Bradford White M-I-MH30T6FLX Specification Sheet

Residential Manufactured Home Atmospheric Vent
Energy Saver Gas Water Heater
Photo is of
M-I-MH30T6FLX
Bradford White received the highest numerical score among water heater/boiler manufacturers in the proprietary J.D. Power and Associates/ McGraw-Hill Construction 2006 HVAC and Water Heater/Boiler Subcontractor Satisfaction Study
Study based on 882 responses measuring 3 water heater/boiler manufacturers and measures opinions of subcontractors. Proprietary study results are based on experiences and perceptions of subcontractors surveyed in May through July 2006. Your
experiences may vary. Visit jdpower.com
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 7,063,133 B2; 5,954,492; 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185;
5,485,879; 5,277,171; (B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968;
4,672,919; Re. 34,534. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105.
Defender Safety System ® , ScreenLok ® and Vitraglas
"Highest in Subcontractor Satisfaction among Water Heater/Boiler Manufacturers"
The Manufactured Home FVIR Defender Safety System
Advanced ScreenLok
I
arrestor is designed to prevent ignition of flammable vapor outside of the
water heater.
Resettable Thermal Switch—Proven and reliable bimetallic switch prevents
I
burner and pilot operation in case of ongoing flammable vapor burn inside of
the combustion chamber or restricted air flow.
Piezo Igniter—Easy and quick lighting of the pilot burner by push button.
I
Pedestal Base—Rugged and durable base allows easy transport and
I
positioning, while providing corrosion resistant contact with floor.
Maintenance Free—No regular cleaning of air inlet openings or flame arrestor
I
is required under normal conditions.
Sight Window—Offers a view into the combustion chamber to observe the
I
operation of the pilot and burner.
Housing and Urban Development—This water heater is designed in
I
accordance with H.U.D. and is certified for installation in a manufactured
home(mobile home) only and must be installed in an enclosure that will
completely separate the water heater combustion and venting system from the
dwelling interior.
Optional Roof Jack Kit for Installation Flexibility—Roof Jack Kit must be
I
used when venting and must specify roof size clearance when ordering.
Available in 12", 18"/32", 32"/60" or 48"/90".
Vitraglas ®
I
corrosive effects of hot water by an exclusive ceramic porcelain-like coating.
The Bradford White high silica Vitraglas
for our hot water tanks.
Fully Automatic Controls—Automatic temperature selection at your
I
fingertips. Built-in energy cut-off switch prevents abnormally high water
temperature for extra safety. Built-in gas pressure regulation.
Convertible Gas Control—Easily convertible control for use with either
I
Propane or Natural Gas.
1" Non-CFC Foam Insulation—Covers the side and top of tank, saving
I
energy by retarding loss of heat.
Water Connections—3⁄4" NPT factory installed true dielectric fittings extend
I
water heater life and eases installation.
Heat Trap—Installed on hot water outlet to minimize heat loss through piping.
I
Protective Magnesium Anode Rod—Provides added protection against
I
corrosion for long trouble-free service.
3"x4" "Snap Lock" Draft Diverter—Allows either 3" or 4" vent connections
I
with inputs of 40,000 BTU/Hr. or less.
Flue Baffle—Maximizes the amount of heat absorbed by the tank and
I
reduces heat loss during standby periods.
Steel Tank—Heavy gauge steel automatically formed, rolled and welded.
I
T&P Relief Valve—Included.
I
Brass Drain Valve.
I
Design Certified by CSA International (formerly AGA/CGA).
I
6 or 10-Year Limited Tank Warranties / 6-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties. See complete
copy of the warranty included with the heater.
® are registered trademarks of Bradford White
® Technology Flame Arrestor Design—Flame
Lining—Bradford White water heater tanks are protected from the
®
® Corporation.
®

Models Feature:

lining provides a tough interior surface
SM .
110-B 0807
