Zuiver TRAVIS Assembly Instructions

ASSEMBLY INSTRUCTIONS
CABINET TRAVIS
A
C
- PLEASE DO NOT DISCARD ANY OF THE PACKAGING UNTIL YOU
HAVE CHECKED ALL THE PARTS AND THE PACKS OF HARDWARE.
- BEFORE YOU BEGIN TO ASSEMBLE YOUR NEW PIECE OF
FURNITURE, PLEASE CHECK TO ENSURE THAT ALL PARTS HAVE
BEEN SUPPLIED.
- FOLLOW INSTRUCTIONS CLOSELY AS DEVIATION FROM THEM
MAY VOID YOUR WARRANTY AND PRESENT A POSSIBLE SAFETY
RISK.
- IT IS RECOMMENDED THAT ASSEMBLY IS DONE ON A SOFT
SURFACE LIKE CARPET TO AVOID ANY DAMAGE.
- PERIODICALLY CHECK AND RE-TIGHTEN ANY FASTENERS. WIPE
DOWN ALL SURFACES WEEKLY WITH A CLEAN CLOTH. DO NOT
CLEAN ANY SURFACES WITH HARSH ABRASIVES OR CHEMICALS.
1.
E
C
B
F
E
G
D
G
F
G
05
01
Parts Check List
Components
Code
A BODY
B WINE RACK
C D LEG FRAME
E BACK STRETCHER
F FRONT STRETCHER
G BOTTOM STRETCHER
Hardware Check List
D
code
01 Short bolt
02 Long bolt
03 Spring washer
04 Plat washer
05 Allen key
06 Metal bracket
07 Screw
08 Plastic strap
09 Nylon wall strap
Tools required
Not supplied
2.
05
100%
description
04
03
02
05
Qty
x01
x01
x02
x01
x01
x02
qty
x20
x18
x18
x18
x01
x04
x04
x02
x02
100%
A
04
03
02
