Samsung SGH-C260 User Manual

SGH-C260
User's Guide
• Depending on the software installed or your service provider or country, some
of the descriptions in this guide may not match your phone exactly.
• Depending on your country, your phone and accessories may appear different
from the illustrations in this guide.
Printed in Korea
Code No.: GH68-13785A
World Wide Web
http://www.samsungmobile.com English (EU). 09/2007. Rev.1.2
Silent Press and hold in Idle mode to disable all sounds on the phone.
mode To exit, press and hold this key again.
Voicemail
Press and hold 1 in Idle mode to access your voicemail server.
server
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Icons
Text and graphics
Soft key function
Menu Phonebook
indicators
Using the menus
In Idle mode, press the Menu soft key to enter the main menu.
Labels at the bottom corners of the display
show the current soft key functions. Press
the left soft key ( ) or right soft key ( )
to perform the function indicated.
To exit the menu
To return to the
without changing
previous menu
the menu settings,
level, press the
press this key.
C
soft key or .
Use the 4-way navigation keys ( )
as shortcuts to access your favourite menus.
1. In Idle mode, press the Menu soft key.
→
2. Select Phone settings Short cut.
3. Select a key.
4. Select a menu to be assigned to the key.
Installing the SIM card and battery
1. Remove the battery cover and insert the SIM card.
Battery
cover
2. Install the battery and reattach the cover.
Battery
Your phone displays the following status indicators on the top of the
screen:
Icon Description
Received signal strength
Call in progress
Out of your service area; you cannot make or receive calls
except for emergency calls
GPRS network
Roaming network
Call ringer set to vibrate
Silent mode
Call diverting feature active
New text message
New voicemail message
Alarm set
Battery power level
To select or modify a menu or feature:
1. In Idle mode, press the Menu soft key.
2. Press the Navigation keys to reach a desired menu and then press
the Select soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the Select soft key or
enter the submenu.
If the selected menu contains additional submenus, repeat this
step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the Select soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu mode.

Charging the battery

1. Plug the supplied travel adapter.
Note: Never plug the connector of a headset into the travel adapter jack.
2. When charging is finished, unplug the adapter.
Note: Do not remove the battery from the phone without unplugging the
adapter first. Otherwise, the phone may be damaged.
Switching on or off the phone
1. Press and hold for more than one second to switch on the phone.
2. Press the Yes soft key and set the time and date settings by the
following onscreen instructions.
3. To switch off the phone, press and hold
Changing the display language
1. In Idle mode, press the Menu soft key.
2. Select Phone settings → Language.
3. Select a language.
Making a call
1. In Idle mode, enter an area code and phone number, and press
2. When you want to end the call, press .
Answering a call
1. When the phone rings, press the Accept soft key or
call.
Menu map
1. SIM AT* 4. Sound settings
2. Call records
2.1 Missed calls
to
2.2 Received calls
2.3 Dialled calls
2.4 Delete all
2.5 Call time
2.6 Call cost*
5. Messages
3. Network services
3.1 Call diverting
3.2 Call barring
3.3 Call waiting
3.4 Network selection
3.5 Caller ID
3.6 Closed user group
Phone layout and key functions
Web access/
Confirm key
In Idle mode, accesses
the web browser.
Selects the highlighted
option or confirms
input in a menu mode.
To AC wall outlet
Soft keys
Perform functions
indicated by the text
above the key.
Dial key
Makes and answers a
call. In Idle mode,
retrieves the most
recent calls.
Voicemail server key
Voicemail server
Cancel/Clear key
Deletes characters from
the display. Returns the
display to the previous
menu level.
To reject the call, press the
2. When you want to end the call, press

Adjusting the volume

for more than two seconds. 1. In Idle mode, press the
2. Select Sound settings
3. Press Up or Down to adjust the volume level.
4. Press the OK soft key.
Changing a ringtone for calls
1. In Idle mode, press the
2. Select Sound settings
.
3. Select a ringtone.
Redialling recent numbers
1. In Idle mode, press
to answer a
2. Press Up or Down to scroll to the number you want.
3. Press to dial the number.
6. Funbox
4.1 Ring tone 6.1 WAP browser
4.2 Ring volume 6.2 Sounds
4.3 Alert type 6.3 Images
4.4 Keypad tone 6.4 Delete all
4.5 Keypad volume 6.5 Memory status
4.6 Message tone
4.7 Alert on call
4.8 Folder tone
7. Organiser
4.9 Extra tones
7.1 Alarm
7.2 Calendar
7.3 Time & Date
7.4 Calculator
5.1 Inbox 7.5 To do list
5.2 Outbox 7.6 Voice memo
5.3 Write new 7.7 Currency exchange
5.4 Templates
5.5 Settings
5.6 Delete all
5.7 Memory status
5.8 Voice mail
5.9 Broadcast
4-way navigation
keys
In Menu mode, scroll
through menu options.
In Idle mode, access
your favourite menus
directly.
Power/End key
Turns the phone on or
off when pressed and
held. Also, ends a call.
Silent mode key
Silent mode
Alphanumeric keys
Reject soft key or .
.
Menu soft key.
Ring volume.
→
Menu soft key.
→ Ring tone.
.
8. Phonebook
8.1 Search
8.2 New entry
8.3 Group search
8.4 Edit group
8.5 Speed dial
8.6 Delete all
8.7 Memory status
8.8 SDN*
9. Phone settings
9.1 Display settings
9.2 Greeting message
9.3 Own number
9.4 Language
9.5 Security
9.6 Extra settings
9.7 Short cut
9.8 Reset settings
*
Shows only if supported by your SIM card.
