Johnson Controls tyco CC3 Manual page 6

TFP633
Page 6 of 8
FRAME ARMS OF SPRINKLER
MUST BE INSTALLED
IN-LINE WITH PIPE RUN
4" (102 mm)
MAXIMUM
1-1/2" (38 mm)
MINIMUM
FRAME ARMS OF SPRINKLER
MUST BE INSTALLED
IN-LINE WITH PIPE RUN
2" (51 mm)
MAXIMUM
1-1/2" (38 mm)
MINIMUM
COMPOSITE
WOOD JOISTS
CEILING
FRAMING
NON-COMBUSTIBLE INSULATION-FILLED UPPER DECK
SOLID WOOD OR COMPOSITE WOOD JOIST CONSTRUCTION
CROSS SECTION ELEVATION VIEW
MODEL CC3
SPRINKLER
CEILING
FRAMING
OBSTRUCTED WOOD TRUSS CONSTRUCTION
CROSS SECTION ELEVATION VIEW
UPPER NON-COMBUSTIBLE
DECK INSULATION
MODEL CC3 2x FLOOR SOLID
SPRINKLER WOOD JOISTS
CEILING
FIGURE 6
STEEL PIPE
UPPER TOP CHORD GREATER
DECK THAN 4" (102 mm) IN DEPTH
CEILING
FIGURE 7
STEEL PIPE
84" (2134 mm)
MAXIMUM
60" (1524 mm)
MAXIMUM
6" (152 mm)
MINIMUM
84" (2134 mm)
MAXIMUM
60" (1524 mm)
MAXIMUM
6" (152 mm)
MINIMUM
