Samsung SGH-B200 User Manual

SGH-B200
User's Guide
Some of the contents in this guide may differ from your phone depending on the
software of the phone or your service provider.
Printed in Korea
World Wide Web Code No.:GH68-18702A
http://www.samsungmobile.com English (CIS). 04/2008. Rev. 1.0
Press and hold in Idle mode to disable all sounds on the
Silent mode
phone. To exit, press and hold this key again.
Press C 4 times in Idle mode with the keypad locked to send
SOS mode
an SOS message to preset phone numbers. Once the SOS
message is sent, the phone will change to SOS mode and will
receive calls only from the registered recipients. Upon
receiving a call from the SOS message recipients, the phone
will automatically answer the call. Press to exit SOS
mode.
Press and hold in Idle mode to lock the keypad and ignore
Keypad lock
mode accidental key pressing. To unlock, press Unlock and then
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Icons
Text and graphics
Soft key function
Menu Phonebook
indicators

Using the menus

In Idle mode, press the Menu soft key to enter the main menu.
Labels at the bottom corners of the display
show the current soft key functions. Press
the left soft key or right soft key to perform
the function indicated.
To return to the To exit this menu
previous menu without changing
level, press the the menu settings,
soft key or C. press this key.
Use the 4-way navigation keys as shortcuts
to access your favourite menus.
1. In Idle mode, press the Menu soft key.
2. Select Phone settings → Shortcuts.
3. Select a key.
4. Select a menu to be assigned to the key.

Installing the SIM card and battery

1. Remove the battery cover and insert the SIM card.
Battery
cover
2. Install the battery and reattach the battery cover.
Battery
Your phone displays the following status indicators on the top of the
screen:
Icon Description
Signal strength
Call in progress
GPRS network
Roaming network
Call ringer set to vibrate
.
Silent mode
Mute mode, during a call
Call diverting feature active
SOS message feature active
New text message
New multimedia message
New voice mail message
Keys locked
Alarm set
Battery power level
To select or modify a menu or feature:
1. In Idle mode, press the Menu soft key.
2. Press the Navigation keys to reach a desired menu and then press
the Select soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the Select soft key or
enter the submenu.
If the selected menu contains additional submenus, repeat this
step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the Select soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu
mode.

Charging the battery

1. Plug the supplied travel adapter.
With the triangle facing up
2. When charging is finished, unplug the travel adapter.
Note: Do not remove the battery from the phone without unplugging the
travel adapter first. Otherwise, the phone may be damaged.

Switching on or off the phone

1. Press and hold for more than one second to switch on the phone.
2. If the time & date message appears, press the
the time and date by following the onscreen instructions.
3. Press and hold for more than two seconds to switch off the phone.

Changing the display language

1. In Idle mode, press the Menu soft key.
2. Select Phone settings → Language.
3. Select a language.

Making a call

1. In Idle mode, enter an area code and phone number, and press
2. Press to end the call.

Answering a call

1. When the phone rings, press the Accept soft key or
call.
Press the Reject soft key or to reject the call.
2. Press to end the call.
Menu map
1. SIM AT * 4.7 Alert on call
4.8 Power on/off
2. Call records 4.9 Extra tones
2.1 Missed calls
5. Messages
2.2 Received calls
5.1 Text messages
2.3 Dialled calls
2.4 Delete all 5.2 Multimedia messages
2.5 Call time 5.3 Push messages
5.4 Configuration
2.6 Call cost *
to
messages
3. Network services 5.5 SOS messages
3.1 Call diverting
6. Funbox
3.2 Call barring
6.1 WAP browser
3.3 Call waiting
3.4 Network selection 6.2 FM Radio
3.5 Caller ID 6.3 Games
6.4 Sounds
3.6 Closed user group
6.5 Images
4. Sound settings
6.6 Delete all
6.7 Memory status
4.1 Ring tone
4.2 Ring volume
7. Organiser
4.3 Alert type
7.1 Alarm
4.4 Keypad tone
4.5 Keypad volume 7.2 Calendar
4.6 Message tone 7.3 Time & Date
7.4 Calculator

Phone layout and key functions

Web access/
Confirm key
In Idle mode, accesses
the web browser.
In Menu mode, selects
the highlighted option
or confirms input.
Soft keys
Perform functions
indicated by the
text above the key.
Dial key
Makes and answers
a call. In Idle mode,
retrieves the most
recent calls.
Voice mail server key
In Idle mode, accesses
your voice mail server
when held down.
Keypad lock key
Keypad lock mode
Alphanumeric keys

Adjusting the volume

1. In Idle mode, press the Menu
Yes soft key and set 2. Select Sound settings → Ring
3. Press Up or Down to adjust the volume level.
4. Press the OK soft key.
While a call is in progress, press
volume.

Changing a ringtone for calls

1. In Idle mode, press the Menu
2. Select Sound settings → Ring
3. Select a ringtone.
.

Redialling recent numbers

1. In Idle mode, press .
2. Press Up or Down to scroll to the number you want.
to answer a
3. Press to dial the number.

Entering text

Changing the text input mode
7.5 To do list
7.6 Voice memo
In a text input field, press the right soft key until the input mode indicator
7.7 Currency exchange
you want appears.
8. Phonebook
8.1 Search
T9 mode
8.2 New entry
8.3 Group search
1. Press 2 to 9 to start entering a word. Press each key once for one
8.4 Edit group
letter.
8.5 Speed dial
8.6 Delete all
The word you are entering appears on the display. It may change with
8.7 Memory status
each keypress. Finish entering the word before editing or deleting any
8.8 SDN *
keystrokes.
9. Phone settings
Example: To enter "Hello" in T9 mode, press 4, 3, 5, 5, and 6.
9.1 Display settings
9.2 Greeting message
2. To display alternative word choices, press 0.
9.3 Own number
9.4 Language
3. Press to insert a space and enter the next word.
9.5 Security
9.6 Extra settings
ABC mode
9.7 Shortcuts
9.8 Connection settings
Press the keys labelled with the letter you want once for the first letter,
9.9 Reset settings
twice for the second letter, and so on.
* Show only if supported
For example, press 2 three times to enter "C" and
by your SIM card.
"K."
4-way navigation keys
In Idle mode, access
your favourite menus
directly.
In Menu mode, scroll
through menu options.
Power/End key
Turns the phone on or
off when held down.
Also ends a call.
Cancel/Clear key
Deletes characters from
the display. Returns the
display to the previous
menu level.
Sends SOS messages
when pressed four times
with the keypad locked.
SOS mode
Silent mode key
Silent mode
soft key.
volume.
Up or Down to adjust the earpiece
soft key.
tone.
5 two times to enter
