- Page 1 USER MANUAL Edition 01-2020 Designed, Engineered, and manufactured in Italy...
-
Page 2: Table Of Contents
Ital E-Bike User manual - Edition 01-2020 ............................4 arnings ? .......................5 hat is assisted pedalling ..........................6 asic information Description of the contents........................6 Legal requirements ............................6 For your safety ..............................6 10 rules for riding safely ..........................6 Warranty terms ..............................7 Travelling range of a pedal assisted cycle .....................8 Who can ride your e-bike? ..........................8 Electric assisted pedalling ...........................9 Physical and mental fitness ........................9... - Page 3 Ital E-Bike user manual - Edition 01 - 2020 How to turn your Ital E-Bike on and off ....................29 Password to turn on ...........................30 Selecting assist modes..........................30 Speed, mileage, trip data..........................31 Walk assist mode ............................31 Headlight on/off(day and night mode switch) ................32 Battery level..
-
Page 4: B Asic Information
Ital E-Bike user manual - Edition 01 - 2020 Congratulations on choosing Ital E-Bike Warning, Read this manual carefully and follow the instructions below. • This is a pedal assisted cycle. • It is not a toy, do not allow it to be used by children. •... -
Page 5: Hat Is Assisted Pedalling
Ital E-Bike user manual - Edition 01 - 2020 WHAT IS ASSISTED PEDALING? This bicycle is equipped with an electric assisted pedaling system. An electric motor assists the effort made by the cyclist. To activate the assiist it is necessary to begin pedaling and impart force on the pedals, and consequently the torque sensor. -
Page 6: Who Can Ride Your E-Bike
Ital E-Bike user manual - Edition 01 - 2020 BASIC INFORMATION contents escription of the • E-bike complete with pedals and wheels • Support for transport, which can be used in a vehicle • Battery charger • Instruction manual. egal reQuirements Every road user must follow the traffic regulations in force in their country. -
Page 7: Warranty Terms
Ital E-Bike user manual - Edition 01 - 2020 arranty terms The durability and reliability of the bicycle, as well as the warranty coverage, are valid only if the customer complies with some basic rules: • The use of the e-bike for anything other than the intended design may result in dangerous situations, falls and accidents. -
Page 8: Travelling Range Of A Pedal Assisted Cycle
Ital E-Bike user manual - Edition 01 - 2020 ravelling RANGE of a pedal assisted cycle The Range of an e-bike is dependent on several factors. The electric motor will absorb more power with increased weight and when climbing hills, riding against the wind, stopping and starting repeatedly and changing gear, thereby reducing the distances that can be traveled. -
Page 9: Electric Assisted Pedalling
Ital E-Bike user manual - Edition 01 - 2020 lectric assisted pedalling Ital E-Bike is equipped with an electric assisted pedaling system. Assistance may be set to one of 5 modes (Fig. 1): OFF (No assist) HIGH RACE Decrease assistance ... -
Page 10: Fire
Ital E-Bike user manual - Edition 01 - 2020 RESIDUAL RISKS Only keep the e-bike in rooms with ambient temperatures between 15°f and +100°f. KEEP THE E-BIKE AWAY FROM HEAT SOURCES SUCH AS RADIATORS, HEATERS, STOVES, ETC. IN THE EVENT FLAMES OR SMOKE EMERGE FROM THE BATTERY PACK, IM- MEDIATELY STOP THE BIKE. -
Page 11: Technical Data
Ital E-Bike user manual - Edition 01 - 2020 TECHNICAL DATA Gearbox Ital E-Bike 8 speed electric with rotary gear selection Gear shifters Electrical with a microswitch on the handlebars Gears 8 sequential Motor Ital E-Bike FL80S 48 V 500 Watts Ital E-Bike technology for detection load Torque sensor Ital E-Bike 48Volt 10.5 Ah (504 W/H) lithium-ion battery... - Page 12 Ital E-Bike user manual - Edition 01 - 2020 MAIN COMPONENTS Display Battery closing Battery Battery charger socket Electronic control unit box Gears and motor Single arm fork Kickstand Saddle 10. Seatpost Saddle lock 12. Crank 13. Pedal 14. Wheels 15.
-
Page 13: B Emoving And Installing The Support
Ital E-Bike user manual - Edition 01 - 2020 REMOVING AND INSTALLING THE SUPPORT This special support for your Ital E-Bike is provided with each bike and can be used for easy transport of your Ital E-Bike by vehicle BEFORE SETTING OFF WITH YOUR BICYCLE Be careful whenever you are riding a bicycle, there is a danger of serious falls and... -
Page 14: Checklist Of Controls To Perform Before Each Use
Ital E-Bike user manual - Edition 01 - 2020 • Stop and inspect the proper set up of your newly purchased bike, so as to more easily recognize any anomalies at a later time • If any defects are detected during these inspections, immediately contact your dealer. •... -
Page 15: Checking The Seat And The Seat Post
Ital E-Bike user manual - Edition 01 - 2020 With greater load on the bike, tire pressure should be increased, however do not exceed the maximum pressure marked on the tire. hecking the seat and the seat post If the seat post is not inserted deep enough into the frame, it could separate from the frame while riding and lead to dangerous riding conditions, falls and accidents. -
Page 16: Checking The Brakes
Ital E-Bike user manual - Edition 01 - 2020 hecking the Brakes Faulty brakes can cause hazardous riding conditions, falls and accidents. Mal- functioning brakes could be life threatening. • Check your braking system with particular attention. • During everyday use the discs and the brake pads wear out diminishing their braking power. - Page 17 Ital E-Bike user manual - Edition 01 - 2020 • Before setting off, always raise the stand. The stand will not lower by itself. • Apply gentle force with your hands, making sure that the extractable part does not shift. •...
-
Page 18: General Use
Ital E-Bike user manual - Edition 01 - 2020 GENERAL USE With your Ital E-Bike it is possible to reach unusually high speeds. • Only use your Ital E-Bike if you are able to safely control it while riding and braking at high speeds. -
Page 19: General Summary Of Federal And Local Regulations Governing E-Bikes, And Warnings Regarding Adjusting The Speed Limiter
Ital E-Bike user manual - Edition 01 - 2020 General summary of The United States Code of Federal Regulations The CFR 16 part 1512 defines a bicycle as: (1) A two wheeled vehicle having a rear drive wheel that is solely human powered (2) A two or three wheeled vehicle with fully operable pedals and an electric motor of less than 750 watts (1) hp, whose maximum speed on a paved level surface, when powered solely by such a motor while ridden by an operator who weighs 170... -
Page 20: Ideal Height Of The Saddle
Ital E-Bike user manual - Edition 01 - 2020 ADJUSTMENTS deal height of the saddle The ideal height of the saddle is when, with your foot resting on the pedal in the lowest position and the knee is slightly bent, almost fully extended. It is important that a minimum of one inch of clearance be maintained between the top tube of the bicycle and... -
Page 21: Adjusting The Saddle Height
Ital E-Bike user manual - Edition 01 - 2020 • Loosen the locking screws (A) by a few turns until the seat moves easily and you can adjust the inclination. • Move the saddle to the desired position. • Re-tighten the locking screws (A) with a torque wrench. The specified torque is indicated on the seatpost. -
Page 22: Handlebar Adjustment
Ital E-Bike user manual - Edition 01 - 2020 andleBar adjustment Handlebar - Fig 01 1. Loosen the screws in area (A) until the handlebar is able to rotate 2. Rotate and/or position the handlebars to the desired position B. 3. -
Page 23: Adjusting The Brake Levers
Ital E-Bike user manual - Edition 01 - 2020 Adjustable handlebar stem (if available) - Fig 01 On some models it is also possible to verti- cally adjust the handlebar stem. 1. Loosen the screw (A) (Fig. 1) locking the vertical movement of the handlebar stem. -
Page 24: Ontrols On The Side Right Of The Handlebar
Ital E-Bike user manual - Edition 01 - 2020 CONTROLS ON THE RIGHT SIDE OF THE HANDLEBAR Selection Selection of transmission of transmission gear gear Not used... -
Page 25: Functional Overview
Ital E-Bike user manual - Edition 01 - 2020 USING THE DISPLAY unctional overvieW • Four buttons, easy to operate • Use password to turn on • Mileage display: Subtotal mileage (TRIP), total mileage (ODO) • Speed display: Current speed (SPEED) maximum speed (MAX) average speed (AVG) •... -
Page 26: Home Screen
Ital E-Bike user manual - Edition 01 - 2020 Home screen �� �� �� �� �� �� �� �� �� Headlight: Shows only when the headlight is on. �� Speed: Shows current speed, KM/H or MPH ��... -
Page 27: Settings Screen
Ital E-Bike user manual - Edition 01 - 2020 Settings Screen DEFINITION OF BUTTONS �� Turn on/off �� Function button Adjust + Adjust - OPERATION urn on Hold the on/off button for 2 seconds, the start screen will display and then the wait screen will display. -
Page 28: Password To Turn On
Ital E-Bike user manual - Edition 01 - 2020 Entering the PIN After the "wait screen" is displayed, the password screen is displayed, the correct PIN must be entered within 60 seconds to prevent the display from sutting down. Press ��... -
Page 29: Speed, Mileage, Trip Data
Ital E-Bike user manual - Edition 01 - 2020 Information Screens Press �� to select the three different information screens: TRIP TIME/DISTANCE or ODO/RANGE or AVG SPEED/ MAX SPEED. The three information screens are shown below TRIP TIME MAX SPEED TRIP TIME... -
Page 30: Headlight On/Off(Day And Night Mode Switch)
Ital E-Bike user manual - Edition 01 - 2020 eadlight on day and night mode sWitch Hold the button for 2 seconds to turn on the headlight. The display will change to night mode and the headlight icon will appear. Hold the button again for 2 seconds to turn off the headlight and return the display to daytime mode. -
Page 31: Current Power Usage
Ital E-Bike user manual - Edition 01 - 2020 Current power demand Instantaneous power demand is shown as a horizontal bar graph at the bottom of the home screen. Level 0 Level 1 Level 2 Level 3 Level 4 Level 5 USER SETTINGS Through the settings screen the user can adjust the backlighting, clock, automatic shut down delay, and password settings. -
Page 32: Setting The Units
Ital E-Bike user manual - Edition 01 - 2020 nit setting Unit: Metric/Imperial • Enter unit setting screen, press / to choose KM/H or MPH. Press �� to save the parameter and exit unit setting screen and return to setting screen. ack light setting Brightness adjust screen Press / to choose the level of the backlight, Level 5 is the brightest. -
Page 33: Setting The Password
Ital E-Bike user manual - Edition 01 - 2020 ASSWORD SETTING SCREEN Exit: exit start password screen Start Password: Password function ON/OFF Setting Password: Changing the password • Press / to scroll between, "Exit", "Start Password", and "Setting Password", •... -
Page 34: Setting The Automatic Shutdown Time
Ital E-Bike user manual - Edition 01 - 2020 The new password will need to be entered twice After entering the new password press �� and exit the screen utomatic shutdoWn time setting 10 minutes: Automatic shutdown if 10 minutes no operation and speed of the bike 20 minutes: Automatic shutdown if 20 minutes no operation and speed of the bike 30 minutes: Automatic shutdown if 30 minutes no operation and speed of the bike 40 minutes: Automatic shutdown if 40 minutes no operation and speed of the bike... -
Page 35: Setting The Wheel Diameter
Ital E-Bike user manual - Edition 01 - 2020 heel diameter and speed limitation information Wheel diameter and speed limitation information can only be set by an authorized Ital E-Bike dealer. Users can only view these settings. ystem information revieW S/N: Serial number of equipment FW version: Firmware version number HW version: Hardware version number... -
Page 36: Resetting Factory Settings
Ital E-Bike user manual - Edition 01 - 2020 eset Exit: Exit RESET interface Yes: Reset to factory settings Short press / to select Exit, Yes, select Yes then short press �� o return to factory settings (unit, backlight brightness, turn on password, auto shut off time) and return to user setting interface. -
Page 37: Data Clearance
Ital E-Bike user manual - Edition 01 - 2020 DATA CLEARANCE 10 seconds within display turned on, and speed is 0, long press �� (2 seconds) en- ter the data clearance interface, short press �� to clearance trip mileage(TRIP), riding time(TRIP TIME),average speed(AVG) and maximum speed(MAX). -
Page 38: Error Information
Ital E-Bike user manual - Edition 01 - 2020 ERROR INFORMATION Nr. Status Description Note data 0x01 Normal status LED of controller is on 0x03 Already brake Display will not show 0x04 Torque sensor 0x05 Throttle error 0x06 Under voltage protection Display will not show 0x07 Over voltage protection 0x08 Hall signal error of motor... -
Page 39: How To Activate The Ital E-Bike Anti-Theft System
Ital E-Bike user manual - Edition 01 - 2020 HOW TO ACTIVATE THE ITAL E-BIKE ANTI-THEFT SYSTEM The bike has two anti-theft systems. The first inhibits transmission and can only be deactivated by entering the Ital • E-Bike Pin code. See page 29 "turning on/off" The second system consists of the mechanical locking of the rear wheel. -
Page 40: The Battery
Ital E-Bike user manual - Edition 01 - 2020 THE BATTERY seful information aBout the Battery The charging process must be carried out in a well ventilated area. The battery can be installed in the bicycle or removed from the bicycle while charging . Before charging make sure the battery has not been subjected to large fluctuations in temperature, if so wait 30 minutes for battery temperature to stabilize While charging a red light is lit on the battery charger. -
Page 41: The Ital-Ebike Battery
Ital E-Bike user manual - Edition 01 - 2020 Warnings • The first time the battery must be recharged for at least 7 hours. • For the first 5 uses completely charge the battery and then fully discharge it. This will ensure the maximum performance of the battery pack. Do not store the Ital E-Bike for long periods with the battery discharged. -
Page 42: Battery Technical Data
Ital E-Bike user manual - Edition 01 - 2020 attery technical data Battery: lithium ion, removable Nominal power: 48 V 10.5 Ah Rated capacity: Weight: 5.5 lbs Dimensions: 360x90x85 mm Charging time: 4-5 hours (first time minimum 7 hours) Only recharge the battery using the supplied battery charger. Press the “charge status”... -
Page 43: Lock For Assembly And Taking Apart Of The Battery
Ital E-Bike user manual - Edition 01 - 2020 Lock for instalation and removal of battery Features: The key can only be removed in the CLOSED position. Close 1 CLOSE position: the battery is inserted and locked in the correct position. Open 2 OPEN position: the battery is unlocked and can be removed from the bike. -
Page 44: Installing The Battery
Ital E-Bike user manual - Edition 01 - 2020 nstalling the Battery Close To install the battery be sure that the key is turned to the CLOSED position. Take the battery with your one hand as shown. (Fig.1) and insert the bottom of the battery into the housing inside the main frame tube at a downward angle (Fig. -
Page 45: How Does The Ital E-Bike Battery Perform During Use
Ital E-Bike user manual - Edition 01 - 2020 HOW DOES THE Ital E-Bike BATTERY PERFORM DURING USE It's important to remember that the Ital E-Bike battery reaches its best performance after the first 4 or 5 full charging and recharging cycles and when it is recharged for the first time for at least 7 hours. -
Page 46: Battery Life
Ital E-Bike user manual - Edition 01 - 2020 attery life The life of a Battery depends mainly on the type of use. Like any lithium-ion battery, the Ital E-Bike battery ages naturally, even when not in use. Factors that shorten the life span: •... -
Page 47: Charging The Battery
Ital E-Bike user manual - Edition 01 - 2020 harging the Battery The Ital E-Bike battery can be charged either while installed on the bike (Fig. 1) or when removed from its housing (Fig. 2) by inserting the charging connector plug into the front of the battery. - Page 48 Ital E-Bike user manual - Edition 01 - 2020 Do not clean your bike with water during the battery charging procedure. For longer battery life, use only original Ital E-Bike equipment for the charging Do not pedal or ride the bike while charging the battery, so as to avoid falls or seriously damaging the charging equipment.
-
Page 49: How To Use The Battery Charger
Ital E-Bike user manual - Edition 01 - 2020 oW to use the Battery charger 1. Be sure that connections are in good condition and not damaged in any way. 2. Insert the plug (1) of the power set in a 110 AC outlet. If the plug is inserted in the AC outlet without the battery connected, the two LEDs will be red and green, indicating stand by mode. -
Page 50: Introduction
Ital E-Bike user manual - Edition 01 - 2020 GEARBOX 8 SPEED Your Ital E-Bike is equipped with an innovative gearbox that is similar to that found on a motorcycle or car. It uses a rotary gear selector that is controlled electronicly by microswitches on the handlebars. -
Page 51: Upshifting
Ital E-Bike user manual - Edition 01 - 2020 Gear Gear UPSHIFT (OR INCREASE IN GEAR) This is the change from one gear to a higher gear, i.e. from gear 1 to 8. This may be carried out at any time whether the bike is moving or stationary, and regardless of the force on the pedals. -
Page 52: Motor
Ital E-Bike user manual - Edition 01 - 2020 MOTOR The Ital E-Bike has an electric assistance motor integrated with the gearbox and contained in a die-cast aluminum housing. The brushless 48volt 500watt motor requires no maintenance The motor capable of an output of 500 W with an efficiency level of 85%. The motor weighings only 2 kg. -
Page 53: Aintenance And Care
Ital E-Bike user manual - Edition 01 - 2020 MAINTENANCE AND CARE Regular and proper care of the bicycle is important and one of the conditions for maintaining the warranty. Corrosion caused by poor maintenance or damage caused by winter weather conditions is not covered by the warranty. -
Page 54: Ashing
Ital E-Bike user manual - Edition 01 - 2020 WASHING For washing do not use steam jets or high pressure cleaners. strong water damage your Ital E-Bike or result in a short circuit (fire hazard). For this reason it is advisable to adopt the procedures described below. -
Page 55: P Utting The Bicycle In Storage
Ital E-Bike user manual - Edition 01 - 2020 PUTTING THE BICYCLE OUT OF SERVICE PREPARING THE BICYCLE FOR STORAGE Keep the Ital E-Bike in an enclosed environment protected from the sun and rain. Regularly check the tire pressure, remove the battery and charge it every 2-3 months. - Page 56 Ital E-Bike user manual - Edition 01 - 2020 QUESTIONS AND ANSWERS Question: What speed can I ride this bike at? Answer: It depends on the cyclist. There is no maximum limit. In any case, at speeds above 20 mph, the assistance will be deactivated. Question: Are Ital E-Bikes bicycles very heavy? Answer: No.
- Page 57 Ital E-Bike user manual - Edition 01 - 2020 Question: Do I have to charge the battery when I’m not using it? Answer: For proper use and maintenance of the battery, read the battery section of this manual. Question: What should I do when I’m not going to use the bike for a long time? Answer: It is recommended to charge the battery to 70-80% before storing it for an extended period.
