CAUITON: Make sure you know the max. weight capacity of your mounting solution before attaching the Tablet Cradle and your tablet. Include the weight of
your monitor, tablet and the Tablet Cradle: 1.25lbs (0.57kg) when fi guring mounted weight on your mounting solution. Failure to follow this Caution may lead to
equipment damage and/or personal injury.
A
1x
1
= 1.25 lbs (0.57 kg)
B
C
1x
2x
M4 x 14mm
2x
M4 x 8mm
Tablet Cradle
(200-250 mm)
D
M3 x 10mm
1x
1x
M4 x 10mm
1x
ASSEMBLY INSTRUCTIONS
< 2.5 lbs
(1 kg)
5.5" - 8"
(140-200 mm)
8" - 9.75"
< 0.75"
(19 mm)
1 of 6
Advertisement
Summary of Contents for Ergotron Tablet Cradle
- Page 1 CAUITON: Make sure you know the max. weight capacity of your mounting solution before attaching the Tablet Cradle and your tablet. Include the weight of your monitor, tablet and the Tablet Cradle: 1.25lbs (0.57kg) when fi guring mounted weight on your mounting solution. Failure to follow this Caution may lead to equipment damage and/or personal injury.
- Page 2 M3 x 10mm M4 x 10mm 2 of 6...
- Page 3 3 of 6...
- Page 4 M4 x 14mm 5.5" - 8" 8" - 9.75" < 0.75" (19 mm) (140-200 mm) (200-250 mm) M4 x 8mm 4 of 6...
- Page 5 CAUITON: If mounting just the Tablet Cradle Interface, make sure you know the max. weight capacity of your mounting solution. Include the weight of your tablet and the Tablet Cradle Interface: 0.55lbs (0.25kg) when fi guring t otal weight on your mounting solution. DO NOT attach the Tablet Cradle Extension to any other products other than the Tablet Cradle Interface. Failure to follow this Caution may lead to equipment damage and/or personal injury.
- Page 6 6 of 6 Check out the collection of computers & hardware we offer.
