1. About Stratus ES/ESG

1.1.

Overview

Stratus ES and Stratus ESG by Appareo are panel-mounted level 2els Class 1 Extended
Squitter transponders. They are Class B1S transponders which are ADS-B Out compliant.
Stratus ES and Stratus ESG respond to legacy Mode A/C interrogations and Mode S
interrogations from both ground radar and airborne collision avoidance systems. To support the
ADS-B Out function, Stratus ESG also contains a Class Beta 1 GPS/WAAS receiver. Stratus ES
receives GPS information from approved GPS position sources.
Stratus ES/ESG may be referred to as "transponder" unless product differences require them to
be identified separately.
The most recent version of this document and other Stratus ES/ESG documentation can be
found on the Appareo Dealer Portal or at www.appareo.com/resources.
1.2.

TSO and FCC compliance

TSO
Stratus ES/ESG is compliant with the following Technical Standard Orders:
Reference/Issue
FAA TSO-C112e
FAA TSO-C145d
(Stratus ESG only)
FAA TSO-C166b
FCC
Stratus ES/ESG has an FCC ID of 2AETC-1505005.
1.3.

TSO deviations

TSO
TSO-C145d
(Stratus ESG only)
600840-000031 Stratus ES/ESG Installation Instructions
Technical Standard Order: Air Traffic Control Radar Beacon
System/Mode Select (ATCRBS / Mode S) Airborne Equipment
Technical Standard Order: Airborne Navigation Sensors Using The
Global Positioning System
Technical Standard Order: Extended Squitter Automatic Dependent
Surveillance - Broadcast (ADS-B) and Traffic Information Service -
Broadcast (TIS-B) Equipment Operating on the Radio Frequency of
1090 Megahertz (MHz)

Table 1: TSO compliance

Section
Section 3, Subpart D

Table 2: TSO deviations

Title
Deviation
Environmental qualification testing was
performed to DO-160G, not DO-160E.
Rev. 2.1
Last Revised: June 22, 2017
Page 11 of 44
