POLARA iNS2 Manual

Accessible pedestrian signal push button station
Hide thumbs Also See for iNS2:
Table of Contents

Advertisement

Quick Links

iNS/iDS 2-Wire System Manual
350-077
Rev. D - 1/20/2021
Polara
iNS/iDS 2-Wire System Manual
Note: Model iDS2 is equivalent to iNS2 in all aspects, but includes
iDetect functionality. Anywhere iNS2 is used in this manual,
applies to iDS2 also.
For use with iCCU-S2 and iCCU-C2
350-077 Rev. D
1/20/2021
Page 1 of 107

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iNS2 and is the answer not in the manual?

Questions and answers

Related Manuals for POLARA iNS2

Summary of Contents for POLARA iNS2

  • Page 1 Rev. D - 1/20/2021 Polara iNS/iDS 2-Wire System Manual Note: Model iDS2 is equivalent to iNS2 in all aspects, but includes iDetect functionality. Anywhere iNS2 is used in this manual, applies to iDS2 also. For use with iCCU-S2 and iCCU-C2 350-077 Rev.

  • Page 2: Table Of Contents

    Central Control Unit Installation Procedure iNS2 PBS Installation Procedure 3.6.1 Connecting an External Button Technical Support Contact Using the Polara Field Service App for iOS to Change iCCU-X2 Settings Wi-Fi Connection Changing the Password Advanced Communications Settings Channel and Phase Setup 5.4.1...
  • Page 3 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Using the Polara Field Service App for iOS to Change iNS2 PBS Settings Bluetooth Connection PBS Configuration Options Button Counters Wireless Sync iDetect Settings PedApp Settings Quiet Time Viewing iNS2 Button Information Preparing Audio Files 6.9.1...
  • Page 4 12.6 Calendar Events 12.7 Wireless Sync 12.8 iDetect Settings 12.9 Diagnostics Using the Polara Field Service App for PC to Upload Audio Files 13.1 Preparing Audio Files 13.2 Uploading Audio Files 13.3 Extract Audio Files Firmware Update Keeping Up to Date Descriptions of Pilot LED Operation 16.1...
  • Page 5 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 17.3.1 Cancel on Clearance 17.3.2 Clearance Mode Sound 17.3.3 Clearance Tone Pause 17.4 Don’t Walk Interval Settings 17.4.1 Locate Sound 17.4.2 Locate Tone Time 17.4.3 Wait Message 17.4.4 Direction Message 17.4.5 Information Message 17.4.6 Push Confirm Message 17.5 Other Settings...

  • Page 6: Safety Information

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Safety Information Caution! The equipment covered in this manual must be installed and operated as specified in this manual. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.

  • Page 7: Ins2 System Description

    2.1 iNS2 Accessible Pedestrian Signal Push Button Station (PBS) The iNS2 is an Accessible Pedestrian Signal Push Button Station (PBS). These PBSs are typically used in pairs, mounted on poles at each end of a pedestrian crosswalk. Its purpose is to transmit a request for a Walk Signal to a Traffic Controller by pressing its button, then to provide audible and vibro-tactile feedback to the pedestrian, indicating the current status of the pedestrian signal.

  • Page 8: Iccu-S2 Intelligent Central Control Unit For Shelf

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Push button Operating Force Range: 1 to 3 lbs. Maximum Audio Output Level: 100 dBA @ 1 meter Dimensions W x D x H: 129 x 69 x 355 (mm - Reference Only) Weight: 4.4 lbs.

  • Page 9: Iccu-C2 Intelligent Central Control Unit Plug-In Card

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 2.3 iCCU-C2 Intelligent Central Control Unit Plug-in Card 2.3.1 Technical Specifications Input Voltage / Current: 24VDC Nominal / 0.5A PBS Output: Connects to existing push button wiring via card edge – replaces two Type 242 isolators Ped Walk / Don’t Walk Inputs: 24 volt logic, active low, via front panel 15 pin connector Ped Outputs: Optically Isolated 36 Volts AC/DC peak, 300mA Solid State Fused Contact Closure Communication: Ethernet, Wi-Fi (IEEE 802.11b/g/n)

  • Page 10: System Installation

    3.1 iNS2 System Operation During Intersection Flash The iNS2 APS buttons are designed to cease normal function in the event of intersection flash. When pedestrian walk and don’t walk signals are absent, the iCCU-X2 firmware suspends normal communication to disable the buttons. For added safety, we recommend the AC input power for the system be connected such that power to the buttons is removed during intersection flash.

  • Page 11: Iccu-S2 With Ins2 Pbs - Wiring Diagrams

    2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.2 iCCU-S2 with iNS2 PBS – Wiring Diagrams 3.2.1 Typical NEMA TS2 Type 1 Cabinet Connection with Interconnect Board – BIU Mode Page 11 of 107...

  • Page 12: Typical Nema Ts2 Type 1 Cabinet Connection With Interconnect Board - Sdlc Hybrid Mode

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.2.2 Typical NEMA TS2 Type 1 Cabinet Connection with Interconnect Board – SDLC Hybrid Mode Page 12 of 107...

  • Page 13: Typical Nema Ts1 Cabinet Connection With Interconnect Board - Hard-Wired Mode

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.2.3 Typical NEMA TS1 Cabinet Connection with Interconnect Board – Hard-Wired Mode Page 13 of 107...

  • Page 14: Control Unit Cabinet Wiring (Optional Wiring For Preemption And General Purpose Inputs)

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.2.4 Control Unit Cabinet Wiring (Optional Wiring for Preemption and General Purpose Inputs) Page 14 of 107...

  • Page 15: Iccu-C2 With Ins2 Pbs - Wiring Diagrams

    2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.3 iCCU-C2 with iNS2 PBS – Wiring Diagrams 3.3.1 Typical 332 or Similar Cabinet Connection #1 – Preferred Page 15 of 107...

  • Page 16: Typical 332 Or Similar Cabinet Connection #1 - Alternate

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.3.2 Typical 332 or Similar Cabinet Connection #1 – Alternate Page 16 of 107...

  • Page 17: Typical 332 Or Similar Cabinet Connection #2

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.3.3 Typical 332 or Similar Cabinet Connection #2 Page 17 of 107...

  • Page 18: Iccu-S2 Central Control Unit Installation Procedure

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 3.4 iCCU-S2 Central Control Unit Installation Procedure Note, all wiring must be completed before applying power to the iCCU-S2. It is required to connect the LOGIC GROUND wire from CABLE-C-LG or CABLE-C to the cabinet’s LOGIC GROUND even when SDLC will not be used.

  • Page 19: Preemption And General Purpose Inputs (Diagram Section 3.2.4)

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 colors are a stripe on a white background. These wires typically connect to phases 2, 4, 6, and 8 respectively, but each may be assigned to any phase during configuration, so the connections can be to any phase as desired. This cable connects to the connector on the iCCU-S2 labeled “C/To Ped Inputs”.
  • Page 20 Input File, replacing two Type 242 isolators in locations I-12 and I-13 (with the card edge plugged into I-13). Connect the C4 adapter cable to the iCCU-C2 front panel. Complete the installation with the iNS2 PBS mounting and wiring per the next section.
  • Page 21 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Mounted Interconnect Board Power Cord Connection Installed C4 Cable Adapter Installed iCCU-C2 with optional Ethernet Page 21 of 107...

  • Page 22: Ins2 Pbs Installation Procedure

    Android device or PC with iN-DGL. Your device must have iOS version 9.0 or higher or Android 5.0 (Lollipop) or higher. The Polara FS App will need to be installed on your device. It is available on the Apple App Store and the Google Play Store. The Intelligent Config PC App is available at www.polara.com.
  • Page 23 Re-install EARTH GND (ground) connection screw to location between terminal blocks. Connect the two wires from the traffic signal cabinet to the terminals of the larger black terminal block labeled BUTTON/PLC. Wire polarity is not important. Recheck tightness of all connections. Pole-mounted iNS2 PBS Page 23 of 107...

  • Page 24: Connecting An External Button

    Skip to section 6 for instructions on connecting via Bluetooth. Upon first run of the Polara FS app, you will be prompted with two iOS dialogs for granting access. The Polara FS app needs access to iOS Location Services in order to gain access to the WiFi network information allowing the app to detect and connect to iCCU units.

  • Page 25: Wi-Fi Connection

    The display should confirm that Wi-Fi is enabled. Go to Settings on your iOS device and tap Wi-Fi. Locate the Polara iCCU-X2 in the list of available devices. Tap the name to select (SSID indicated on LCD of iCCU-X2), then enter the Wi-Fi password as requested.
  • Page 26 Note: If the password is unknown, the password can be reset to factory default by tapping the Reset button on the password prompt dialog. Call Polara at the number listed on the reset dialog and request a password reset verification code. Enter the new...

  • Page 27: Changing The Password

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 5.2 Changing the Password To change the password, choose iCCU Configuration from the Main Menu and then choose Password from the CCU Config Menu. Enter in the appropriate fields, the current password, new password, and retype new password. Then choose Save from the upper-right area of the screen.

  • Page 28: Advanced Communications Settings

    A, B, or C. During initial startup, the iCCU-X2 will operate in Channel B by default. The first time an iNS2 PBS powers up, it will auto- calibrate by finding the communication channel the iCCU-X2 is operating on, and then adjust its signal until it establishes communication with the iCCU-X2.

  • Page 29: Channel And Phase Setup

    C4 connection, select the Advanced 4-Chan Settings option and tap the Advanced Options button to change the configuration of the Load Switch and Ped Call Assignments. Proceed to Assigning iNS2 PBSs to Phases in section 5.5. Page 29 of 107...
  • Page 30 Tap the save button in the upper right corner to store the setting, then tap the back button to return to the previous screen and proceed to Assigning iNS2 PBSs to Phases in section 5.5. If your setup differs from one of these options, select either of the SDLC...

  • Page 31: View Interval Status

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 listed, or more than 4 pedestrian phases are needed, select the “Adv. Load Switch Settings and assign the appropriate phases to load switch channels. Configure the Traffic Controller to enable the detector BIU number selected. Program the Traffic Controller to remap the detector inputs to Ped inputs according to the table above.

  • Page 32: Advanced Iccu-X2 Settings - Channel Assignment

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 5.4.3 Advanced iCCU-X2 Settings – Channel Assignment Associate phases with the SDLC PED channels that should be monitored. Refer to the Traffic Controller’s user manual and configuration to determine which SDLC channels correspond to which Ped phases. To associate an SDLC PED channel with a phase, choose the channel from the selector on the bottom-left of the screen and choose a phase from the selector from the bottom-right of the screen.

  • Page 33: Advanced Iccu-X2 Settings - Ped Call Connection Setup

    Cabinet Ped Interface selection screen. Tap the left arrow in the upper left corner to return to the previous screen. With the Channel/Phase assignments configured, iNS2 PBSs can now be assigned to phases. Page 33 of 107...

  • Page 34: Assigning Ins2 Pbss To Phases

    5.5 Assigning iNS2 PBSs to Phases Following the Cabinet Ped Interface setup process, each connected iNS2 PBS must be named and be assigned a phase. At this point, all buttons need to have been installed and powered. From the iCCU Configuration menu, choose Phase Setup.

  • Page 35: Setting The Iccu-X2 Time/Date, Sntp & Dst Settings

    Note that setting the time on the iCCU-X2 also sends the updated time to any iNS2 PBSs currently connected to the network. Also, when new iNS2 units establish a connection with the iCCU-X2, the time is synchronized with the iNS2 units automatically.

  • Page 36: Setting Ethernet Configuration

    The SNMP MIB for the iCCU-X2 is available for download on Polara.com website under the iCCU-X2/iNS2 Installation downloads section.

  • Page 37: General Purpose Input And Preemption (Iccu-S2 Only)

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 5.8 General Purpose Input and Preemption (iCCU-S2 Only) From the iCCU Configuration menu, select GPIn/Preemption. For each General Purpose Input to be used, select the desired function, the effective channels, and the desired volume. Preemption may be configured in the same way.

  • Page 38: Viewing Iccu-X2 Information

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 5.9 Viewing iCCU-X2 Information From the main menu, select iCCU Configuration, then select Info/Diagnostics. The Info screen displays basic information about the iCCU-X2 including its Serial Number and Firmware Version. If you tap on the button for “View All iCCU Information”...

  • Page 39: Using The Polara Field Service App For Ios To Change Ins2 Pbs Settings

    Before starting the Polara Field Service App, make sure your iOS device has Bluetooth set to ON in Settings. Then, start the app. Tap the refresh symbol at the top right. This will display a list of all available devices. The symbol to the left of each device name indicates the type of wireless connection.

  • Page 40: Pbs Configuration Options

    6.2 PBS Configuration Options From the Polara App main menu, select PBS Configuration, then select Settings. This presents an extensive list of operational settings that may be adjusted according to desired operation. You can swipe the list up and down to find the setting to be changed.
  • Page 41 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Options for selecting sounds have a button with a speaker symbol. To listen to sounds, use the slider to Enable Audio Playback or press the icon next to the sound you wish to hear. For safety, the unit will need to go into Maintenance Mode and the LED will perform a three-flash pattern.
  • Page 42 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 The currently displayed settings may be saved to a file and recalled for later uploading to other PBSs. Tap “Save As File” from the options menu and enter a file name to create a file. Tap “Load From File”...

  • Page 43: Button Counters

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 6.3 Button Counters From the Main Menu, select PBS Configuration, then select Counters. Each PBS keeps a count of events that have occurred in the button from the date of manufacture. These numbers act as a kind of odometer for the unit and cannot be reset.

  • Page 44: Wireless Sync

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 6.4 Wireless Sync Considering a scenario where a crossing on one side of the intersection does not have button wires, but does have a ped head, an iN2 unit cannot be placed on that corner, so an iN3 unit must be used. In this instance, there is no method of communicating a button press or ped call through a wired connection.

  • Page 45: Idetect Settings

    APS and is an added feature in all iDS APS buttons. There are many technologies that can facilitate touchless actuation, but each has strengths and weaknesses. Polara has chosen to use radar technology because of its performance, reliability, and resistance to vandalism. The intent of iDetect is to provide touchless actuation within a sensing range of 2”...

  • Page 46: Pedapp Settings

    6.6 PedApp Settings The iNS can be configured to work with the Polara PedApp, which is available for iOS via the App Store and for Android via Google Play. When the buttons at an intersection are configured for use with the PedApp, they allow pedestrians to place calls for the desired crossing, without touching the buttons.

  • Page 47: Quiet Time

    In this scenario, it may be useful to have the iNS2 PBS set loud enough to be heard over traffic during the day, but be nearly inaudible in the evening hours, as not to disturb residents living nearby.

  • Page 48: Viewing Ins2 Button Information

    Note: This information is also prepended to the health log when exported to file. Tap the down arrow at the top right of the screen to select additional iNS2 units in the intersection to view their information remotely.

  • Page 49: Preparing Audio Files

    OneDrive, and others. Then use the iOS “Files” app to copy the files into the Polara FS audio directory or access the Share feature of the file to open the file in Polara FS. This method can be used to import large groups of messages into the Polara FS app.

  • Page 50: Download Audio Files From Polara.com

    The following procedure is demonstrated using iOS 13. Other versions of iOS may behave differently. Open the Safari app and browse to Polara.com, then zoom in and tap the Audio Library link on the top left of the page. Search for the audio message(s) of your chose. Then zoom in and tap the Download button. A confirmation box will appear.
  • Page 51 Tap the folder icon at the bottom center of the screen. This will bring up another browser which allows you to select the destination folder for the files. Tap to expand the On My iPhone folder, then select Polara FS and choose the audio folder.

  • Page 52: Sending Audio Files To Inav Device

    To add a new Information Message file, tap on “Information Message”. This displays a list of available voice files loaded into the Polara FS App. Tap on the name of the file you wish to load as the Information Message sound in the PBS. Then tap the Select File button.
  • Page 53 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 As soon as the Select File button is tapped, the file will begin to upload. Once the file has completed uploading, press OK on the dialog box to return to the Audio Update screen. Repeat this process for each file to be uploaded.

  • Page 54: Extract Audio Files

    The same messages that are available to be changed via Audio Update can be extracted from the PBS. This feature requires firmware version v3.199 or greater in the iNx unit. From the Polara App main menu, Tap on “Audio Update” Tap the “Extract” button in the upper right corner of the Audio Update screen.

  • Page 55: Using The Polara Field Service App For Ios To Access The Health Log

    These can be very useful for troubleshooting. Select “Health Log” in the Polara App main menu. The Name / ID of the currently connected device is visible at the top. To read the Health Log from this device tap “Read”. The current log is downloaded and displayed. Swipe the screen to browse through the log.

  • Page 56: Using The Polara Field Service App For Ios For Firmware Updates

    The iOS App also has the ability to connect to polara.com to check for new updates directly from within the App. Your device must be connected to the internet in order to perform the check. While disconnected from any iCCU-X2 or PBS, tap the three dots on the upper left of the connection screen.

  • Page 57: Performing A Firmware Update

    To perform a firmware update, at the Polara App main menu, tap the box for “Firmware Update”. On the firmware update page, you can view the current firmware version on the iCCU-X2 as well as the iNS2 device you are connected to. By tapping on List All Button Versions, a list of all connected iNS2 devices will appear with the firmware versions installed on each device.
  • Page 58 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 To update the firmware of the connected device, tap the Update Firmware button. The list of available firmware update files will appear. Tap the file you wish to upload and tap Select File to begin the firmware update process. When the process is complete, a message is displayed confirming the success.

  • Page 59: Using The Polara Field Service App For Ios To Program Calendar Features

    2-Wire System Manual 350-077 Rev. D - 1/20/2021 Using the Polara Field Service App for iOS to Program Calendar Features The calendar feature can no longer be used via the iOS Application. Due to the complexity of the feature, it must be enabled and configured using the PC application only.

  • Page 60: Using Polara Field Service App For Pc To Change Iccu-X2 Settings

    10.1 Download Polara Field Service App for PC (Intelligent Config) Application The Intelligent Config application is available for download from www.polara.com. 10.2 iN-DGL (BLE Dongle) The Intelligent Config application requires the use of the Polara iN-DGL (BLE Dongle) to communicate with the Polara iNS2 PBS. 10.3 Application Installation Your computer must be running Windows 7, 8, 8.1, or Windows 10.

  • Page 61: Auto-Login

    Rev. D - 1/20/2021 Go to the Wi-Fi connection software on your PC to search for available Wi-Fi networks within range. Locate the Polara iCCU-X2 in the list of available devices. Select the iCCU-X2 device (SSID indicated on LCD of iCCU-X2), then enter the Wi-Fi password as requested.

  • Page 62: Initial System Setup

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.4.2 Initial System Setup Once you have successfully logged in, you will then be presented with the Intersection Status screen. If the system has not yet been configured with PBSs, the Intersection will be blank as pictured below. Begin the setup process by selecting a Cabinet Ped Interface (10.7) and follow that up with assigning Phases to each PBS in Phase Setup (10.8).

  • Page 63: Changing The Password

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.5 Changing the Password To change the password, click on the Password menu item under the iCCU Configuration category. Enter in the appropriate fields; the current password, new password, and retype new password. Then click the Change Password button.

  • Page 64: Advanced Communications Settings

    A, B or C. During initial startup, the iCCU-X2 will operate in Channel B by default. The first time an iNS2 PBS powers up, it will auto- calibrate by finding the communication channel the iCCU-X2 is operating on, and then adjust its signal until it establishes communication with the iCCU-X2.

  • Page 65: Channel And Phase Setup

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.7 Channel and Phase Setup The iCCU-S2 can obtain Ped interval information by monitoring the outputs of the load switches (via the Cable A harness) or by monitoring the SDLC bus. The iCCU-C2 obtains Ped interval information via the C4 cable adapter and has automatic source selection.
  • Page 66 13 through 16 for PED load switches. Select the appropriate SDLC option based on the load switch setup in your cabinet. Click the Save Settings button, then proceed to Assigning iNS2 PBSs to Phases in section 10.8. If your setup differs from one of the default SDLC options, choose the Advanced Load Switch Channel Settings option, click Save Settings, and then modify the setup for your specific needs.
  • Page 67 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 If using an SDLC cable in BIU Mode (no Cable A and no Cable C) : The NEMA TS 2 2003 specification defines SDLC command and response frames for 4 detector BIUs. The iCCU-S2 can be configured to operate as any one of these four BIUs for the purpose of placing pedestrian calls to the Traffic Controller.
  • Page 68 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Each detector BIU communicates call status for up to 16 detector inputs. When configured as a detector BIU, the iCCU-S2 uses the first 8 detectors. See the table below for detector input numbers and how they need to map to pedestrian inputs.

  • Page 69: View Interval Status

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.7.2 View Interval Status While selecting the Cabinet Ped Interface type, you can view the status of the interval information coming into the iCCU-X2 by clicking on the View Interval Status button. In 4-Channel mode, the interval information will be displayed for the 4 channels wired to the load switches (or C4 connector for iCCU-C2).

  • Page 70: Assigning Ins2 Pbss To Phases

    10.8 Assigning iNS2 PBSs to Phases Following the Channel Setup process, each connected iNS2 PBS must be named and be assigned a phase. At this point, all buttons need to have been installed and powered. Click the Phase Setup menu item. It is suggested to name the PBS with something that identifies the installed location and the phase (must be 4 to 15 characters).

  • Page 71: Intersection Status

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.9 Intersection Status Clicking on the Status menu item will show the full intersection diagram with each phase identified and the attached buttons for each phase. The Ped Call indicator under the Ped Head becomes highlighted in red when a ped call has been latched for that phase.

  • Page 72: Health Log

    For help with a particular issue, or a message of concern, email the log to support@polara.com. Note: You must tap the Read button prior to exporting the health log, otherwise the health log export will only include device information and not the entire health log of the unit.

  • Page 73: Setting The Iccu-X2 Time/Date, Sntp & Dst Settings

    Manually Set Time option and select the desired time, then click Set iCCU Time. Note that this operation also sends the time to any iNS2 PBSs currently connected to the network. The iCCU-X2 has the ability to connect to a network time server to periodically obtain the current time. The time server cannot be a device on the open internet but must be a local server connected to the same network as the iCCU-X2.

  • Page 74: General Purpose Input And Pre-Emption (Iccu-S2 Only)

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Click the Save Settings button to save the SNTP and DST changes. 10.12 General Purpose Input and Pre-emption (iCCU-S2 only) Click the GPIn/Preemption menu item from the iCCU Configuration category. For each General Purpose Input to be used, select the desired function, the effective channels, and the desired volume. Preemption may be configured in the same way.

  • Page 75: Information

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.13 Information Click on the Information menu item under the iCCU Configuration category to view the iCCU-X2’s Serial Number, Wi-Fi SSID and Firmware Version. You can also click the Reset iCCU button to cause the iCCU-X2 to restart. If you click on the “View All iCCU Information”...

  • Page 76: Ped Isolator

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.14 Ped Isolator Click on the Ped Isolator menu item under the iCCU Configuration category. From this screen, single calls can be placed on individual phases by clicking the Place Call button. Also, calls can be locked in for any phase. As long as the lock call switch is activated, the call will remain locked, even after disconnecting from the Wi-Fi connection.

  • Page 77: Setting Ethernet Configuration

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 10.15 Setting Ethernet Configuration Click the Network menu item from the iCCU Configuration category. Enter the desired IP, Port, Subnet Mask, and Gateway. Click the Save Changes button. Page 77 of 107...

  • Page 78: Setting Snmp Configuration

    Once you have your network management system installed, you can configure it to send you automatic email notifications any time a trap is received. The SNMP MIB for the iCCU-X2 is available for download on Polara.com website under the iCCU-X2/iNS2 Installation downloads section.

  • Page 79: Connecting To The Iccu-X2 Via Ethernet

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Connecting to the iCCU-X2 via Ethernet 11.1 Direct Connection from PC to iCCU-X2 The IP address of the iCCU-X2 has been preset from the factory to 192.168.1.218. The Ethernet port on the iCCU-X2 is auto-sensing, which means that the use of a crossover-cable is not necessary, a standard Ethernet cable from your PC or Laptop directly to the iCCU-X2 can be used.

  • Page 80: Iccu-X2 Wired Connection

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 11.2 iCCU-X2 Wired Connection The iCCU-X2 can be connected via Ethernet connection to an internal network. Any Ethernet connection to the iCCU-X2 should not be open to the internet, but should be restricted to the department’s intranet. An IP address should be assigned by the IT department prior to connection so proper setup can be performed.

  • Page 81: Using Polara Field Service App For Pc To Change Pbs Settings

    Using Polara Field Service App for PC to Change PBS Settings 12.1 Running the Application Make sure you have a Polara iN-DGL BLE Dongle connected to a USB port on your computer. Click on the Intelligent Config icon in the Start Menu to run the application.

  • Page 82: Bluetooth Connection

    Type in the password (Factory default is 1234) and click ‘Login’. You may click ‘Disconnect’ to cancel or click ‘Reset Password’ if the password is unknown. You will be prompted to call Polara for assistance in resetting the password. After login, the Status page will appear.

  • Page 83: Status Page

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 12.3 Status Page The status page provides information about the connected PBS. The panel on the left contains a menu of pages containing the various setup and maintenance functions. Online help is available on each page by hovering the mouse pointer over a function button.

  • Page 84: Settings

    Press Yes on the confirmation dialog box to enable Maintenance Mode. In this mode, the unit’s main button will not operate or respond to interval changes so a pedestrian cannot use it. This will only be done on the iNS2 unit you are directly connected to, so a remote If you tap on the link for “View All iCCU Information”...

  • Page 85: Adjusting Push Force

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 The configuration parameters can be saved using the File Save button. This will allow you to save the parameters to a file on your computer. They can later be recalled using the File Open button. Note: The configuration files only save the PBS Settings listed on this screen and do not apply to additional parameters on other screens such as Quiet Time or Network Settings and also do not save audio files.

  • Page 86: Quiet Time

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 12.5 Quiet Time The details of the feature’s operation is such that if the current time of day falls between the selected start and end time of the Quiet Time period, then all Minimum and Maximum volume settings will be reduced by the specified reduction amount. Note: The “Minimum”...

  • Page 87: Calendar Events

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 12.6 Calendar Events Calendar Events allow the configuration of time-based changes to operating characteristics from four possible configuration sets. This feature enables changes to the settings based on the time of day, day of week, or specific day of the year.
  • Page 88 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Step 1: In the Settings page, write the low volumes in Config Set 1. Make sure the appropriate settings are set to all buttons in the intersection. The Write To All button allows you to update all buttons in the intersection with the same settings at the same time.
  • Page 89 iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Step 3: In the Calendar Events page, click the Add button. A dialog box will appear which will allow you to add a new event. Keep the Daily option selected, then choose Config Set 1 as the Base Config Set.

  • Page 90: Wireless Sync

    Considering a scenario where a crossing on one side of the intersection does not have button wires, but does have a ped head, an iNS2 unit cannot be placed on that corner, so an iNS3 unit must be used. In this instance, there is no method of communicating a button press or ped call through a wired connection.

  • Page 91: Idetect Settings

    APS and is an added feature in all iDS APS buttons. There are many technologies that can facilitate touchless actuation, but each has strengths and weaknesses. Polara has chosen to use radar technology because of its performance, reliability, and resistance to vandalism.

  • Page 92: Diagnostics

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 12.9 Diagnostics Helps to determine if there is a problem with the PBS hardware, and allows a reboot. If you click on the “View All Unit Information” button, you will be presented with a dialog which includes all factory and user-settable settings. This information is also prepended to the health log when exported to file.

  • Page 93: Using The Polara Field Service App For Pc To Upload Audio Files

    13.1 Preparing Audio Files The audio files which are played in the iNav units are encoded using the open-source Ogg Vorbis codec. Polara provides professionally recorded custom audio files on the website. Go to Polara.com and click on the Audio Library option. You can search for audio files which have already been recorded if the streets on the desired intersection are common.

  • Page 94: Uploading Audio Files

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 13.2 Uploading Audio Files From the left menu, click Audio Update. The Audio Update page allows you to upload audio files to provide new sounds. From the Sound dropdown, choose the sound slot to update, for example the “Information Message”...

  • Page 95: Extract Audio Files

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 13.3 Extract Audio Files The same messages that are available to be changed via Audio Update can be extracted from the PBS. This feature requires firmware version v3.199 or greater in the iNx unit. In the Audio Update screen, click the “Extract”...

  • Page 96: Firmware Update

    From the left menu, click Firmware Update. This page allows you to upload the latest firmware to the iNS2 PBS. The Intelligent Config App is bundled with a firmware file that represents the most up to date version available at the time the App was released. To use this version, select “Use stored firmware file”.

  • Page 97: Keeping Up To Date

    Keeping Up to Date The Intelligent Config application is able to connect to the internet to check for new versions of itself and for new versions of the iNS2 firmware. Make sure your computer has internet access in order to check for updates.

  • Page 98: Descriptions Of Pilot Led Operation

    If the unit is connected to an iCCU-X2, the iNS2 will perform the 2-flash pattern while the unit searches for a connection to the iCCU-X2 via PLC. It will begin the 2-flash pattern as it searches for an iCCU-X2 using the PLC interface. If the...

  • Page 99: No Pedestrian Interval Detected

    This indicates that the PBS is not receiving a valid Ped Interval even though it has PLC communication with the iCCU-X2. This will happen when the iNS2 is not assigned to a phase or if it is assigned to a phase and it is receiving an Off Interval from the iCCU-X2.

  • Page 100: Configuration Settings Details

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 Configuration Settings Details This section will provide details on each of the settings which can be accessed from the PBS Configuration / Settings screens on each application, PC or iOS. Most of the below information is available by tapping or clicking on the information button next to each setting in any application.

  • Page 101: Walk Interval Settings

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 17.2 Walk Interval Settings 17.2.1 Walk Mode Sound This function selects the preferred sound played during the Walk interval. The available options are: None, Cuckoo (N/S), Chirp (E/W), Standard Walk, Custom Walk 1, Custom Walk 2, Custom Walk 3, Walk Sign is On for All Crossings, Rapid Tick 1, Rapid Tick 2, Rapid Tick 3, Canadian Melody, Australian Walk, Walk Sign is On.

  • Page 102: Sound/Vibrate Re-Trigger

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 • 2 Message: The selected walk sound will play two times, or until the Walk interval ends, whichever occurs first. • 3 Messages: The selected walk sound will play three times, or until the Walk interval ends, whichever occurs first. •...

  • Page 103: Clearance Tone Pause

    The Wait Message is available regardless of the Walk Sound Trigger setting. Note: When the iCCU-X2 updates the date/time on the iNS2 units, the timer between sounds resets. Therefore, the duration between these sounds may occasionally shorten.

  • Page 104: Information Message

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 17.4.5 Information Message This option details what notice occurs when the button is held down for the extended push time. This typically allows for a custom message that gives blind pedestrians additional information on the street they are crossing and its cross street. The options noted as ‘with Pulse’...

  • Page 105: Second Language

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 The available options are selected in seconds from 0 to 6 in ½ second increments. Factory Default: 1 second 17.5.4 Second Language This function allows for a Second Language to be played for the information message, walk message and countdown. This language is a custom programmed option.

  • Page 106: External Speaker Option

    iNS/iDS 2-Wire System Manual 350-077 Rev. D - 1/20/2021 17.5.7 External Speaker Option This option is only available on special ordered units with part number suffix –ES and must be specified at time of ordering. When enabled, all walk and clearance sounds emanate from an external speaker and all other sounds emanate from the internal speaker.

  • Page 107: Fail Safety

    2. If an iNS2 is connected to the iCCU but not yet assigned to a phase, the iCCU will place calls on all phases. 3. If an iNS2 is in maintenance mode, a call will be placed on the associated phase. This can be achieved by explicitly placing the button into maintenance mode, enabling audio playback from within the Apps, or performing a firmware update.

This manual is also suitable for:

Ids2

Table of Contents

Save PDF
