www.unicol.com magnets STEP 10 STEP 9 With the help of another person place the screen Carefully, locate the mount fixing holes located on (in landscape) onto the twin column mount adapter the rear of the Microsoft Surface Hub 2S and fix assembly, ensuring that the arms are securely in the two mount arms into position.
- Page 6 01865 767676 sales@unicol.com www.unicol.com STEP 14 STEP 13 Cable up and then identify remaining mast in-fill Identify mast in-fill panels (the 4 with cut-outs go panels. Start from the bottom and clip 2 of the 3 to the rear). Start from the bottom and clip the 4...
