- Page 1 EXCLUSIVELY FOR i5000 s e r i e s BIG & TALL EXECUTIVE CHAIR 330-812 / 898-221 Made in China / Fabriqué aux Chine / Hecho en China Version 0617...
- Page 2 Parts / Pièces / Piezas Left Arm Right Arm Note: Do not use power tools. Only use the Allen Key provided. Seat Plate Seat Cushion Armrests Note : Ne pas utiliser d’outils électriques. Utiliser seulement la clé Allen (hexagonale) fournie. Back Cushion Assise Plaque du siège...
- Page 3 Step 2 Step 3 Place the Seat Cushion (B) on top of the box prior to Attach the Seat Cushion (B) to the Back Cushion (A) assembly. Align Seat Plate (D) over pre-drilled holes at a right angle. Align the metal bar of the Back on the underside of Seat Cushion (B) with black Cushion (A) over the Seat Cushion (B) as shown and connect with 4 Bolts (J3).
- Page 4 Step 4 Step 5 Attach the Right Arm (C2) to the sides of Back Attention: Please keep levers on Arms (C1 & C2) to Cushion (A) and Seat Cushion (B) with two Bolts the down position for easy assembly. with Spring Washers (J2). Then assemble the Lift the lids of the EZ cable connectors attached to Left Arm (C1) in the same way.
- Page 5 Step 6 Step 7 Pull down the metal plate of Back Cushion (A) Put the Plastic Shroud (H) over the Seat Plate (D) and attach it over to the Seat Plate (D) by using (with front of plastic shroud facing the front of seat 1 Knob (I).
- Page 6 Step 8 Step 9 Insert the Gas Lift (E) into the central hole on the Place the Arm Inserts (K & L) into arm grooves Seat Plate (D) as shown. Turn the assembled chair once all screws have been tightened. upright and push down firmly over the Gas Lift (E) until it is securely connected.
- Page 7 Step 10 Before using your Chair, ensure that all the bolts are tightened fully for safety. You can now enjoy TO ADJUST SEAT HEIGHT the comfort of your new Chair! While seated, reach under the right side of the arm to find the NOTE: Please keep the allen key and lever.
- Page 8 TO OPERATE TILT LOCKOUT TO ADJUST TILT TENSION While seated, reach under the left side of the arm to Reach under the front center of chair seat and find the lever. Pull up the lever and lean back to allow grasp the round black knob.
- Page 9 Featuring PostureSync™ Responsive Support 360˚ SWIVEL System 360˚ Seat swivel. Patented posturesync responsive support system allows the lumbar zone to flex, changing from full support to relaxed as you ROTATION DE shift your sitting position from upright to reclined. The chair can 360 DEGRÉS be locked in the upright position using the tilt lockout for constant Rotation du siège de...
- Page 10 True Innovations seating products. Limited 10 Year Product Warranty True Innovations seating products. Garantie limitée de 10 ans This limited warranty covers the original purchase of new product used for normal commercial, personal or household use. True Cette garantie limitée couvre les produits neufs utilisés dans le cadre d'applications commerciales ou domestiques normales. Innovations seating products warrants its products will be free from defects in materials and workmanship (normal wear and tear True Innovations seating products garantit ses produits contre les défauts de matériel et de main-d'oeuvre (à...
- Page 11 True Innovations seating products Garantía limitada de 10 años para el producto Esta garantía limitada cubre la adquisición original de un producto nuevo utilizado con fines comerciales, personales o domésticos normales. True Innovations seating products garantiza que sus productos estarán exentos de defectos materiales y de fabricación (a excepción de los derivados de un uso y desgaste normal) durante 10 años a partir de la fecha de compra del producto, con la salvedad de lo dispuesto a continuación.
Need help?
Do you have a question about the WorkPro Serta Icomfort i5000 Series and is the answer not in the manual?
Questions and answers
Can I buy the Arm pads for the OMX WorkPro Serta Icomfort i5000 Series
