- Page 1 Scoreboard displays HF 87 HF 87/1 1 0 % 1 0 0 % Operating and Maintenance Equipment in Instructions accordance with CE directives MS 87/./. R 03/03...
-
Page 2: Table Of Contents
SUMMARY GENERAL WARNING WIRING OF THE DISPLAY HF 87 WIRING OF THE LOAD CELL POWER SUPPLY CONNECTION TEST FUNCTIONS SET – UP N°4 : CALIBRATION OF THE DISPLAY 7 - 8 x Basic calibration menu 8 - 10 x High accuracy calibration menu 11 –... -
Page 3: General Warning
4- Never apply to the Dynasafe® a load or an effort in excess of the working load limit, and never use it for an operation for which it is not intended. 5- TRACTEL SAS declines any responsibility for the consequences of dismantling or altering the machine by any unauthorised person. - Page 4 CONNECTION OF SCOREBOARD DISPLAY HF/87 POWER LIMIT FUSE LO relay (NO) SHUNT HI relay ( NO) Power supply Tare light horn Load cell NO 1 : S-LO intermediary trip point (NO 5 Amp) 0 V : common for tare and memories NO 2 : S-HI safety trip point (NO 5 Amp) IN 1 : tare COM : common...
-
Page 5: Wiring Of The Load Cell
Once the power supply is switched on, the scoreboard displays the model reference (e.g.HF 87/1) for 2 seconds, during which time the alarms are triggered and the safety relays reversed. Then, it displays a value in weight units. This value will only be correct after the system has been calibrated). -
Page 6: Test Functions
TEST FUNCTIONS The scoreboard display is supplied within 4 touch programming keyboard. ž Connect the keyboard to the RS 232 socket on the display. This keyboard allows the following tests to be carried out : Display the signal from the load cell Press the button ... -
Page 7: Set - Up N°4 : Calibration Of The Display
CALIBRATION OF DISPLAY HF 87/1/. AND 87/2/. SET-UP N° 4 (see synoptic page 13) Display installation main steps : 1. Load cell installation and wiring. 2. Display installation and wiring. 3. Display calibration. 4. Safety trip points adjustment. Definitions of the different calibration parameters :... -
Page 8: Basic Calibration Menu
CALIBRATION STEPS Procedure to access to the calibration menus DISPLAY ACTION COMMENT. Display before calibration Hook with no load Press buttons S & E simultaneously for 5 seconds to access the menu of calibration. (5 sec) (auto) Access code CODE (Automatic display) Press buttons arrows UP &... - Page 9 Defines the working load limit of the lifting system. CALI (auto) E.g. 20000 Lbs. Crane capacity. Sheaved 4/1: Cali = 20000 Press E to view this parameter . CALI Use the arrows to correct the value to 20000 × Ø 20000 Press E to confirm.
- Page 10 ( The next functions are not available on display manufactured before 01/01/98 ) Defines the dynamic damper value Sped 2 (auto) Press E to view this parameter . Sped 2 Use the arrows to correct the value witch should be set ×...
- Page 11 HIGH ACCURACY CALIBRATION : SET. L In order to increase the accuracy of the installation it could be appropriated to optimise the linearity of the weighing system by forcing the display to show accurate pre-set points along the scale. Several points (maximum 10) could be forced and thereby optimise the linearity. Those points could be either uniformly spread from the “0”...
- Page 12 Previous conditions at SET.L : Set-Up N° 4 basic functions has been successfully achieved. Remember ! LIN must be disabled.. Equipment required : As many intermediate points load as required accurate preset points. HIGH ACCURACY CALIBRATION : SET. L At each forced point corresponds a well-known load, e.g. if you want to set 3 forced points, you will need 3 well-known loads identified as P1 ( point 1) for the first load, P2 ( point 2) for the second load and so on…...
-
Page 13: High Accuracy Calibration Menu
SYNOPTIC OF CALIBRATION MENU SET – UP . 4 E + S 5 s e c ( see details page 7 ) C O d E Ï Ð 4 5 6 7 S E t Ï Ï Ï Ï Ï Ï... -
Page 14: Set - Up N° 1 : Trip Points Adjustment
TRIP POINTS ADJUSTMENT Diagram : load Charge (Kg) HI-HI S-HI Hystérésys S-HI SPED (calcul de l'effet dynamique) Hystérésys S-LO S-LO Hystérésys S-LO time Load cell signal MS 87/./. R 03/03... -
Page 15: Definitions
Definitions : S-HI : - Safety trip point. - Its value is generally set at 110% of crane capacity. - Adjustable to any point within the nominal capacity. - Control the 'HI'. Relay. - Value in weigh unit. - Takes account of the dynamic effect damper. HIHI : - Final safety trip. - Page 16 SYNOPTIC OF MANUAL TRIP POINTS ADJUSTMENT SET UP N°1 E + S 5 s e c C O d E 1 2 3 4 S E t Ï Ï C O r r Ð Ð Ï Ð Ï Ï S - H I S - L O H I H I Ð...
-
Page 17: Set Up N°2 : Automatic Trip Points Adjustment
AUTOMATIC SETTING OF SAFETY TRIP POINT SET- UP N°2 Essential conditions : THE TEST OPERATION SHOULD HAVE BEEN SUCCESSFULLY CARRIED OUT (page 7 ) The relay (rEL) is set by default in « HI » (see page 16) Equipment required : A load equivalent to 100 % if the working load limit of the lifting system. -
Page 18: One Safety Trip Point And Slack Wire Rope Detection
AUTOMATIC SETTING OF SAFETY TRIP POINT AND SLACK WIRE ROPE TRIP POINT Essential conditions : THE TEST OPERATION SHOULD HAVE BEEN SUCCESSFULLY CARRIED OUT (Page 7 ) The relay (rEL) is set to « LO » through SET –UP N°1 (page 16) Equipment required : A lifting accessory (Load n°1) is required for setting the slack wire rope trip point S-LO. -
Page 19: One Safety Trip Point And One Intermediate Trip Point
AUTOMATIC SETTING OF SAFETY TRIP POINT AND INTERMEDIATE TRIP POINT Essential conditions : THE TEST OPERATION SHOULD HAVE BEEN SUCCESSFULLY CARRIED OUT (page 7 ) The relay (rEL) is set by default in « HI » (page 16 Equipment required : A load (Load n°1) equivalent to the value of the intermediate trip point S-LO. -
Page 20: Gain And Zero Adjustment
ZERO AND GAIN ADJUSTMENT General information : Load cell are adjusted from factory and put out a frequency signal of 7500 Hz at there nominal capacity and 500 Hz without any load. ( the first 500 hertz indicates the well functioning of the system ) Some load cell due to the sheaving mode are not stressed at there nominal capacity. -
Page 21: Safety Wiring Diagrams
CONNECTION LAYOUT 1 SAFETY TRIP POINT + 1 SLACK WIRE ROPE POINT RXD- RXD+ TXD- TXD+ DEPHM DEPHD RCPT + 12 COM+ COM+ 220 + COM - MS 87/./. R 03/03... - Page 22 CONNECTION LAYOUT 1 SAFETY TRIP POINT + 1 INTERMEDIATE TRIP POINT RXD- RXD+ TXD- TXD+ DEPHM DEPHD RCPT + 12 COM+ COM+ 220 + COM - MS 87/./. R 03/03...
-
Page 23: Load Cell Wiring Diagrams
WIRING DIAGRAMS Remarks : Use shielded 4 x 0.34 mm² wires to connect the load cell. Shield must be connected only on the display side. Load cell with build in converter Sticker on the cover back. UTOCOLLANT SUR LE BOUCHON POWER LIMIT 0V +12 POWER... -
Page 24: Load Cell With Remote Converter
Load cell with remote converter POWER DYN HF87 HF84/1 RCPT Conditionneur HF84/1 Converter Load cell Capteur HF84/1 Shield Tresse POWER LIMIT Shield must be connected to the HF 84 / 1 side on the BL terminal. MS 87/./. R 03/03... -
Page 25: Sum Of Load Cells With Millivolts Signal Out Put
Several load cells with sum function in millivolts. POWER DYN HF87 HF84/2 RCPT Converter & sum unit Conditionneur Sommateur HF84/2 HF 84/2 Load cell Capteur 1 HF84/2 Capteur 2 Load cell HF84/2 Shield Shield Tresse Tresse POWER POWER LIMIT LIMIT Shield must be connected to the HF 84 / 1 side on the BL terminal. -
Page 26: Sum Of Load Cells With Frequency Signal Out Put
Several load cells with sum function in frequency. POWER DYN 100% HF83/2 HF87 (bornier 5) +12V -12V RCPT Tresse MMATEUR HF83 bornier 1 bornier 2 bornier 5 Load cell 2 CAPTEUR2 HF83/2 CAPTEUR1 Load cell & HF83/2 (bornier 2) (bornier 1) CAPTEUR 2 CAPTEUR 1 Load cell 1... -
Page 27: Radio Transmission
Radio receiver Wiring. HF89/2 POWER DYN 100% HF87 HF89/2 RCPT MS 87/./. R 03/03... -
Page 28: Trouble - Shooting
- Wrong wiring. - Double check wiring. - Power supply fault. - Double check power supply. - Display fault - Contact Tractel ASS - Load cell fault - Contact Tractel ASS NOTE : Wrong polarity wiring may cause destruction of some electronic components. -
Page 29: Information Messages
INFORMATION MESSAGES COMMENT DISPLAY t E S t Auto test when turn ON SEt 1 Set-up N° 1 Parameters adjustment menu SEt 2 Set-up N° 2 Trip points adjustment menu SEt 3 Set-up N° 3 Display zeroing. Code 3456 Only to reset the "zero" point SEt 4 Set-up N°... - Page 30 NOTES : MS 87/./. R 03/03...
