PowerStroke PS21ESLM Quick Reference Manual

WARNING:
This Quick Reference Guide is not a substitute for reading the operator's manual. To reduce the risk of injury or death, user must read and understand operator's manual before using this product. All page references refer to the operator's manual.
FIRST TIME ASSEMBLY
1
Unfold and adjust the handle assembly (see page 7).
If side discharging is desired along with mulching, install side discharge
2
deflector (see page 8).
1
2
3
PS21ESLM QUICK REFERENCE GUIDE
If rear bagging is desired instead, remove pre-installed mulching plug and
3
install grass catcher (see page 8).
4
Connect the battery (see page 8).
5
Add entire bottle of lubricant provided (see page 9).
Set unit on flat surface so engine is level. Remove dipstick,
wipe clean, put back in hole (but don't screw in) and check
lubricant level.
SETTING THE BLADE HEIGHT
1
Set the blade height to the position best suited for your lawn (see page 8).
OPERATING THE MOWER
1
Add fuel (see page 10).
NOTICE:
Do not use E15 or E85 fuel in this product. It is a violation
of federal law and will damage the unit and void your war-
ranty. Only use unleaded gasoline containing up to 10%
ethanol.
This is a 4-cycle engine. Do not mix fuel and lubricant
together.
Insert the start key, open the fuel valve, then pull the start bail/operator
2
presence control toward the handle and hold. Turn the start key to start
the mower using the electric start feature or pull the starter grip and rope
until the engine runs. (See page 10)
To use the self-propel drive, pull the drive bail toward the handle to engage
3
the drive transmission (see page 10).
4
To stop the mower, release both bails (see page 10).
Make the most of your purchase! Go to www.powerstroketools.com
and register your new tool online. For questions about operating
or maintaining your product, please call 1-877-617-4050.
CUSTOMER SERVICE
Monday – Friday 8am-8pm ET /
Saturday & Sunday 9am-6pm ET
Translation Available in Over 200 Languages
10-15-15 (REV:02)
991000701
