Baha Aluminum Venetians Quick Start Manual

25mm

Hide thumbs

Item Checklist

Venetian Blind

Brackets & Screws

Plaster

Use the provided

screws

If no solid

mounting point,

we recommend

Ramset 10mm

Hollow Wall

Anchors (not

supplied)

Installing 25mm Aluminum Venetians

Fixing Type

Timber

Use the provided

screws

Tools Required

Cordless Drill (with Hammer

capability if masonry wall)

#2 Phillips Head drill bit.

Metal Tape Measure

Pencil

Concrete, Brick or Stone

(These items need to be

purchased separately)

Use the provided

screws

50mm Red Wall

Plugs

5.5mm Masonry

Hammer

Table of Contents

Need help?

Do you have a question about the Aluminum Venetians and is the answer not in the manual?

Questions and answers

Summary of Contents for Baha Aluminum Venetians

Page 1 Installing 25mm Aluminum Venetians Item Checklist Tools Required Venetian Blind Cordless Drill (with Hammer Brackets & Screws capability if masonry wall) #2 Phillips Head drill bit. Metal Tape Measure Pencil Fixing Type Plaster Timber Concrete, Brick or Stone Use the provided Use the provided Use the provided screws screws screws If no solid 50mm Red Wall mounting point, Plugs we recommend 5.5mm Masonry Ramset 10mm Hammer Hollow Wall (These items need to be Anchors (not purchased separately) supplied)
Page 2 Positioning the Brackets It is important to first observe the placement of the blind’s components within the head rail. At some locations you will be unable to clip the bracket in due these components interfering. The brackets should be roughly, evenly spaced along width of the blind. The end brackets should be placed 115mm from each end. For Face Fit the brackets should be positioned flush with the top of the architrave, or at the ordered height (if wall installation). For Recess fit the front of the bracket should be positioned at the front of the reveal. Mounting the Brackets The bracket is universal, fix the bracket according to your installatin and wall type.
Page 3 Mounting the Blind Place the top inside edge of the head rail on to the front of the bracket. Then slightly push whilst rotating your blind upward until the back of the head rail clips into place. Cleat + Hold downs To complete the installation, mount the cord cleat on the wall on the lifting cord side. The hold clips are optional. To install, fasten the L shaped part of your hold down clip in the bottom corners of the window and screw into place. Then insert the pin into the base rail and slide the pin into hold down clip Your blind is now professionally installed and you just saved on the installation expense! BAHA offer a 5-year warranty on your new blinds. Please see further details on our webpage. For further information please contact our customer service team Monday to Friday 9am to 5pm Phone: 1800 039 171 or Email: sales@baha.com.au...
