Summary of Contents for ADS Technologies IntraOral Camera AdvanceCAM
- Page 1 AdvanceCAM IntraOral Camera Operation And Installation Manual...
- Page 2 Advance Video Remote Control: Full / Quad Button: Choose to capture image in full screen or capture 4 images (quad). F/M: Press button to capture image on monitor Delete Button: Press shaded quad (1,2,3 or 4) to “delete” image from that specific quad. Press “Freeze Button” to re- capture image for specific quad.
- Page 3 Docking Station AIC815 Full / Quad Button: Push button to capture image(s) in full screen or 4 images (quad). Choice Button: Press the choice button to highlight image 1 2 3 or 4 when in quad mode. The number will turn green. This function only works in quad mode.
- Page 4 Advance Cam Press “Freeze button” to freeze image. Press “Freeze button” again to copy image into memory. There is also an additional button on the wand that will allow you to change from “full” to “quad”. Press this button once and it will put you in “quad”...
-
Page 5: Installation Instructions
AdvanceCAM Intraoral Camera Installation Instructions AIC 850 Turn power to transmitter on and off. Light will emit from end of camera when power is on. AIC 900 Turn power to transmitter on and off. Light will emit from end of camera when power is on. - Page 6 Prior to using the TPC-WIC 850, AIC900 charge the Wireless Video Module TX until the power supplies LED turns back to green. It will be red while the unit is charging. After the charging period is over, it is recommended that the power charger be removed from the transmitter.
- Page 7 AIC810 Plug adv20 “switching power adapter” into Docking Station ADV-20 /AIC815 “DC 5VIN” port. Plug power supply into wall outlet. AIC810 Plug RCA jack or S-Video into Docking Station ADV- 20 “AV Out” or “YC Out” port. Connect other end of video cable into Video Input port on monitoring device (pc or TV).
- Page 8 Notes: Cameras that start with PA or NT, you will need to press the freeze button to activate the camera’s LED’s. This will turn the camera on. Then you will be able to see an image from the camera. Docking Station Settings: AIC800,805,810,815 •...
-
Page 9: Troubleshooting Guide
Troubleshooting Guide The remote to my camera does not work. Point the remote towards the lens of the camera, press any button and hold on the remote. You should see light flickering on the monitor. You must use the camera to see this because the human eye cannot detect this light.
