Summary of Contents for Sierra Titanium Power TM500.1AB
- Page 2 A. Precautions 1. Volume Level Adjustment When driving, Keep the volume level low enough to be aware of road and traffic conditions. 2. When Car Washing Do not expose the equipment, including the speakers and CDs, to water or excessive moisture. This could cause electrical shorts fire or other damage.
-
Page 3: Trunk Mounting
Trunk Mounting Mounting the amplifier vertically on a surface with the fin grooves running up and down will provide the best cooling of the amplifier. Mounting the amplifier on the floor of the trunk will work but provides less cooling capability than vertical mounting. Mounting the amplifier upside down to the rear deck of the trunk will not provide proper cooling and will severely affect the performance of the amplifier and is not recommended. -
Page 4: Wiring The System
3. Wiring the System CAUTION : Avoid running power wires near the low level input cables, antenna, power leads, sensitive equipment or harnesses. The power wires carry substantial current and could induce noise into the audio system. For safety, disconnect the negative lead from the battery prior to beginning the installation. 1. -
Page 5: Battery And Charging
8. Connect the speakers. Strip the speaker wires 5/8" and insert into the appropriate terminal on the amplifier. Insert the bared wire into the speaker terminal and tighten the set screw to secure into place. Be sure to maintain proper speaker polarity. DO NOT Chassis ground any of the speaker leads as unstable operation may result. -
Page 6: Feature Overview
FEATURE OVERVIEW Class-AB Mono Block TM500.1AB FEATURE OVERVIEW ● High Efficiency "Class-AB" MONOBLOCK Amplifier ● Varable Subsonic Filter from 20Hz - 55Hz @ 12dB/octave ● 2 Ohm Stable MONO Amplifier Design ● Gold/Silver Plated 4 Gauge Power and Ground Connections ●... -
Page 7: System Example
Class-AB Mono Block TM500.1AB System Example 2 ohm : 1 Speaker System 4 ohm : 2 Speaker System... - Page 8 FEATURE OVERVIEW Class-D Mono Block Amplifier TM1200.1D FEATURE OVERVIEW ● 1 Ohm Stable D Class Amplifier Design ● Gold/Silver Plated Audio Input and Output Connections ● Accurate Stated Amplifier Ratings ● Bass Remote Controller Included ● Variable Bass Boost 0 - +15dB ●...
- Page 9 Class-D Mono Block Amplifier TM1200.1D System Example SPL System Example Master Amplifier Set Config switch : LP/LP RCA input from Headunit A single LPL plugged into the Master amplifier controls the lowpass level of the master and Slave amplifiers. Slave Amplifie Aux Output provides a lowpass signal for additional amplifier(s)
-
Page 10: Channel Power Amplifier
FEATURE OVERVIEW 2 Channel Power Amplifier TM300.2 FEATURE OVERVIEW ● 2 Ohm Stable MOSFET Amplifier Design ● Intercooled Semi-conductor Technology ● Accurate Stated Amplifier Ratings ● Gold/Silver Plated 4 Gauge Powwer and Ground Connections ● Variable Bass Boost 0 - +18dB at 45Hz ●... -
Page 11: Troubleshooting
2 Channel Power Amplifier TM300.2 System Example (Bridged Mode) System Example (Stereo Mode) Troubleshooting Symptoms Check Cure Amplifier turns off at ● Check speakers for damage ● Have your dealer inspect low volume levels. or short circuit. the speakers No sound. ●... - Page 12 FEATURE OVERVIEW 4Channel Power Amplifier TM300.4 FEATURE OVERVIEW ● High Efficiency MOSFET Power Supplies ● Wire Free PC Board Layout ● Multi-standed Power Torroids ● Fully Varibale Electronic Crossover ● 2 ohm Stable Stereo Operation ● 4 Way Protection Circuitry ●...
-
Page 13: Power Cable Calculator
4Channel Power Amplifier TM300.4 Power Cable Calculator Total Amperage 0-4ft 4-7ft 7-10ft 10-13ft 13-16ft 16-19ft 19-22ft 22-28ft 0-20 20-35 35-50 50-65 65-85 85-105 105-125 125-150 The above chart shows cable gauges to be used, if no less than a 0.5 volt drop is acceptable. If aluminum wire or tinned wire is used, the gauges sould be of an even larger size to compensate. - Page 14 FEATURE OVERVIEW 4Channel Power Amplifier TM400.4 FEATURE OVERVIEW ● 2 Ohm Stable MOSFET Amplifier Design ● PWM Regulated Amplifier Technology ● Accurate Stated Amplifier Ratings ● Intercooled Semi-conductor Technology ● Variable Bass Boost 0 - +18dB at 45Hz ● Gold/Silver Plated 4 Gauge Powwer and Ground Connections ●...
- Page 15 4Channel Power Amplifier TM400.4 POWER CABLE CALCULATOR Total Amperage 0-4ft 4-7ft 7-10ft 10-13ft 13-16ft 16-19ft 19-22ft 22-28ft 0-20 20-35 35-50 50-65 65-85 85-105 105-125 125-150 The above chart shows cable gauges to be used, if no less than a 0.5 volt drop is acceptable. If aluminum wire or tinned wire is used, the gauges sould be of an even larger size to compensate.
- Page 16 FEATURE OVERVIEW 5 Channel Power Amplifier TM500.5 FEATURE OVERVIEW ● 2 Ohm Stable MOSFET Amplifier Design ● Intercooled Semi-conductor Technology ● Accurate Stated Amplifier Ratings ● Gold/Silver Plated 4 Gauge Powwer and Ground Connections ● Variable Bass Boost 0 - +18dB ●...
- Page 17 System Example 5 Channel Power Amplifier TM500.5 5 Channel Installation 4 Channel Installation 3 Channel Installation...
-
Page 18: Specifications
Specifications Titanium Power Amplifier TM500.1AB TM1200.1D TM300.2 TM300.4 TM400.4 TM500.5 Into 4 ohm at 14.4V 300W x 1Ch 500W x 1Ch 150W x 2Ch 75W x 4Ch 100W x 4Ch 50W x 4Ch + 150w x 1Ch Into 2 ohm at 14.4V 510W x 1Ch 800W x 1Ch 260W x 2Ch...
