'MINI' Quick Start Guide - Setup

8
7
The quick start guide can be used to aid the setup of your welder but it's important to fully read
and understand this manual fully prior to setting up the welding machine.
1. Strap attachment points
2. Current adjustment dial
3. Power indicator light
4. Abnormal indicator light
5. Positive output terminal
6. Negative output terminal
7. Earth clamp
8. MMA (stick) weld clamp
