Welcome to Allspace! You have just purchased one of the most flexible multi-configuration
systems in the world of organization. Before you start assembly, please note the many
configuration suggestions at the end of the manual.
Wall Organization System
Assembly Instructions
THIS
MANUAL
MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND UNDERSTAND ALL
CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO COULD RESULT IN SERIOUS
PERSONAL INJURY AND/OR PROPERTY DAMAGE. IF YOU SHOULD HAVE ANY QUESTIONS OR EXPERIENCE A
PROBLEM WITH YOUR PRODUCT, DO NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER
SERVICE DEPARTMENT AT 1-800-423-3598. BEFORE YOU CALL, HAVE THE FOLLOWING INFORMATION AVAILABLE:
MODEL No., DATE PURCHASED AND STORE LOCATION. AN ALLTRADE REPRESENTATIVE CAN RESOLVE YOUR
PROBLEM OVER THE PHONE. .
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
CONTAINS
IMPORTANT
INFORMATION
REGARDING
SAFETY,
OPERATION,
Advertisement
Summary of Contents for Allspace Wall Organization System
- Page 1 Welcome to Allspace! You have just purchased one of the most flexible multi-configuration systems in the world of organization. Before you start assembly, please note the many configuration suggestions at the end of the manual. Wall Organization System Assembly Instructions...
-
Page 2: Safety Warnings
SAFETY WARNINGS WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. READ ALL INSTRUCTIONS BEFORE ASSEMBLY. Follow all warnings and safety precautions. If the installation is not performed correctly, the unit could fall off the wall and cause serious injury or death. Always use appropriate safety equipment when using power and hand tools. - Page 3 COMPONENTS 450048U 450048U Component 450048C 450048HF 450075HF 450076HF Component 450048HF 450075HF 450076HF 450048C 450036-01 450036-19 24 in. Utility Track 3 in. Metal Peg Hook 450036-02 450036-21 26 in. Top Track Standard Bar Connector ✽✽ 450036-03 18.75 in. 450036-23 Vertical Standard Bike/Ladder Hook ✽✽...
-
Page 4: Installation
INSTALLATION The Allspace Wall Organization System was created to give you the amount of organization you need in whatever size space you have. Change that bare wall in the garage into rows of easily found tools. Store household items in that space above the washer. - Page 5 MOUNTING THE TOP TRACKS Now you are ready to mount the top tracks (450036-02). Remember that the insert slots in the tracks must be facing up toward the ceiling. Do not mount the track upside-down. For non-stud-direct wallboard mount, use minimum of three wall anchors (450036- 30/450036-36) per 26 inch top track.
- Page 6 Each track must have at least two stud screws or three wallboard screws securing it to the wall. Use a level to check each track as it is mounted. Step 4 FASTENING VERTICAL STANDARDS TOGETHER 450036-03 450036-21 450036-32 Step 5 Make sure that the keyholes Now it is time to attach the vertical standards.
- Page 7 MOUNTING VERTICAL STANDARDS TO TOP TRACKS 450036-02 450036-03 Step 6 Find the insert slots located on the top of the tracks (450036-02). Make sure the notch on the end of the standard (450036-03) is facing up. Line up the arms of the standard with the insert slots and care- ful push in and down.
- Page 8 MOUNTING PEGBOARD PANELS Make sure that the keyholes in both bars are facing the same direction. The round part of the keyhole should be toward the top. 450036-04 Step 8 If you want the panels to fit tightly together in double vertical panel configurations (one panel on top of the other), you must insert the bottom pegboard panels first.
- Page 9 MOUNTING THE UTILITY TRACK This set includes four utility track bars. These utility track (450036-01) can be used for hanging bikes, lad- ders, hoses and larger tools. You can mount these tracks wherever they are needed. They can be mounted between the upper and lower pegboards or they can be mounted at the bottom below the pegboards.
- Page 10 MOUNTING HOOKS, UTILITY TRAYS AND BASKETS Now you are ready to attach the various hanging accessories. The plastic hooks have a keyhole-shaped lock on the back. To hang them, simply line the lock up with one of the keyholes in the pegboard and insert.
- Page 11 PREPARING AND MOUNTING BIKE/LADDER/HOSE HOOK Before you use the bike/ladder hook (450036-23), it is necessary to release the bike hook from its Depress springs and swing out to release packing position. To do this, turn bike hook around bike hook arms. so you can see the springs inside.
- Page 12 PREPARING AND MOUNTING WIRE SHELF AND BRACKET Note: Instructions only apply for model no. 450076HF 450036-38 Figure 1 Figure 3 Figure 2 Insert top hook of shelf bracket (450036-38) into mounting slot of vertical standard (450036-03) at desired height. The bracket should be inserted at an oblique angle (See Figure 1) Rotate shelf bracket clockwise until bottom hooks slide into mounting slot of vertical standard (See Figure 2).
- Page 13 VERSATILITY Remember that your pegboard system can be adjusted to fit any space you have. Use one panel or all four, it’ s up to you. 100 in. 52 in. 49 in. 52 in. 25 in. 74 in. 49 in. 76 in.
