Summary of Contents for Polon-Alfa ADC-4001M
- Page 1 IK-E283-001E POLON 4000 INTERACTIVE FIRE DETECTION AND ALARM SYSTEM ADC-4001M ADAPTER Installation and maintenance manual IK-E323-001E Edition IA...
- Page 2 IK-E283-001E The ADC-4001M adapter, covered by this manual, complies with the requirements of the following European Union directives: 89/106/EWG - on construction goods; 2004/108/WE - on electromagnetic compatibility. The ADC-4001M adapter has been approved with the EC Certificate of Conformity No. 1438/CPD/0069, issued by the Scientific and Research Centre for Fire Protection (CNBOP) Józefów, Poland, an EU notified...
- Page 3 The elements that are installed in a branch line are assigned with a common address, determined by the ADC-4001M adapter’s address and their activation evokes a fire alarm at the control panel. The adapter is equipped with a short-circuit isolator.
- Page 4 4 DESIGN DESCRIPTION The ADC-4001M adapter is placed in a casing similar to those of 40 model range detectors, however the casing is not ribbed – the upper part is entirely closed. A cover is fitted to the casing and a two-colour diode is located from the front side.
- Page 5 POLON 4000 system control panel manuals. 6 POLON 4000 INTRINSICALLY SAFE DETECTION LINES The POLON 4000 intrinsically safe detection lines can be routed only as branch lines behind ADC-4001M adapters using intrinsically safe separators manufactured by STAHL: one-channel type 9167/13-11-00s;...
- Page 6 7 INSTALLATION 7.1 Installation place and fastening The ADC-4001M adapter is designed for wall or ceiling mounting, inside premises, using the G-40 base. The base should be fastened to a ceiling with two screws and expansion anchor bolts (Ø6 recommended). It is advised to drill the bolt holes using a pattern of 63 mm hole spacing.
- Page 7 +70 °C. The ADC-4001M adapters should be stored in closed premises that are free of corrosive gases or vapours, at ambient temperature from +5 °C to +40 °C and relative humidity between 40 % and 80 %, away from...
- Page 8 IK-E283-001E Fig. 2 ADC-4001M adapter exemplary connection into addressable detection line with exemplary adapter branch line connection IK-E323-001E/05.2009/01.2012...
