P.O. Box 1767
Covington, LA, 70434 USA
WM300 WeatherMate
Open the case and click into the fully opened position OR, if
using a tri/unipod, click to 90-degree position and attach,
using the threaded fitting in the bottom of the case.
POWER ON by pressing the ON/OFF button momentarily.
POWER OFF by pressing and holding the ON/OFF button for
approx. 3 seconds.
AUTO POWER OFF: if the meter is inactive for approx. 5
minutes, it will automatically shut down to preserve the
battery.
OPERATING MODES: Turn the unit on using the ON/OFF
button. Use the MODE button on the left to scroll to the
desired function. To turn off the unit, press and hold the
ON/OFF button for 3 seconds, until the display is blank, then
release.
CHANGING UNITS OF MEASURE: With the WeatherMate
on, change the units of measure by selecting the mode you
wish to change (Windspeed or Temperature). Next, press
the UNIT button to change the units of measure. When
changing the mode for windspeed, you will need to press the
UNIT key repeatedly to scroll through options (MPH, KPH,
FPM, MPS, BF (Beaufort) and KNT.
(985) 892-3870
www.weathermate.us
Manual Version 1.00

Advertisement

loading
Need help?

Need help?

Do you have a question about the WM300 and is the answer not in the manual?

Questions and answers

Summary of Contents for WeatherMate WM300

  • Page 1 To turn off the unit, press and hold the ON/OFF button for 3 seconds, until the display is blank, then release. CHANGING UNITS OF MEASURE: With the WeatherMate on, change the units of measure by selecting the mode you wish to change (Windspeed or Temperature). Next, press the UNIT button to change the units of measure.
  • Page 2 NOTE: When you restart your WeatherMate, it will default to the last mode and unit used. TAKING MEASUREMENTS: Hold or place the meter so airflow enters the vane (impeller) from the rear of the unit. When holding the meter, hold it at arm’s length, away from your body.
  • Page 3: Compass Calibration

    represents favorable spraying conditions. When Delta T values are low (i.e. when it is hot and dry), applicators should consider using coarser sprays. WIND DIRECTION/COMPASS: Press the MODE button repeatedly until the Compass mode appears. Point the meter in the direction of travel or target and get a steady compass reading.
  • Page 4 LOW BATTERY: When you see the battery icon in the lower R corner, the battery is low and should be changed as soon as possible, or accuracy will become an issue. WeatherMate uses a Lithium CR2032 battery, available almost anywhere.
  • Page 5 Ausschalten halten Sie die ON/OFF Taste für ca. 3 Sek. gedrückt, bis die Anzeige erlischt. Wechseln der Einheiten: Schalten Sie zunächst die Anzeige des WeatherMate ein und wählen Sie die gewünschte Funktion (Windgeschwindigkeit oder Temperatur) aus. Anschließen können Sie durch Drücken der UNIT (Einheiten) Taste die gewünschte Maßeinheit auswählen.
  • Page 6 Luftstrom direkt von Hinten durch das Windrädchen strömt. Falls Sie mit der Hand messen, halten Sie eine Armlänge Körperabstand ein. Vorsicht: Der WeatherMate misst bei niedrigen bis mittleren Windgeschwindigkeiten sehr genau. Eine ständige Benutzung bei sehr hohen Windgeschwindgkeiten, z.B. aus einem fahrenden Auto, führt zu einer übermäßigen Belastung der...
  • Page 7 Windrichtung/Kompass: Drücken Sie die MODE Taste solange hintereinander bis in der Anzeige das Kompass Symbol erscheint. Halten Sie das Gerät in die Windrichtung oder in Richtung des Messpunktes. Halten Sie nun die UNIT Taste gedrückt bis “Headtailcross” in der Anzeige erscheint, die Anzeige wird nun drei Mal blinken. Lassen Sie die UNIT Taste los und richten den Windmesser so aus, dass der Kompass einen konstanten Wert anzeigt.
  • Page 8 Anzeige erscheint ist die Batterie schwach und sollte umgehen ausgetauscht werden, um die Genauigkeit der Messung zu garantieren. Der WeatherMate verwendet eine Lithiumknopfbatterie vom Typ CR2032. Zum Wechseln der Batterie drehen Sie den Deckel der Batterie mit einer Münze in Uhrzeigerrichtung auf.
  • Page 9 WM300 WeatherMate Manual de Instrucciones 1.0 Abra su WeatherMate® a 180o tal como se indica. Si utiliza un trípode, abra su WeatherMate® como se muestra en la figura de arriba a un ángulo de 90o para acceder al adaptador del trípode.
  • Page 10 Compass (Brújula) y Humidity (Humedad). Más abajo se detalla la secuencia de unidades de medición para cada modelo. Secuencia para el WM300 • muestra la velocidad del viento • muestra la velocidad máxima del viento • muestra la velocidad promedio tomada en 10 segundos •...
  • Page 11 Dirección Digital del Viento Apunte el WeatherMate® directamente hacia el viento y seleccione el modo Compass (Brújula). El extremo de la veleta apuntará directamente hacia usted. La dirección del viento será mostrada digitalmente y en cuartas. La función de brújula también puede calcular el viento cruzado y el viento de frente y de cola.
  • Page 12 Reemplazo del Transductor de Viento Los transductores de WeatherMate® pueden ser reemplazados. Póngase en contacto con su distribuidor en caso de requerir piezas e instrucciones de ensamblaje. P.O. Box 1767 (985) 892-3870 Covington, LA, 70434 USA www.weathermate.us...
