CAUTIONS:
1. Please format the card before power on, otherwise video errors and freezes will occur during video playback. Please
use a high-speed TF card. If a low-speed card is used, problems are likely to occur.
2. You can view the video through the mirror. Or you can connect to the mobile APP to view through the mobile phone.
3. WiFI account: YV09-XXXXXX, Password: 12345678
4. About touch buttons: When two touch areas are touched at the same time, the touch buttons will malfunction
temporarily. Function resumes after 15 seconds.
Note: For the best performance and durability of video recording, we recommend to use C10 U1 level TF card or
better.
NG
Class 4
Class 10
This manual is only for your reference, please check the actual product as the standard!
Serial No.: 2020YV0960114
GOOD
OK
Class U1
Class U3
9.66" 1080P Streaming Media Mirror Monitor
With Built-in Dash Cam
U S E R M A N U A L
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Master Tailgaters MR-10-M2DVR4
- Page 1 CAUTIONS: 9.66” 1080P Streaming Media Mirror Monitor 1. Please format the card before power on, otherwise video errors and freezes will occur during video playback. Please use a high-speed TF card. If a low-speed card is used, problems are likely to occur. With Built-in Dash Cam 2.
-
Page 2: Specifications
PACKAGE FEATURES The package contains the following: Front recording 1080P Night mode Rear recording 1080P LCD power save 9.66 inch full display screen G-sensor Super Capacitor Touch screen button Real-time view on app Wi-Fi connection IP67 waterproof rear camera Parking mode Back up camera display Time lapses video 01 Rear view mirror... -
Page 3: How To Wire
BASIC OPERATING INSTRUCTIONS HOW TO WIRE 9 10 11 When wiring, please align the two white Follow this direction to insert the SD card. arrows shown in the picture, otherwise, the wire interface may be damaged. 0:00:54 2019.07.17 08:00 Touch area Rear camera NOTED: The touch area of the keys is not on the glass screen, but on the plastic frame below the key icon. - Page 4 NOTE: Always use caution, DO NOT force the mount. We will not be responsible for broken windshields. If you HOW TO INSTALL MIRROR MONITOR are not sure how to remove or re-install the mirror seek trained, qualified help. Remove the original mirror Different cars have different brackets.
-
Page 5: Menu Settings
MENU SETTINGS 2019.12.03 Exposure Stop recording, tap the icon “ ” in the main interface to proceed to the menu settings. Video Time Lapse 15:30 Timelapse Rec Time 2019.12.03 Movie Mode FHD 30fps HD 30fps Protect Level Movie Clip Time 15:30 Night Mode Sound Record... - Page 6 2019.12.03 2019.12.03 Parking Monitoring Flicker 50 Hz 60 Hz LCD Power Save 15:30 Clock Settings 15:30 Language Wifi ON/OFF Volume Format SD-Card Flicker: Can set “50Hz / 60Hz”. Parking Monitoring: Can set “Off /On”. Each country has different supply frequency due to geographical reason. Standard frequency of dash camera lens is constant 50Hz. When this function is turned on, when the recorder is shaken when it is turned off, it will start the machine to record for 30 seconds and When the supply frequency inconsistent with frequency standard the image on the device will appear joggling phenomenon.
- Page 7 PLAYBACK [1/18] [00:03:00] 2019.12.05 FILE191205-131524-000365R Stop recording, tap the icon “ ” in the main interface to proceed to the playback interface. There are 6 sub-menus. FILE191205-132138-000366R 15:30 They are: 1. Front-view normal video; 2. Rear-view normal video; 3. Front-view locked video; 4. Rear-view locked FILE191205-151022-000367R video;...
- Page 8 3. Enter mobile phone interface, turn on Wi-Fi and MOBILE PHONE APP CONNECTION and OPERATION 5. In Figure 4, click the “ ” icon, the phone and connect Wi-Fi ID, enter initial password: 12345678, rearview mirror are successfully connected, as shown Built- in WiFi module system allows to connect mobile 3.
- Page 9 6. Once connected, user can check the recording video and operate accordingly. Click “ ” to enter the list of recorded videos, Press and hold the file thumbnail to select the file, download the video to the local, delete videos in batches, etc. See the figure below. Disconnect Setting Recorded files...
