BUL10482
ASSEMBLY INSTRUCTIONS FOR
HARDWARE
A
REV.
INSTALLING CLHAN-01
PAGE OF
1
2
INSTRUCTIONS FOR
REPLACING LOCK ON DC100 CABINET
**ENSURE TO
HOLD LOCK ROD
ASSEMBLY SO IT
DOES NOT FALL
WHEN REMOVING
HANDLE ASSEMBLY**
PUSH OUT PLASTIC
REMOVE 2 SCREWS
HANDLE ASSEMBLY
AND RETAINING BOLT
PLACE BOTTOM OF NEW
INSTALL 2 PROVIDED
PUSH TOP OF HANDLE
HANDLE IN FIRST THEN PUSH
SCREWS (RETAINING
ASSEMBLY OUT FIRST
TOP INTO LOCK ROD ASSEMBLY
BOLT NOT REQUIRED)
NOTE: Provided back plate is not needed on DC100
Phillips
TOOL BOX
Screw Driver
