Dimensions
Distribution:
PureLink GmbH
Sheet Metal Extension Bracket
Thank you for purchasing a Grandview projection screen.
Before use, please read instructions carefully.
After installation, store instructions for future reference.
To assure safety, please make sure the wall to be installed on
Caution:
can bear a weight twice heavy as the weight of the screen.
Available from B2B Online Portal
Advertisement
Table of Contents
Summary of Contents for Grandview 6939982391070
- Page 1 Dimensions Installation Guide for Sheet Metal Extension Bracket Thank you for purchasing a Grandview projection screen. Before use, please read instructions carefully. After installation, store instructions for future reference. To assure safety, please make sure the wall to be installed on Caution: can bear a weight twice heavy as the weight of the screen.
- Page 2 Installation Kit Installation Guide 4. Install the extension bracket to the wall and make sure it is firm enough, refer Horizontal & vertical Inclined bar(2pcs) 5x40mm self-tapping screws to diagram 4 left side. bar joint(2 sets) and swell plastic button(4sets) Install the M5x38mm screw on the horizontal bar, fasten all the screws, refer to diagram 4 right side.
