ASSEMBLY INSTRUCTION
LOT#
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION. PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
UPC#849392013102/849392013096
3-Tier-Metal Cart
MS59-020-098-01/MS59-020-098-02
Easy Home Organization Manufacturing Co., Ltd
NEED HELP? For help with assembly or missing
part ordering, please call our helpdesk toll-free:
1-855-968-6917 between 9 a.m and 4 p.m (Central
Time) Monday to Friday.
Or email us:
easyhome.customersupport@usa.arcoxmail.com
Please let customer service know:
1. You purchased this item from Wal-Mart
2. The item description is: 3-Tier-Metal Cart
3. The vendor stock number is MS59-020-098-01/
MS59-020-098-02
4. The part number/letter and quantity needed
If you have this information ready, we will be
able to process your request promptly. Thank you
This unit is intended for use only with the products
and maximum weights indicated. MAXIMUM
SAFE LOAD: 120 lbs (54.4kgs)
Use with other products or products heavier than the
maximum weights indicated may result in instability
causing possible injury. Furniture can tip over or
break if improperly moved. Have a friend help to lift
and carry the unit to it's new location.
Printed in China
DATE PURCHASED
Do Not Return To The Store!
WARNING!!!
/
/
Advertisement
Summary of Contents for Mainstays MS59-020-098-01
- Page 1 Please let customer service know: 1. You purchased this item from Wal-Mart 2. The item description is: 3-Tier-Metal Cart 3. The vendor stock number is MS59-020-098-01/ MS59-020-098-02 4. The part number/letter and quantity needed If you have this information ready, we will be able to process your request promptly.
- Page 2 CAUTION: 1. Read this instruction manual and keep it for reference. 2. Adult supervision is required due to small parts. 3. Assembly on soft surfaces to prevent damage to the product finish. 4. Estimated ten minutes for assembly. 5. Call our toll-free customer service if needed. ASSEMBLY TOOLS REQUIRED HEX WRENCH WRENCH...
- Page 3 Bigger Shelf Smaller Shelf Support Beam 24（+1） Bolt 24（+1） Wheel Wheel with Brake Hex Wrench Wrench...
- Page 4 STEP 1. Lay the parts "A" and "B" on side，insert parts "C" into part "A" and then lay on part "B" as shown. Align all holes of parts"C" with holes of parts "A" and "B" correspondingly, insert bolts "D" through the holes,and tighten up by using nuts"E" and wrench "H"and "I"...
- Page 5 STEP 2. Turn over the assembled unit in step1, repeat the operation and assemble the other two pieces of parts "C" as shown. C -2PCS D -12PCS E -12PCS STEP 3. Screw the wheels into parts "C" and tighten up by using the wrench “I” as shown.
- Page 6 Complete. Safe Load =40bls(18.1kg） Safe Load =40bls(18.1kg） Safe Load =40bls(18.1kg） CAUTION: Make sure parts and hardware are properly fixed before using the product to prevent damage or injury. Do not scratch or chip the finish. To clean the Organizer , wipe with soft, dry cloth. Do not use abrasive cleaners in order to prevent the scratching the surface.
-
Page 7: Instrucciones De Montaje
INFORMACIÓN IMPORTANTE DE SEGURIDA.POR FAVOR LEA Y MANTENGA EL FOPLEASE LEER Y MANTENGA LA REFERENCIA FUTURA. UPC#849392013102/849392013096 Carro de metal de 3 niveles MS59-020-098-01/MS59-020-098-02 Easy Home Organization Manufacturing Co., Ltd No vuelvas a la tienda! DETENER ¿NECESITAS AYUDA? Para obtener ayuda con... - Page 8 PRECAUCIÓN: 1. Lea este manual de instrucciones y guárdelo como referencia. 2. Se requiere la supervisión de un adulto debido a las piezas pequeñas. 3. Montaje sobre superficies blandas para evitar daños en el acabado del producto. 4. Estimado diez minutos para el montaje. 5.
- Page 9 PIEZAS Y HARDWARE ANTES DE COMENZAR, SIGA LAS INSTRUCCIONES DE MONTAJE CUIDADOSAMENTE.SÍGUELOS PASO A PASO. Estante más grande Estante más pequeño Viga de soporte 24（+1） Tornillo 24（+1） Nuez Rueda Rueda con freno Llave hexagonal Llave...
- Page 10 PASO 1. Coloque las partes "A" y "B" en el lado, inserte las partes "C" en la parte "A" y luego colóquelas en la parte "B" como se muestra. Alinee todos los orificios de las partes "C" con los orificios de las partes "A" y "B"...
- Page 11 PASO 2. Dé vuelta la unidad ensamblada en el paso 1, repita la operación y ensamble las otras dos piezas de las partes "C" como se muestra. C -2PCS D -12PCS E -12PCS PASO 3. Atornille las ruedas en las partes "C" y apriételas usando la llave "I" como se muestra.
- Page 12 Completar. Carga segura = 40bls (18.1kg） Carga segura = 40bls (18.1kg） Carga segura = 40bls (18.1kg） CAUTION: Antes de usar el producto, asegúrese de que las piezas y los accesorios estén bien fijados para evitar daños o lesiones. No raye ni astille el acabado. Para limpiar el Organizador, limpie con un paño suave y seco.
