OUTDOOR 13' SEE THROUGH FIREPLACE SYSTEM
Natural Gas
Serial #: 7280
www.acucraft.com
888-317-6499
Complies with ANSI Z21.97-2014 / CSA 2.41-2014
Installation/Operator's Manual
Rev3
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7280 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acucraft 7280

  • Page 1 OUTDOOR 13’ SEE THROUGH FIREPLACE SYSTEM Natural Gas Serial #: 7280 www.acucraft.com 888-317-6499 Complies with ANSI Z21.97-2014 / CSA 2.41-2014 Installation/Operator’s Manual Rev3...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction ................. pg 3 Safety / Guide ..............pg 4 Installation Guide System Illustration ..............pg 8 Wiring Diagrams ..............pg 9 Connecting the Gas Valve & Ignition System ......pg 10 Installing the Log Set ............. pg 14 Operation Guide Instructions ................
  • Page 3: Introduction

    INTRODUCTION Acucraft Fireplaces 19672 172nd Street Big Lake, MN 55309 www.acucraft.com 888-317-6499...
  • Page 4: Safety / Guide

    The appliance is rated for installation up to 4500’ (1372m) damaged. For replacement please contact Acucraft at: above sea level. Above 4500’ the appliance must be 763-263-3156 or service@acucraft.com.
  • Page 5: Installation Guide

    INSTALLATION GUIDE Note: The installation of this product must conform with local codes or, in the absence of local codes, the cur- rent National Fuel Gas Code - ANZI Z223.1 (NFPA 54) Installation Code. Please check local codes before installation. NOTE TO INSTALLER: 1.
  • Page 6 It is imperative that the control compartment, burners and circulating air passageways of the appliance be kept clean. 2. Carefully inspect for shipping damage. If any parts are damaged, call Acucraft at 763-263-3156. 3. Correct installation and proper placement of the unit and decorative media is crucial to safe performance of the unit.
  • Page 7 INSTALLATION GUIDE GAS INFORMATION Fuel - Before making gas connections ensure appliance being installed is compatible with the available gas type. Gas Pressure - Proper Input Pressures are required for optimum appliance performance. Gas line sizing re- quirements need to be made following NFPA51. Pressure Requirements for Appliance (Natural Gas) Minimum Inlet Pressure: 0.25 psi...
  • Page 8: System Illustration

    COMBUSTION INTAKE RELIALE OPERATION RELATIONSHIP WITH CHIMNEY FAN BURNER/FUEL DELIEVRY METHOD PROVEN DRAFT SWITCH (PDS) GLASS COOLING INTAKE COMPONENTS FOR INDUCED DRAFT PILOT BURNER AUTOMATIC DRAFT CONTROL (ADC) UTILITY AND GAS INSTALL` TRANSFORMER FAN DISCONNECT SWITCH © 2015 ACUCRAFT FIREPLACES...
  • Page 9: Wiring Diagrams

    INSTALLATION GUIDE...
  • Page 10: Connecting The Gas Valve & Ignition System

    INSTALLATION GUIDE...
  • Page 11 INSTALLATION GUIDE...
  • Page 12 INSTALLATION GUIDE...
  • Page 13 INSTALLATION GUIDE Control Box Connection of the ignition system to the burner. On the side of the AWEIS there are two connections for the pilot burner assembly. The white “quick connect” is the electrical connection and the brass plumbing fitting is the gas connection. There is a label next to these connections, “Attached Pilot Burner Here.”...
  • Page 14: Installing The Log Set

    INSTALLATION GUIDE Installing the Log Set WARNING Always wear protective equipment when dealing with open flames. Failure to follow this warning may result in serious injury. Log placement is very important for the proper operation of the Real-Fyre® gas log set. Although you have some flexibility in the log arrangement, it is necessary to follow the LOG PLACEMENT instructions carefully to fully enjoy your log set.
  • Page 15 INSTALLATION GUIDE Installing the Log Set...
  • Page 16 INSTALLATION GUIDE Installing the Log Set Note: Optional Charred Series log sets are supplied with an ember screen (Fig. 8-1). Attach the ember screen to the burner by slipping it onto the back edge (center left to right) with the perfo- rated section facing toward the back fireplace wall (Fig.
  • Page 17 INSTALLATION GUIDE Installing the Log Set...
  • Page 18 INSTALLATION GUIDE Installing the Log Set...
  • Page 19: Instructions

    INSTALLATION GUIDE OPERATING INSTRUCTIONS WARNING Do NOT use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. WARNING Fire Risk / Burn Risk / HOT! DO NOT TOUCH SEVERE BURNS MAY RESULT - CLOTHING IGNITION MAY RESULT...
  • Page 20: Lighting Instructions

    INSTALLATION GUIDE LIGHTING INSTRUCTIONS 1. Prior to turning appliance on, visually inspect fire feature to ensure debris such as leaves or other combustible material has not collected inside the feature which could burn and emit embers once the fire feature is turned on. Also ensure any person standing close to the fire feature is aware that you will be turning the fire feature on prior to actually turning it on.
  • Page 21: Troubleshooting

    24 volts. If you do have a minimum of 24 volts at the fire feature contact Acucraft for further assistance: 763-263-3156. Q: I installed the Electronic Ignition System, turned it on and I can see the glow plug glowing orange and I can hear gas flowing but it will not ignite.
  • Page 22 2.0 amps. If you do not see the amps listed above AND the wire gauge used was less than 12 gauge wire - change the wiring. Otherwise contact Acucraft for further assistance: 763-263-3156.
  • Page 23: Caution

    INSTALLATION GUIDE CAUTION • Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition •...
  • Page 24: Maintenance & Care

    INSTALLATION GUIDE MAINTENANCE AND GENERAL CARE • Examination and inspection of the appliance and all components including the burner, should be performed annually by a qualified service technician • Examination and visual check of the burner & flame should be performed periodically to ensure prop- er operation •...
  • Page 25: Specifications

    PRODUCT SPECIFICATIONS SPECIFICATIONS NATURAL GAS Height = 79 3/8” Based on testing that was performed, the following results have been re- Width = 156” Input Rating (BTU/hr) 0-1370 m = 290,000 BTUs/hr. corded. Depth = 36” Minimum inlet pressure (in.w.c.) = 7.0 in. W.C. Minimum Clearances to combustibles Appx Weight.
  • Page 26 PRODUCT SPECIFICATIONS...
  • Page 27 PRODUCT SPECIFICATIONS...
  • Page 28 PRODUCT SPECIFICATIONS OUTDOOR DECORATIVE GAS APPLIANCE MANUFACTURER: Serial #/En Série: Acucraft Fireplaces MODEL/ MODELE: Outdoor 13’ See Through Fireplace 19672 172nd St Big Lake, MN 55309 (763) 263-3156 GAS / TYPE DE GAZ: Natural Gas (Gaz naturel) INPUT RATING (ENTRÈE NOTE) (Btu/hr) 0-610m: 290,000 ORIFICE SIZE (DIMENSIONS DE L’ORIFICE) (DMS) 0-610m:...
  • Page 29: Notes
