- Page 4 STEP 1 Attach the Front Side Rails (P5) to the Front Deck (P2) using six of the F3 bolts (into the slats), two of the F5 bolts (into the front lip) and six of the barrel nuts (F8). When attaching the side rails, insert each bolt and tighten slightly one by one, not fully tightening.
- Page 5 STEP 3 Attach the Back Legs (P10) to the Rear Side Panels (P7) using the four F2 bolts. Then attach the “L” bracket (F11) using the four F6 screws. STEP 4 Attach the Rear Side Panels (P7) to the Rear Deck (P4) using six of the F3 bolts and six barrel nuts (F8).
- Page 6 STEP 7 Join the Front Deck (P2) to the Middle Deck (P3) using two of the Clevis Pins (F9). STEP 8 Tilt the decks (as shown in the image) to inset them between the arms and slot the rollers into the cut out grooves. STEP 9 Attach the Rear Deck (P4) to the Middle Deck (P3) using the two remaining Clevis Pins (F9).
