Essence Care@Home ES700BD User Manual

Bed sensor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Care@Home™
Bed Sensor
User Guide
ESUGSC104
Version 1.0
February 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Care@Home ES700BD and is the answer not in the manual?

Questions and answers

Related Manuals for Essence Care@Home ES700BD

Summary of Contents for Essence Care@Home ES700BD

  • Page 1 Care@Home™ Bed Sensor User Guide ESUGSC104 Version 1.0 February 2019...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Overview ..............................3 Setting Up the Bed Sensor ........................4 2.1. Required Items ........................... 4 2.2. Pairing the Bed Sensor ....................... 4 2.3. Placing the Bed Sensor ....................... 6 2.4. Associating the Bed Sensor with a Motion Detector ..............7 Operating the Bed Sensor ........................

  • Page 3: Overview

    Overview 1. Overview The Essence Bed Sensor is a battery-operated, bi-directional wireless sensor for detecting the resident's presence in bed. Care@Home™ uses the bed sensor, together with an associated motion detector (PIR), to determine if the resident is in the bedroom.

  • Page 4: Setting Up The Bed Sensor

    Setting Up the Bed Sensor 2. Setting Up the Bed Sensor To set up the bed sensor:  Ensure you have the required items  Pair the bed sensor  Place the bed sensor  Associate the bed sensor with a motion detector 2.1.
  • Page 5 Setting Up the Bed Sensor 2. Press and hold the PAIRING button on the control panel until you hear a double beep. PAIRING Button 3. Move the bed sensor at least 2 m (~6 ft. 7 in.) from the control panel. 4.

  • Page 6: Placing The Bed Sensor

    Setting Up the Bed Sensor Control Panel Response Meaning Low pitch beep and This bed sensor has already been paired with EMERGENCY button ring lights this control panel. blue as EMERGENCY button lights red. Beeps and the EMERGENCY Bed sensor cannot be paired. Control panel memory is full.

  • Page 7: Associating The Bed Sensor With A Motion Detector

    Setting Up the Bed Sensor 2.4. Associating the Bed Sensor with a Motion Detector The bed sensor and motion detector work together to determine the presence of the resident in the bedroom. You must associate the bed sensor with a specific motion detector (PIR). Use the Care@Home™...

  • Page 8: Operating The Bed Sensor

    Operating the Bed Sensor 3. Operating the Bed Sensor The bed sensor monitors certain events, and reports them by:  LED indications  Sending notifications to the CP 3.1. LED Indications The bed sensor LED lights for the following events: ...

  • Page 9: Replacing The Battery

    Replacing the Battery 4. Replacing the Battery To replace the battery: 1. Insert a screwdriver into the transmitter's slot and press the tab to release the mounting base. 2. Remove the old battery. 3. Press the tamper switch several times. Tamper switch 4.

  • Page 10: Specifications

    Specifications 5. Specifications Item Data ES700BD Part Number  Maximum RF range: Up to 400 m (1,312 ft.) – open air Communications  Protocols: Proprietary bi-directional radio protocol  Modulation and frequency: FSK modulation:  868.3 MHz (China)  869.225 MHz (Europe) ...

  • Page 11: Legal Notice

    Nothing contained herein shall be construed as conferring by implication, estoppels, or otherwise any license or right, either express or implied, under any patent or trademark of Essence or any third party. No use of any trademark may be made without the prior written authorization of Essence.
