Page 1 PARTS AND OPERATION MANUAL MQ POWER WHISPERWELD WELDER/A.C.GENERATOR Model DAW-500S PART No. D6845200104B Revision #0 (07/19/01) MULTIQUIP INC. PARTS DEPARTMENT: 18910 WILMINGTON AVE. 800-427-1244 CARSON, CALIFORNIA 90746 FAX: 800-672-7877 SERVICE DEPARTMENT: 310-537-3700 800-421-1244 800-835-2551 FAX: 310-537-3927 FAX: 310-638-8046 • E-mail:mq@multiquip.com...
Page 2 PAGE 2 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 3: Here's How To Get Help
HERE'S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING PARTS DEPARTMENT 800/427-1244 or 310/537-3700 FAX: 800/672-7877 or 310/637-3284 SERVICE DEPARTMENT 800/835-2551 or 310/537-3700 FAX: 310/638-8046 WARRANTY DEPARTMENT 800/835-2551 or 310/537-3700 FAX: 310/638-8046 MAIN 800/421-1244 or 310/537-3700 FAX: 310/537-3927 DAW-500S WELDER/A.C.
Page 4: Table Of Contents
Explanation Of Codes in Remarks Section ..... 40 Alternator Assembly ......... 108-109 Suggested Spare Parts ........... 41 Alternator Component Assembly ..... 110-111 MQ Power DAW-500S — Starter Assembly ..........112-113 Starter Component Assembly ......114-115 Welder/AC Generator Oil Switch Assembly ......... 116-117 Generator Assembly ..........
Page 5: Parts Ordering Procedures
PARTS ORDERING PROCEDURES Dealer account number Dealer name and address Shipping address (if different than billing address) Return fax number Applicable model number Quantity, part number and description of each part Specify preferred method of shipment: • UPS Ground • UPS Second Day or Third Day* •...
Page 6: Rules For Safe Operation
NEVER use accessories or attachments, which are not fire could result causing severe bodily harm or even death. recommended by MQ Power for this equipment. Damage to Topping-off to filler port is dangerous, as it tends to spill fuel. the equipment and/or injury to user may result.
Page 7 RULES FOR SAFE OPERATION CAUTION: CAUTION: This welder/AC generator is a source of providing LETHAL high voltages. Never permit unqualified personnel-especially children to operate the welder/AC generator. This welder/AC generator is equipped with a ground terminal for your protection. Always complete the grounding path from Never use damaged or worn cables when connecting the welder/AC generator to an external grounding source.
Page 8: Operation And Safety Decals
OPERATION AND SAFETY DECALS Machine Safety Decals The DAW-500S welder/AC generator is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. The illustration below shows these decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer.
Page 9 OPERATION AND SAFETY DECALS DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 9...
Page 10 DAW-500S — SPECIFICATIONS a t l s t l a t l a t l s t l ) y l ) y l c i t , l a n i l y t i 4 / l y t i 4 / l y t i 5 / l...
Page 11: General Information
Reference Table 1, ! Idle Control Switch page 10 for engine specifications. ! Starter Switch In keeping with MQ Power's policy of constantly improving ! Warning Lamp Unit its products, the specifications quoted herein are subject to ! Hour Meter change without prior notice.
Page 12: Dimensions
DAW-500S — DIMENSIONS Dry Weight: 1,025 lbs. Total Weight: 1,150 lbs. Figure 1. DAW-500S Dimensions PAGE 12 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 13: Controls And Indicators
DAW-500S — CONTROLS AND INDICATORS Engine Oil Filler Port – Remove this cap to add engine Figures 2 and 3 show the location of the controls and indicators. oil. Use only recommended type oil. See table 3, page 16. The functions of each control or indicator is described below and on the preceding page.
Page 14 DAW-500S — CONTROLS AND INDICATORS 15. Fuel Drain Plug – Remove this plug to drain fuel from the 24. Main Circuit Breaker – This single-pole circuit breaker fuel tank. provides circuit protection (125V @25 amps) for the electric parts assembly. 16.
Page 15: Trailer Safety Guidelines
DAW-500S — TRAILER-SAFETY GUIDELINES CAUTION: 7. Coupler - Type of hitch used on the trailer for towing. 8. Tire Size - Indicates the diameter of the tire in inches ALWAYS make sure the trailer is in good (10,12,14, etc.), and the width in millimeters operating condition.
Page 16: Trailer Specifications
DAW-500S — TRAILER-SPECIFICATIONS " 6 " 0 " 6 " 0 " 6 " 0 " 5 " 2 " 4 " 5 " 4 " 8 " 4 " 5 " 4 " 5 " 4 " 5 " 0 "...
Page 17 DAW-500S — TRAILER-SPECIFICATIONS ) t ' " 2 X " " 0 B " X " " 5 B " X " " 5 B " " 5 B " " 5 " 2 X " " 0 " 2 "...
Page 18 DAW-500S — TRAILER TIRES & SUSPENSION Tires/Wheels/Lug Nuts Tires and wheels are a very important and critical components of the trailer. When specifying or replacing the trailer wheels it is important the wheels, tires, and axle are properly matched. CAUTION: DO NOT attempt to repair or modify a wheel.
Page 19 DAW-500S — TRAILER TIRES & SUSPENSION e r i e t I - . t ) . s " 8 / " 6 " 2 / SHACKLE BOLT SNUG FIT ONLY PARTS MUST ROTATE FREELY SPRING EYE BOLT LOCKING NUTS OR COTTER PINS ARE PROVIDED TO RETAIN NUT BOLT ASSEMBLY SHOULDER TYPE...
Page 20 DAW-500S — TRAILER WIRING DIAGRAMS NOTE: LIGHTS ARE ORIENTED FROM THE DRIVER’S SEAT PAGE 20 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 21: Installation
DAW-500S — INSTALLATION Outdoor Installation Indoor Installation Install the welder/AC generator in a location where it will not Exhaust gases from diesel engines are extremely poisonous. be exposed to rain or sunshine. Make sure the welder/AC Whenever an engine is installed indoors the exhaust fumes generator is on secure level ground so it cannot slide or must be vented to the outside.
Page 22 DAW-500S — PRE-SETUP Fuel Lubrication Oil Fill the fuel tank with clean diesel fuel. Do not fill the tank Fill the engine crankcase with lubricating oil through the filler beyond capacity. hole, but do not overfill. Make sure the welder/AC generator is level.
Page 23 DAW-500S — PRE-SETUP CAUTION : Cleaning the Radiator The radiator may overheat if the fins become overloaded with dust or debris. Periodically clean the radiator fins with When adding coolant or antifreeze to the compressed air. Change the radiator fluid every two yearsl radiator, do not remove the radiator cap Fan Belt Tension until the unit has completely cooled.
Page 24: Instrumentation
DAW-500S — INSTRUMENTATION Idle Control Switch CAUTION : The DAW-500S Welder/AC generator is provided with an When using a combination of dual automatic idle (engine) control capability for noise receptacles, total load should not exceed suppression and fuel cost reduction. The automatic idle the rated capacity of the welder/AC control feature automatically engages under a no-load generator set.
Page 25: Load Application
DAW-500S — LOAD APPLICATION Single Phase Load CAUTION: Always be sure to check the nameplate on the welder/AC Motors and motor-driven equipment draw generator and equipment to insure the wattage, amperage much greater current for starting than and frequency requirements are satisfactorily supplied by during operation.
Page 26: Welder Operating Instructions
DAW-500S— WELDER OPERATING INSTRUCTIONS Welding Cables and Polarities NOTE Connect the welding cables (Figure 8) to the welder's output ALWAYS attach terminal connectors at terminals located on the control panel. The output terminals the end of each cable. NEVER connect have (+) and (-) polarities.
Page 27 DAW-500S— WELDER OPERATING INSTRUCTIONS CC Mode (for stick) CAUTION : This mode is for use of welding sticks. Use the current regulator to adjust the feeding speed. See Table 11 for maximum current range in relevant to electrode size. Never turn Main or Sub Welding CV/CC Selector Switch while using welder.
Page 28 DAW-500S — WELDER/GENERATOR USE Ground Welding Cable The nut and ground terminal on the welder/AC generator When welding, use the table below (Table 12) to measure should always be used to connect to a suitable ground. The the optimum amount of voltage and amperes when selecting ground path should be of #8 size wire.
Page 29 DAW-500S— WELDER/GENERATOR USE 2. Correct Current Duty Cycle If current on equipment is too high or too low, you are The welder is rated at 100% duty cycle at 350 amps. Duty certain to be disappointed in your weld. If too high, the Cycle refers to the amount of time the user can weld and electrode melts too fast and your molten pool is large and how long the machine must rest.
Page 30: Engine Operating Instructions
DAW-500S — ENGINE OPERATING INSTRUCTIONS WARNING: Starting 1. Turn the fuel cock lever to the “ON” position (Figure 10). The engine's exhaust contains harmful emissions. ALWAYS ventilate the exhaust when operating inside tunnels, excavations or buildings. Direct exhaust away from nearby personnel. Before Starting 1.
Page 31 DAW-500S — ENGINE OPERATING INSTRUCTIONS 7. When the engine starts, the oil pressure light and charge light should go out. If these lights stay on, immediately stop the engine and check the system and wiring (refer to the Kubota Engine Operator's Manual). 8.
Page 32 DAW-500S — MAINTENANCE General Inspection the drain cock and drain the contents. During cold weather, the more empty volume inside the tank, the easier it is for Prior to each use, the generator should be cleaned and water to condense. This can be reduced by keeping the inspected for deficiencies.
Page 33 DAW-500S — MAINTENANCE CAUTION : ! Apply fuel oil thinly over the gasket and hand-tighten the cartridge into position. ! Vent any air. Allow engine to cool when flushing out radiator. Flushing the radiator while hot Flushing Out Radiator and Replacing Coolant will damage engine and radiator.
Page 34: Generator Wiring Diagram
DAW-500S —GENERATOR WIRING DIAGRAM PAGE 34 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 35: Engine Wiring Diagram
DAW-500S —ENGINE WIRING DIAGRAM DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 35...
Page 36: Troubleshooting Welder
DAW-500S — TROUBLESHOOTING (WELDER) diagnosis based on the Welder Troubleshooting (Table 15) Practically all breakdowns can be prevented by proper information shown below . If the problem cannot be remedied, handling and maintenance inspections, but in the event of a please leave the unit just as it is and consult our company's breakdown, please take a remedial action following the business office or service plant.
Page 37: Troubleshooting (Engine)
DAW-500S — TROUBLESHOOTING (ENGINE) diagnosis based on the Engine and Generator Troubleshooting Practically all breakdowns can be prevented by proper (Table 16) information shown below and on the proceeding handling and maintenance inspections, but in the event of a page. If the problem cannot be remedied, please leave the breakdown, please take a remedial action following the unit just as it is and consult our company's business office or service plant.
Page 38 DAW-500S — TROUBLESHOOTING (ENGINE) l i f r e t o l c t r i r i A e l c . t u i t c i n i i t c c a l f l a i t c i t u l .
Page 39 DAW-500S — TROUBLESHOOTING (ENGINE) - e r r i c ? t i - e r r i c . t i s l i r a t r a t r e t . l e e v i n i r n i r i a r...
Page 40 EXPLANATION OF CODE IN REMARKS COLUMN How to read the marks and remarks used in this parts book. Items Found In the “Remarks” Column Serial Numbers-Where indicated, this indicates a serial number range (inclusive) where a particular part is used. Model Number-Where indicated, this shows that the corresponding part is utilized only with this specific model number or model number variant.
Page 41: Suggested Spare Parts
DAW-500S — SUGGESTED SPARE PARTS DAW-500S W/KUBOTA D1703-EB DIESEL ENGINE 1 TO 3 UNITS Qty. Description 5 .... 7000011081 ..AIR FILTER 5 .... 1552143160 ..FUEL FILTER 5 .... 7000032091 ..OIL FILTER 2 .... 1711297010 ..FAN BELT 1 ....
Page 42 DAW-500S — GENERATOR ASSY. GENERATOR ASSY. PAGE 42 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 43 DAW-500S — GENERATOR ASSY. GENERATOR ASSY. PART NO PART NAME QTY. REMARKS D6110000202 ROTOR ASSY. 0340010045 HEX. HEAD BOLT 030210250 LOCK WASHER ......6 ....REPLACES 0042510000 D6130200103 STATOR ASSY. 0012110120 HEX. HEAD BOLT 030210250 LOCK WASHER ......6 ....REPLACES 0042510000 031110160 PLAIN WASHER ......6 ....
Page 44 DAW-500S — CONTROL PANEL ASSY. CONTROL PANEL ASSY. PAGE 44 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 45: Control Panel Assembly
DAW-500S — CONTROL PANEL ASSY. CONTROL PANEL ASSY. PART NO PART NAME QTY. REMARKS D6225000603 CONTROL PANEL 0021806030 MACHINE SCREW 0601803071 WELDING MAIN SELECTOR ......1 .... SK2533MS 8705945004 SEAL 0016906016 HEX. HEAD BOLT 0601830704 WELDING SUB SELECTOR ......1 .... S7B 0601840214 RHEOSTAT (CURRENT AND VOLT.
Page 46 DAW-500S — ELECTRIC PARTS (1) ASSY. ELECTRIC PARTS (1) ASSY. PAGE 46 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 47 DAW-500S — ELECTRIC PARTS (1) ASSY. ELECTRIC PARTS (1) ASSY. PART NO PART NAME QTY. REMARKS D6353600133 SET PANEL, ELEC. PARTS ..1 0017406016 HEX.HEAD BOLT 0601842464 RESISTOR 0027104016 MACHINE SCREW 0601827619 RELAY ........1 ... G7L2ABUBDC12V 0027104016 MACHINE SCREW 0601821391 RECTIFIER .......
Page 48 DAW-500S — ELECTRIC PARTS (2) ASSY. ELECTRIC PARTS (2) ASSY. PAGE 48 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 49 DAW-500S — ELECTRIC PARTS (2) ASSY. ELECTRIC PARTS (2) ASSY. PART NO PART NAME QTY. REMARKS D6215000413 BOX, ELECT. PARTS ....1 ..UP TO S/N5428475 D6215000423 BOX, ELECT. PARTS ....1 ..S/N5428476~ D9925800104 DC CONTROL UNIT ASSY..1 ..CA50 D9925800184 AC CONTROL UNIT ASSY.
Page 50 DAW-500S — ENGINE & RADIATOR ASSY. ENGINE & RADIATOR ASSY. PAGE 50 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 51 DAW-500S — ENGINE & RADIATOR ASSY. ENGINE & RADIATOR ASSY. PART NO PART NAME QTY. REMARKS D692520034 ENGINE ........1 .... KUBOTA D1703 7000032091 CARTRIDGE, OIL FILTER ... 1 .... REPLACES 0602041173 D6305200104 ENGINE FOOT D6305200004 ENGINE FOOT D6133100104 ENGINE FOOT D6133100004 ENGINE FOOT 012212025...
Page 52 DAW-500S — BATTERY ASSY. BATTERY ASSY. PAGE 52 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 53 DAW-500S — BATTERY ASSY. BATTERY ASSY. PART NO PART NAME QTY. REMARKS 0167306531 BATTERY ........1 ..65D31R 7612251004 BATTERY SHEET D6345200004 BATTERY BAND 1742251004 BATTERY BOLT 0037806000 WING NUT 0040006000 LOCK WASHER 952404470 PLAIN WASHER ......2 ..REPLACES 0041206000 0602220310 TERMINAL ASSY.
Page 54 DAW-500S — MUFFLER ASSY. MUFFLER ASSY. PAGE 54 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 55 DAW-500S — MUFFLER ASSY. MUFFLER ASSY. PART NO PART NAME QTY. REMARKS D6332000322 MUFFLER 0017108020 HEX. HEAD BOLT D6335000523 EXHAUST PIPE 1526312370 GASKET ........1 ..REPLACES 0602320153 1502336004 GASKET 0207008000 HEX. NUT 0017108035 HEX. HEAD BOLT 0130012000 ELBOW JOINT DAW-500S WELDER/A.C.
Page 56 DAW-500S — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 56 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 57: Fuel Tank Assembly
DAW-500S — FUEL TANK ASSY. FUEL TANK ASSY. PART NO PART NAME QTY. REMARKS B6365000423 FUEL TANK 0810105900 CAP, FUEL TANK ....... 1 ..REPLACES 0810105800 E1924300164 SENDER, FUEL GAUGE 0022905015 MACHINE SCREW D6365300613 BRACKET, FUEL TANK 0017108020 HEX. HEAD BOLT 1555527004 TANK SHEET D6492700104...
Page 58 DAW-500S — ENCLOSURE ASSY. ENCLOSURE ASSY PAGE 58 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 59 DAW-500S — ENCLOSURE ASSY. ENCLOSURE ASSY. PART NO PART NAME QTY. REMARKS D6415000722 BASE D6492100104 RUBBER SHEET 0221700150 RUBBER SEAL 0221700365 RUBBER SEAL D6415100104 FLOOR PANEL 0017106016 HEX. HEAD BOLT D6455200603 SPLASHER PANEL D6455200713 SPLASHER PANEL D6415500003 GUIDE 0017106016 HEX. HEAD BOLT D6425000832 FRONT FRAME 0221900410...
Page 60: Enclosure (Rubber Seals)
DAW-500S — ENCLOSURE (RUBBER SEALS) ENCLOSURE (RUBBER SEALS) PAGE 60 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 61 DAW-500S — ENCLOSURE (RUBBER SEALS) ENCLOSURE (RUBBER SEALS) PART NO PART NAME QTY. REMARKS 0228800530 RUBBER SEAL 0221900125 RUBBER SEAL 0221600100 RUBBER SEAL 0221900410 RUBBER SEAL 0228800870 RUBBER SEAL 0228300730 RUBBER SEAL 0228300330 RUBBER SEAL 0228300755 RUBBER SEAL 0228300700 RUBBER SEAL DAW-500S WELDER/A.C.
Page 62: Nameplate And Decals
DAW-500S — NAMEPLATE AND DECALS NAMEPLATE AND DECALS PAGE 62 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 63 DECAL; PROP 65 WARNING ..... 1 ..D92210020 0820650604 DECAL; DANGER EXPLOSIVE GASES 8700625504 DECAL; FUSE BOX D2562200004 DECAL; WHISPERWELD D2562200104 DECAL; MQ POWER D5562100002 STRIPE D5562100102 STRIPE DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 63...
Page 64: Kubota D1703-Eb Engine
KUBOTA D1703-EB ENGINE — CRANKCASE ASSY. CRANKCASE ASSY. PAGE 64 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 65 KUBOTA D1703-EB ENGINE — CRANKCASE ASSY. CRANKCASE ASSY. PART NO PART NAME QTY. REMARKS 1K33201010 CRANKCASE COMP..... 1 ..INCL. ITEMS W/# 020# 1552196020 PLUG 025# 1669196020 PLUG 030# 1552196030 PLUG 040# 1739196160 PLUG, EXPANSION 050# 0631175045 PLUG, EXPANSION 060# 1522103383 SEALING CAP ......
Page 66 KUBOTA D1703-EB ENGINE — OIL PAN ASSY. OIL PAN ASSY. PAGE 66 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 67: Oil Pan Assembly
KUBOTA D1703-EB ENGINE — OIL PAN ASSY. OIL PAN ASSY. PART NO PART NAME QTY. REMARKS 1929901613 OIL PAN 1531301620 GASKET, OIL PAN 1733391010 FLANGE BOLT 1522133750 PLUG 7000065259 GASKET ........1 ..REPLACES 1510933660 1595133750 DRAIN PLUG 0472400160 GASKET 1562832110 OIL FILTER 0112360814...
Page 68 KUBOTA D1703-EB ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. PAGE 68 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 69 KUBOTA D1703-EB ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. PART NO PART NAME QTY. REMARKS 1522101750 ENGINE HOOK 1641501752 ENGINE HOOK 0112360816 BOLT 1547191530 STUD 0215650080 0451260080 LOCK WASHER 0401250080 PLAIN WASHER 1644403040 CYLINDER HEAD COMP... 1 ... INCL. ITEMS W/# 090# 1522103370 SEALING CAP...
Page 70 KUBOTA D1703-EB ENGINE — GEAR CASE ASSY. GEAR CASE ASSY. PAGE 70 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 71 KUBOTA D1703-EB ENGINE — GEAR CASE ASSY. GEAR CASE ASSY. PART NO PART NAME QTY. REMARKS 1749004012 GEAR CASE ASSY......1 ..INCL. ITEMS W/# 020# 1685196010 PLUG 030# 0481400150 O RING 035# 0481100200 O RING 040# 0481400360 O RING 050# 1522156280 START SPRING PIN...
Page 72 KUBOTA D1703-EB ENGINE — HEAD COVER ASSY. HEAD COVER ASSY. PAGE 72 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 73: Head Cover Assembly
KUBOTA D1703-EB ENGINE — HEAD COVER ASSY. HEAD COVER ASSY. PART NO PART NAME QTY. REMARKS 1718214510 HEAD COVER 1552114520 HEAD COVER GASKET 1718205020 BREATHER COMP. 1711405130 BREATHER GASKET 0112350840 BOLT 1624105670 BREATHER ELEMENT 1718214490 PLATE 1718205510 BREATHER TUBE 0931888200 HOSE CLAMP 1545192330 CAP NUT...
Page 74 KUBOTA D1703-EB ENGINE — OIL FILTER ASSY. OIL FILTER ASSY. PAGE 74 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 75 KUBOTA D1703-EB ENGINE — OIL FILTER ASSY. OIL FILTER ASSY. PART NO PART NAME QTY. REMARKS 700032091 CARTRIDGE, OIL FILTER ....1..REPLACES 1732132430 DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 75...
Page 76 KUBOTA D1703-EB ENGINE — DIPSTICK & GUIDE ASSY. DIPSTICK & GUIDE ASSY. PAGE 76 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 77 KUBOTA D1703-EB ENGINE — DIPSTICK & GUIDE ASSY. DIPSTICK & GUIDE ASSY. PART NO PART NAME QTY. REMARKS 1711136410 GAUGE, OIL DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 77...
Page 78 KUBOTA D1703-EB ENGINE — OIL PUMP ASSY. OIL PUMP ASSY. PAGE 78 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 79 KUBOTA D1703-EB ENGINE — OIL PUMP ASSY. OIL PUMP ASSY. PART NO PART NAME QTY. REMARKS 1547135012 OIL PUMP ASSY. 1529635150 OIL PUMP GASKET 0105350650 BOLT 0451260060 LOCK WASHER 1920235660 OIL PUMP DRIVE GEAR 0571200410 FEATHER KEY 1522135682 FLANGE NUT DAW-500S WELDER/A.C.
Page 80 KUBOTA D1703-EB ENGINE — MAIN BEARING CASE ASSY. MAIN BEARING CASE ASSY. PAGE 80 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 81 KUBOTA D1703-EB ENGINE — MAIN BEARING CASE ASSY. MAIN BEARING CASE ASSY. PART NO PART NAME QTY. REMARKS 1901307090 BEARING WHEEL CASE ASSY....1 ....INCL. ITEMS W/# 020# 1901304090 MAIN BEARING CASE ASSY. 030# 1901304540 BEARING CASE BOLT 1907704360 BEARING CASE GASKET 1901304813...
Page 82 KUBOTA D1703-EB ENGINE — CAMSHAFT & IDLE GEAR ASSY. CAMSHAFT & IDLE GEAR SHAFT ASSY. PAGE 82 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 83 KUBOTA D1703-EB ENGINE — CAMSHAFT & IDLE GEAR ASSY. CAMSHAFT & IDLE GEAR SHAFT ASSY. PART NO PART NAME QTY. REMARKS 1560115550 TAPPET 1901315110 PUSH ROD 1733316010 CAMSHAFT ASSY...... 1 ... INCL. ITEMS W/# 040# 1733316150 CAMSHAFT 050# 1552193610 SET SCREW 060# 1552116510...
Page 84 KUBOTA D1703-EB ENGINE — PISTON & CRANKSHAFT ASSY. PISTON & CRANKSHAFT ASSY. PAGE 84 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 85 KUBOTA D1703-EB ENGINE — PISTON & CRANKSHAFT ASSY. PISTON & CRANKSHAFT ASSY. PART NO PART NAME QTY. REMARKS 1642321110 PISTON ..........3... STD. 1642321910 PISTON ..........3... +0.50MM 1733121050 PISTON RING ASSY......3... STD. 1733121090 PISTON RING ASSY......2... +0.50MM 1490121310 PISTON PIN 1410921330...
Page 86 KUBOTA D1703-EB ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PAGE 86 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 87 KUBOTA D1703-EB ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PART NO PART NAME QTY. REMARKS 1K33225010 FLYWHEEL COMP..... 1 ..... INCL. ITEM W/# 020# 1522163820 RING GEAR 1532125163 FLYWHEEL BOLT 1K33204610 FLYWHEEL HOUSING 3122014172 COVER ........1 ..... REPLACES 3122014170 0115350812 BOLT 0451290080...
Page 88 KUBOTA D1703-EB ENGINE — FUEL CAMSHAFT & GOV. SHAFT ASSY. FUEL CAMSHAFT & GOVERNOR SHAFT ASSY. PAGE 88 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 89 KUBOTA D1703-EB ENGINE — FUEL CAMSHAFT & GOV. SHAFT ASSY. FUEL CAMSHAFT & GOVERNOR SHAFT ASSY. PART NO PART NAME QTY. REMARKS 1642716020 FUEL CAMSHAFT ASSY....1 ..INCL. ITEMS W/# 020# 1642716173 FUEL CAMSHAFT 030# 0815306205 BALL BEARING 040# 1641551150 INJECTION PUMP GEAR 050#...
Page 90 KUBOTA D1703-EB ENGINE — ENGINE STOP LEVER ASSY. ENGINE STOP LEVER ASSY. PAGE 90 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 91 KUBOTA D1703-EB ENGINE — ENGINE STOP LEVER ASSY. ENGINE STOP LEVER ASSY. PART NO PART NAME QTY. REMARKS 1552154090 IDLING APPARATUS ....1 ... INCL. ITEMS W/# 020# 1552154100 ADJUSTING BOLT ASSY. 030# 1540192010 040# 1552192330 CAP NUT 050# 1502133660 GASKET 060# 1552154270...
Page 92 KUBOTA D1703-EB ENGINE — STOP SOLENOID ASSY. STOP SOLENOID ASSY. PAGE 92 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 93 KUBOTA D1703-EB ENGINE — STOP SOLENOID ASSY. STOP SOLENOID ASSY. PART NO PART NAME QTY. REMARKS 1749060010 SOLENOID ASSY. 1666160150 SOLENOID GASKET COVER 1522188210 STUD 0205650060 0451260060 LOCK WASHER 166167580 CORD CLAMP DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 93...
Page 94 KUBOTA D1703-EB ENGINE — INJECTION PUMP ASSY. INJECTION PUMP ASSY. PAGE 94 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 95 KUBOTA D1703-EB ENGINE — INJECTION PUMP ASSY. INJECTION PUMP ASSY. PART NO PART NAME QTY. REMARKS 1G70251010 INJECTION PUMP ASSY.... 1 ... INCL. ITEM W/# 020# 1641452090 INJ. PUMP SHIM,0.20MM 1641452110 INJ. PUMP SHIM,0.25MM 1641452120 INJ. PUMP SHIM,0.30MM 011008020 BOLT ...........
Page 96 KUBOTA D1703-EB ENGINE — INJECTION PUMP COMP. ASSY. INJECTION PUMP COMP. ASSY. PAGE 96 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 97 KUBOTA D1703-EB ENGINE—INJECTION PUMP COMP. ASSY. INJECTION PUMP COMP. ASSY. PART NO PART NAME QTY. REMARKS 1G70251010 INJECTION PUMP ASSY..... 1 ..INCL. ITEMS W/# 020# 1647551050 PUMP PLUNGER 030# 1647551030 DELIVERY VALVE 040# 1647551230 DELIVERY VALVE SPRING 050# 1522151240 DELIVERY VALVE GASKET 060#...
Page 98 KUBOTA D1703-EB ENGINE — GOVERNOR ASSY. GOVERNOR ASSY. PAGE 98 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 99 KUBOTA D1703-EB ENGINE —GOVERNOR ASSY. GOVERNOR ASSY. PART NO PART NAME QTY. REMARKS 1666156020 GOVERNOR LEVER ASSY. 1909017830 FORK LEVER ASSY..... 1 ....INCL. ITEMS W/# 030# 1560156130 FORK LEVER 040# 1522156150 FORK LEVER SHAFT 050# 1624194010 PLAIN WASHER 060# 1502156240 LEVER SHAFT BOLT...
Page 100 KUBOTA D1703-EB ENGINE — SPEED CONTROL PLATE ASSY. SPEED CONTROL PLATE ASSY. PAGE 100 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 101: Speed Control Plate Assembly
KUBOTA D1703-EB ENGINE — SPEED CONTROL PLATE ASSY. SPEED CONTROL PLATE ASSY. PART NO PART NAME QTY. REMARKS 1560154120 ADJUSTING BOLT 1560192012 1560196650 GASKET 1584114620 CAP NUT 1622154420 1547157150 SPEED CONTROL LEVER 0571200408 FEATHER KEY 0481100120 O RING 0401360080 PLAIN WASHER 0211250080 1552157240 COLLAR...
Page 102 KUBOTA D1703-EB ENGINE — NOZZLE HOLDER & GLOW ASSY. NOZZLE HOLDER & GLOW PLUG ASSY. PAGE 102 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 103 KUBOTA D1703-EB ENGINE — NOZZLE HOLDER & GLOW ASSY. NOZZLE HOLDER & GLOW PLUG ASSY. PART NO PART NAME QTY. REMARKS 1646742502 OVERFLOW PIPE ASSY. 1733142500 OVERFLOW PIPE ASSY..... 1 ..INCL. ITEMS W/# 030# 1024442320 PIPE CLIP 040# 1497142750 PIPE CLIP 1608253900...
Page 104 KUBOTA D1703-EB ENGINE — NOZZLE HOLDER ASSY. NOZZLE HOLDER ASSY. PAGE 104 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 105 KUBOTA D1703-EB ENGINE — NOZZLE HOLDER ASSY. NOZZLE HOLDER ASSY. PART NO PART NAME QTY. REMARKS 1608253900 ASSY. HOLDER, NOZZLE ....3 ... INCLUDES ITEMS W/ 1584192030 1584153230 WASHER, ADJUSTING 1584153170 SPRING, NOZZLE 1584153350 PIECE, DISTANCE 1584153160 PUSH ROD 1647553280 NUT, NOZZLE 1584194040 WASHER...
Page 106 KUBOTA D1703-EB ENGINE — FUEL FILTER ASSY. FUEL FILTER ASSY PAGE 106 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 107 KUBOTA D1703-EB ENGINE — FUEL FILTER ASSY. FUEL FILTER ASSY PART NO PART NAME QTY. REMARKS 1707643012 FUEL FILTER ASSY....1 ... INCL. ITEMS W/# 030# 1552143522 FILTER HANDLE 040# 1552143672 GASKET 050# 1552143552 HANDLE RETAINER 060# 1552143542 THRUST PLATE 070# 0481110290 O RING...
Page 108 KUBOTA D1703-EB ENGINE — FUEL PUMP ASSY. FUEL PUMP ASSY. PAGE 108 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 109 KUBOTA D1703-EB ENGINE — FUEL PUMP ASSY. FUEL PUMP ASSY. PART NO PART NAME QTY. REMARKS 1712152030 FUEL PUMP ASSY....1 ..INCL. ITEM W/# 020# 1984452040 DIAPHRAGM COMP. 1526352140 FUEL PUMP GASKET 0102350616 BOLT DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 109...
Page 110 KUBOTA D1703-EB ENGINE — ALTERNATOR & PULLEY ASSY. ALTERNATOR & PULLEY ASSY. PAGE 110 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 111 KUBOTA D1703-EB ENGINE — ALTERNATOR & PULLEY ASSY. ALTERNATOR & PULLEY ASSY. PART NO PART NAME QTY. REMARKS 1640464010 ALTERNATOR ASSY. 0117351000 BOLT 0401150100 PLAIN WASHER 0215650100 0451260100 LOCK WASHER 0115360830 BOLT 0401560080 PLAIN WASHER 0451290080 LOCK WASHER ....... 1 ....REPLACES 0451260080 0205650060 0451260060 LOCK WASHER...
Page 112 KUBOTA D1703-EB ENGINE —ALTERNATOR COMP. ASSY. ALTERNATOR COMP. ASSY. PAGE 112 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 113 KUBOTA D1703-EB ENGINE — ALTERNATOR COMP. ASSY. ALTERNATOR COMP. ASSY. PART NO PART NAME QTY. REMARKS 1640464010 ALTERNATOR ASSY....1 .... 12V 40A; INCL. ITEMS W/# 020# 1642764110 ALTERNATOR PULLEY 030# 1588192010 040# 1588164150 COLLAR 050# 6643664040 ROTOR ASSY......1 .... INCL. ITEMS W/% 060#% 1588164800 BEARING COVER...
Page 114 KUBOTA D1703-EB ENGINE — STARTER ASSY. STARTER ASSY. PAGE 114 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 115 KUBOTA D1703-EB ENGINE — STARTER ASSY. STARTER ASSY. PART NO PART NAME QTY. REMARKS 1729863010 STARTER ASSY......1 ..12V 1.4KW 0151751028 STUD 0113351030 BOLT 0217650100 0451260100 LOCK WASHER 0211450080 0451290080 LOCK WASHER ......1 ..REPLACES 0451260080 DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 115...
Page 116 KUBOTA D1703-EB ENGINE — STARTER COMP. ASSY. STARTER COMP. ASSY. PAGE 116 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 117 KUBOTA D1703-EB ENGINE — STARTER COMP. ASSY. STARTER COMP. ASSY. PART NO PART NAME QTY. REMARKS 1729863010 STARTER ASSY......1 ... 12V 1.4KW; INCL. ITEMS W/# 020# 1119763080 YOKE ASSY. 030# 1119763070 ARMATURE ASSY.......1 ... INCL. ITEMS W% 040#% 1146063500 BEARING...
Page 118 KUBOTA D1703-EB ENGINE — OIL SWITCH ASSY. OIL SWITCH ASSY. PAGE 118 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 119 KUBOTA D1703-EB ENGINE — OIL SWITCH ASSY. OIL SWITCH ASSY. PART NO PART NAME QTY. REMARKS 0631155010 PLUG 0471701000 WASHER, W/RUBBER 1584139010 OIL SWITCH DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 119...
Page 120 KUBOTA D1703-EB ENGINE — WATER FLANGE & THERMOSTAT ASSY. WATER FLANGE & THERMOSTAT ASSY. PAGE 120 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 121 KUBOTA D1703-EB ENGINE — WATER FLANGE & THERMOSTAT ASSY. WATER FLANGE & THERMOSTAT ASSY. PART NO PART NAME QTY. REMARKS 1746272702 WATER FLANGE COMP. 1733173342 WATER RETURN PIPE 1576672920 WATER FLANGE GASKET 0112350820 BOLT 1522191530 STUD 0115350870 BOLT 0215650080 0451290080 LOCK WASHER ......
Page 122 KUBOTA D1703-EB ENGINE — WATER PUMP ASSY. WATER PUMP ASSY. PAGE 122 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 123 KUBOTA D1703-EB ENGINE — WATER PUMP ASSY. WATER PUMP ASSY. PART NO PART NAME QTY. REMARKS 1552173033 WATER PUMP ASSY....1 ..INCL. ITEMS W/# 020# 1552173550 BEARING 030# 1666173510 IMPELLER 040# 1666173050 MECHANICAL SEAL ASSY. 050# 1552173520 WATER PUMP FLANGE 1576673430 WATER PUMP GASKET 0112350828...
Page 124 KUBOTA D1703-EB ENGINE — FAN ASSY. FAN ASSY. PAGE 124 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 125 KUBOTA D1703-EB ENGINE — FAN ASSY. FAN ASSY. PART NO PART NAME QTY. REMARKS 1K33274110 1544974150 FAN COLLAR 0175450655 FLANGE BOLT 1735174250 FAN PULLEY DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 125...
Page 126 KUBOTA D1703-EB ENGINE — VALVE & ROCKER ARM ASSY. VALVE & ROCKER ARM ASSY. PAGE 126 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 127 KUBOTA D1703-EB ENGINE — VALVE & ROCKER ARM ASSY. VALVE & ROCKER ARM ASSY. PART NO PART NAME QTY. REMARKS 1648413310 INLET VALVE 1648413120 EXHAUST VALVE 1522113240 VALVE SPRING 1522113330 VALVE SPRING RETAINER 1522113360 VALVE SPRING COLLET 1522113150 VALVE STEM SEAL 1522113280 VALVE CAP 1532114052...
Page 128 KUBOTA D1703-EB ENGINE — INLET MANIFOLD ASSY. INLET MANIFOLD ASSY. PAGE 128 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 129 KUBOTA D1703-EB ENGINE — INLET MANIFOLD ASSY. INLET MANIFOLD ASSY. PART NO PART NAME QTY. REMARKS 1718211760 INLET MANIFOLD 1718205550 BREATHER JOINT 1732611820 INLET MANIFOLD GASKET 011008020 BOLT ........... 5 ... REPLACES 0112350822 DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 129...
Page 130 KUBOTA D1703-EB ENGINE — EXHAUST MANIFOLD ASSY. EXHAUST MANIFOLD ASSY. PAGE 130 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 131: Exhaust Manifold Assembly
KUBOTA D1703-EB ENGINE — EXHAUST MANIFOLD ASSY. EXHAUST MANIFOLD ASSY. PART NO PART NAME QTY. REMARKS 1552112312 EXHAUST MANIFOLD 1531312350 EXHAUST MANIFOLD GASKET 1 1522191530 STUD 1642992010 0151350822 STUD DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 131...
Page 132 KUBOTA D1703-EB ENGINE — HYDRAULIC PUMP ASSY. HYDRAULIC PUMP ASSY. PAGE 132 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 133 KUBOTA D1703-EB ENGINE — HYDRAULIC PUMP ASSY. HYDRAULIC PUMP ASSY. PART NO PART NAME QTY. REMARKS 1718316210 FUEL CAMSHAFT COVER 1522516190 COLLAR 3539437860 GASKET 0461200250 EXT. CIRCULAR CLIP 0112350865 BOLT DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 133...
Page 134 KUBOTA D1703-EB ENGINE — GLOW PLUG ASSY. GLOW PLUG ASSY. PAGE 134 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 135 KUBOTA D1703-EB ENGINE — GLOW PLUG ASSY. GLOW PLUG ASSY. PART NO PART NAME QTY. REMARKS 1569465990 TIMER, GLOW LAMP 1746260600 EMERGENCY UNIT DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 135...
Page 136 KUBOTA D1703-EB ENGINE — STARTER SWITCH ASSY. STARTER SWITCH ASSY. PAGE 136 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 137 KUBOTA D1703-EB ENGINE — STARTER SWITCH ASSY. STARTER SWITCH ASSY. PART NO PART NAME QTY. REMARKS 3741059110 STARTER SWITCH ASSY.... 1 ..INCL. ITEMS W/#; REPLACES 3741059113 020# 3741059110 STARTER SWITCH ...... 1 ..REPLACES 3741059123 030# 3741059123 KEY ASSY........1 ..REPLACES 3741055151 DAW-500S WELDER/A.C.
Page 138: Accessories
KUBOTA D1703-EB ENGINE — ACCESSORIES ACCESSORIES PAGE 138 —DAW-500S WELDER/A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #0 (07/19/01)
Page 139 KUBOTA D1703-EB ENGINE — ACCESSORIES ACCESSORIES PART NO PART NAME QTY. REMARKS 1526312370 MUFFLER GASKET 0966180300 FUEL TUBING 0966180180 FUEL TUBING 0966140280 FUEL TUBING 0966140170 FUEL TUBING 0631210010 PLUG 1644487112 ENGINE NAME PLATE DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 139...
Page 140: Terms And Conditions Of Sale - Parts
TERMS AND CONDITIONS OF SALE — PARTS Effective: July 1, 2000 PAYMENT TERMS Freight is at the sender’s expense. All PRICING AND REBATES parts must be returned freight prepaid to Terms of payment for parts are net 10 days. Prices are subject to change without prior Multiquip’s designated receiving point.
Page 141 NOTE PAGE DAW-500S WELDER/A.C. GENERATOR — PARTS & OPERATION MANUAL — REV.#0 (07/19/01) — PAGE 141...
Page 142 SERVICE DEPARTMENT 800/835-2551 or 310/537-3700 FAX: 310/638-8046 WARRANTY DEPARTMENT 800/835-2551 or 310/537-3700 FAX: 310/638-8046 MAIN 800/421-1244 or 310/537-3700 FAX: 310/537-3927 Manufactured for MQ Power DENYO CO., LTD. JAPAN MULTIQUIP INC. 18910 WILMINGTON AVE. CARSON, CALIFORNIA 90746 310-537-3700 800-421-1244 FAX: 310-537-3927 •...
