Bluefin Led Underwater lights.
Domestic DL6D Installation manual.
Thank you for choosing Bluefin LED underwater lights, our products have been designed and tested
rigorously to ensure the optimum performance and longevity.
All Bluefin Led lights are water tested so please be aware there may be moisture present on the light.
Please ensure that your product is installed as per our instructions below, failure to do so may
invalidate your warranty.
Specs: electrical/fuse ratings
DL6D
DL6DCC
Warnings:
•
Do not under any circumstances hold the light by the cable. (the light is not designed to be
hung by the cable and will result in damage to the unit).
•
Do not remove the inline HYDRO LOCK or your warranty will be void.
•
Do not disassemble the light and puck or you warranty will be void.
•
The cable must be protected with the outer tube supplied or your warranty will be void.
•
Do not use abrasives on the lenses.
Tools required for installation:
•
3mm (1/8") drill bit
•
Drill
•
Posi head hand screwdriver
Installation:
There are two mounting methods to the dock light product which will depend on your mounting
point, these are show below as option 1 and 2. The tubing installation must be done before the
lights are submerged in the water.
The light can be mounted with a top or side entry, either can be used depending on your cable exit
route.
All lights are configured for top or side entry as standard.
Ensure that you plan your cable tubing and fitment before progressing with the light installation.
BlefinLed suggests fitting the light and tubing to a plank of treated wood before installation into
water as shown in Fig 14
The light must remain underwater at all times so please ensure that you take into consideration tides
and the water line.
Ensure that your Tube is connected to the Dock Light puck before installation to the dock.
Option 1 screw mounting
Drill 3mm (1/8") pilot holes to match the mounting holes on the Dock light puck. Fig 2/3
Screw the dock light puck to the plank using the 2 screws provided. Fig 4
Option 2 Strap/wire mounting.
The dock light puck has side entry slots for strapping to pilings or docks. Fig 2
1
Voltage
Current
24V ONLY
24V-1.8amp
24V ONLY
24v-2amp
Fuse rating
3 amp
8 amp
