Instructions for commissioning and operating
When delivered, the radio remote control and the supplied control unit are already connected to
each other. The teaching of further control units is described under point 3.

1. Radio remote control

On / Off button
cold white
Lock remote control:
Press the brightness and
zone buttons simultaneously
for 5 seconds.
After that, only the on / off
function is active.
Radio remote control

2. Preparation of the radio remote control

(1) Unpack the radio remote control
(2) Open the cover on the back of the radio remote control and remove the insulation strip from
the battery compartment. Then close the lid again.
(3) Attach the magnetic holder to the desired location using the double-sided adhesive tape
supplied. Alternatively, the two screws can also be used.
Operating instructions Starterset Z LED 60 Set
(TNR: 33700066 / 33700067)
the adjustable LED lights
brighter
warm white
Zone buttons
1-6
Zone buttons 1-6
Lock remote control:
cw and zone buttons press
simultaneously for 5 seconds.
Insulation strips
Control unit
Teach button
converter
Power cord
Status 19.01.2021
GERA Leuchten GmbH
cover
9-way distributor
Max. 60 Watts
Max. 36 Watts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Starterset Z LED 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for GERA Starterset Z LED 60

  • Page 1 Then close the lid again. (3) Attach the magnetic holder to the desired location using the double-sided adhesive tape supplied. Alternatively, the two screws can also be used. Operating instructions Starterset Z LED 60 Set Status 19.01.2021 (TNR: 33700066 / 33700067)
  • Page 2 / off. Repeat the process to teach in additional devices. IMPORTANT! After each teach-in process, you should wait 60 seconds before teaching in further devices. Operating instructions Starterset Z LED 60 Set Status 19.01.2021 (TNR: 33700066 / 33700067)
  • Page 3 You can change the settings by briefly pressing a button. You can also press and hold the button for a quick change. Operating instructions Starterset Z LED 60 Set Status 19.01.2021 (TNR: 33700066 / 33700067)
  • Page 4 Remote control is locked. Unlock remote control: except on / off function. cw and zone buttons at the same time Press for 5 seconds. Operating instructions Starterset Z LED 60 Set Status 19.01.2021 (TNR: 33700066 / 33700067) GERA Leuchten GmbH...
  • Page 5 (4) The connected lighting unit flashes 5 times and then lights up continuously. the device appears in the user interface (APP) of the Zigbee Hub. Operating instructions Starterset Z LED 60 Set Status 19.01.2021 (TNR: 33700066 / 33700067)
  • Page 6 Control unit is already connected to a Reset the device to factory settings remote control (see point 7.1) After that, you can connect it to the remote control again. Operating instructions Starterset Z LED 60 Set Status 19.01.2021 (TNR: 33700066 / 33700067) GERA Leuchten GmbH...
