Hatteras Hammocks L-EKD Assembly Instructions Manual

Large hammock stand
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

LARGE HAMMOCK STAND
MODEL
#L-EKD
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at
1-800-643-3522, Ext. 506, 7:30 a.m. - 5 p.m., EST, Monday - Friday.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-EKD and is the answer not in the manual?

Questions and answers

Summary of Contents for Hatteras Hammocks L-EKD

  • Page 1 LARGE HAMMOCK STAND MODEL #L-EKD ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-3522, Ext. 506, 7:30 a.m. - 5 p.m., EST, Monday - Friday.

  • Page 2: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Foot Pole Pole with Tapered End Base Pole Upper Arm Pole Foot Cap (pre-assembled) End Cap (pre-assembled)

  • Page 3: Safety Information

    HARDWARE CONTENTS (not shown actual size) Offset S-Hook Steel Spring Clip (pre-assembled) Qty. Qty. Chain Assembly (with S-Hook) Qty. SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. WARNING • Do not exceed the hammock stand’s weight limit. Appropriately installed and cared for, the stand has a weight limit of 450 lbs.
  • Page 4 ASSEMBLY INSTRUCTIONS 1. Place one Foot Pole (A) flat on the ground with one short arm pointed up and the other level with the floor. Attach the Base Pole (C) to the lower arm of the Foot Pole using the Foot Pole’s Steel Spring Clip (AA), pushing down on the silver-colored pin at that end of the Foot Pole and then sliding the wider end of the Base Pole over the pin until the pin pops into the oval...
  • Page 5 ASSEMBLY INSTRUCTIONS 3. Connect the wider end of a Pole with Tapered End (B) to the upward-facing short arm of one Foot Pole (A) using the Foot Pole’s remaining Steel Spring Clip (AA). Repeat step with the other Foot Pole and the remaining Pole with Tapered End.
  • Page 6 ASSEMBLY INSTRUCTIONS HANGING A HAMMOCK 6. Place a link of chain attached to your hammock (not included) over one Offset S-Hook (BB). Repeat for the opposite side of the hammock and stand. Adjust hammock height by changing chain links. Hardware Used Hammock Offset S-Hook chain (not...

  • Page 7: Troubleshooting

    CARE AND MAINTENANCE • Wipe off any loose dirt or debris. Organic material can support mold and mildew growth, which can potentially damage the stand. • To help prevent rust, do not leave stand legs in puddled water. • During long periods in which your hammock (not included) is not in use, disassemble this stand and store it, along with the hammock, in a dry place away from harsh chemicals.
