JONARD TOOLS FCCN-125 Instruction Manual

IMPORTANT - HOW TO REALIGN THE CLEANING CLOTH

Push the stopper
backward
Cleaning cloth
Stopper

ATTENTION

Please hold the base of the cleaning guide when you tilt the tip upwards. FCCN-250 can be tilted
on an angle of 15,30 or 45 degrees. FCCN-125 can be tilted on an angle of 15 or 30 degrees. Do
not tilt cleaning guide down: ONLY TILT UPWARDS. When you feel the click button does not move
smoothly, please check the indicator window (cleaning cloth may be empty).
Jonard Tools assumes no liability whatsoever for actions by a third party, other accidents, intentional
or accidental misuse, or use under other abnormal conditions by the user.
Full Empty

DANGER

• Do not use or leave in places exposed to high temperatures or in places where flammable
gases are generated.
• Do not peer through the ferrule end-face and adapters.
• Do not use with live fiber.

WARNING

• Do not subject to strong impact by dropping or throwing this.
• Do not disassemble, make repairs or modify.
• Do not splash with water or other liquids.
• Should this become splashed with liquid, immediately stop cleaning.
• Malfunctions caused by splashing or moisture are outside the scope of the warranty and
cannot be repaired.
Pull the stopper forward
Misalign Withdraw
Realign
Misalign
CAUTION ANGLE NOTICE
FCCN-125 & FCCN-250
FERRULE END-FACE CLEANER INSTRUCTION MANUAL
