Some of the contents in this manual may differ from your device depending on the software of the device or your service provider. World Wide Web English (EU). 03/2009. Rev. 1.0 http://www.samsungmobile.com...
using this manual This user manual has been specially designed to guide you through the functions and features of your device. To get started quickly, refer to the Quick Start Guide. Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others...
Square brackets—device keys; for example: [ ] (represents the Power key). < > Angled brackets—softkeys that control different functions at each screen; for example: <Select> (represents the Select softkey). Copyrights and trademarks Rights to all technologies and products that comprise this device are the property of their respective owners: •...
contents communication Messaging ... 2 media Contents Manager ... 6 MTV BlogUploader ... 8 Streaming Player ... 8 OnDemand ... 8 ® ® Adobe Flash Lite™ ... 8 Voice Notes ... 9 personal productivity Contacts ... 10 Calendar ... 11 Office Mobile ...
Page 6
Podcast ... 21 connectivity Use the Bluetooth wireless feature ... 22 Connect via USB ... 24 Synchronise your device ... 25 Share internet connection with a PC ... 27 Connect to the internet or your private network additional programs Games ... 30 Java ...
communication Your device allows you to send and receive many types of calls and messages over cellular networks Messaging Learn to use messaging functions. For instructions on entering text, see the Quick Start Guide. Send a multimedia message and the internet. 1.
To insert a multimedia object, press <Menu> → Add → an object type. 8. Press <Send> to send the message. Create an email account Before you can send or receive email messages, you must create an email account. 1. On the Home screen, press <Start> → <All Programs>...
4. Enter an email address in the To field or press <Menu> → Add Recipient to select a contact. The Cc and Bcc fields are located above the To field. 5. Scroll down and enter a message subject. 6. Scroll down and enter your message text. 7.
Page 10
View or save email attachments Email attachments may contain viruses that can damage your device. To protect your device, open attachments only if you trust the sender. To view an attachment, 1. From an open email, scroll to the attachment and press the Confirm key to download.
media Learn to use Contents Manager, MTV BlogUploader, Streaming Player, OnDemand, ® ® Adobe Flash Lite™, and Voice Notes. Contents Manager With Contents Manager, you can view and access all the files and folders on your device. View a photo 1.
• To set a photo as a background or caller ID image, press <Menu> → Set as → an option. • To view your photos as a slideshow, press <Menu> → Play Slide Show. Play a video 1. On the Home screen, press <Start> → <All Programs>...
MTV BlogUploader With MTV BlogUploader, you can upload photos, videos, and audio to your blog on the MTV website. For details, contact your service provider. On the Home screen, select icon MTV → MTV Blog. Streaming Player You can play streaming files on the web. 1.
To view a Flash file, 1. On the Home screen, press <Start> → <All Programs> → Accessories → Adobe Flash Lite. 2. Locate and open a folder where the Flash file is stored. 3. Scroll to the Flash file and press the Confirm key.
Contacts personal Learn to use contact cards to store personal information, such as names, phone numbers, and addresses. productivity Copy contact cards You can copy your contact cards from your Learn to use Contacts, Calendar, Office Mobile, device to your SIM card and vice versa. When Adobe Reader LE, Team manager, File Manager, you copy an Outlook contact to your SIM card, and Tasks.
Assign a speed dial number to a contact card 1. On the Home screen, press <Start> → <All Programs> → Contacts. 2. Scroll to a contact card and press the Confirm key to open it. 3. Scroll to a phone number and press <Menu>...
Change the calendar view 1. On the Home screen, press <Start> → <All Programs> → Organizer → Calendar. 2. Press the left softkey to change the calender view. Stop an event alarm When the alarm sound for a calendar event you set previously, press <Dismiss>.
Page 18
4. Scroll to a cell and press the Confirm key to select it. 5. Enter values or text and press <Done>. 6. Repeat steps 4-5 as necessary. 7. To save the workbook, press <Menu> → File → Save As... → <OK>. 8.
Open and view a PowerPoint slideshow 1. On the Home screen, press <Start> → <All Programs> → Office Mobile → PowerPoint Mobile. 2. Locate a PowerPoint file and select the file name to open it. 3. To begin the slideshow, press any softkey →...
Team manager With Team manager, you can make a team with members and send a message to them at the same time. Make a new team 1. On the Home screen, press <Start> → <All Programs> → Team manager. 2. Press <New>. 3.
Send an appointment 1. On the Home screen, press <Start> → <All Programs> → Team manager. 2. Scroll to a team. 3. Press <Menu> → Set appointment. 4. Enter appointment details. 5. When you are finished, press <Done>. 6. Select a number for a contact (if necessary).
Learn to use Internet Explorer, RSS Reader, and Internet Explorer Use Internet Explorer to browse web pages and bookmark your favourite web pages. Browse a web page Podcast. 1. On the Home screen, press <Start> → <All Programs> → Internet → Internet Explorer.
3. To close the web connection, on the Home screen, press <Start> → <All Programs> → Accessories → Data Call Manager. Scroll to the connection you want to end and press <OK>. To confirm that the connection is ended, press [ ] → Wireless Manager → Phone →...
Windows Live With Windows Live, you can stay in touch with friends and access information on the wireless web quickly. 1. On the Home screen, press <Start> → <All Programs> → Internet → Windows Live. 2. Scroll to Sign in to Windows Live and press the Confirm key.
• Transfer a file: press <Menu> → Send → a file type → a file • Record and send a voice clip: select Voice clip, record your voice clip, and then press <Send> • Switch between the contact list and chat: scroll left or right 4.
Read RSS feeds 1. On the Home screen, press <Start> → <All Programs> → Internet → RSS Reader. 2. Scroll to a feed and press <Update> to get the latest contents. 3. When the update is finished, press <Done>. 4. Press the Confirm key to select an updated feed.
Page 27
Search for a podcast 1. On the Home screen, press <Start> → <All Programs> → Internet → Podcast → Podcasts. 2. Press <Menu> → Search Podcast. 3. Enter a keyword and press <Search>. Your device searches for related reports on the internet and displays the results.
connectivity Learn to transfer data to and from your device via the Bluetooth wireless feature or the PC data cable and synchronise your device to a computer with ActiveSync. Learn to set up data or network connections for connecting to the internet or your Use the Bluetooth wireless feature You can connect with other Bluetooth-enabled...
Search for and pair with a Bluetooth-enabled device 1. On the Home screen, press <Start> → <All Programs> → Settings → More... → Connections → Bluetooth → General Settings. 2. Select Add new device... Your device will search for and display the list of Bluetooth-enabled devices.
Set up a Bluetooth COM port When you connect to a Bluetooth device supporting the Serial profile, you can establish a Bluetooth COM port. 1. On the Home screen, press <Start> → <All Programs> → Settings → More... → Connections → Bluetooth → General Settings.
Transfer files to a memory card 1. Insert a memory card (see the Quick Start Guide). 2. Change the USB connection to Mass storage (To use Mass storage, see "Connect via USB"). 3. Connect your device to a PC with the PC data cable.
Connect your device to a computer with the PC data cable 1. On the Home screen, press <Start> → <All Programs> → Settings → More... → Connections → USB. 2. Change the USB connection to ActiveSync and press <Done>. 3. Connect one end of the PC data cable to the multifunction jack on your device and the other end to the USB port on your PC.
7. Enter a user name, password, and domain address. 8. Press <Next>. 9. Select the types of data to synchronise. 10. When you are finished, press <Finish>. Change the synchronisation schedule If you routinely synchronise your data via an Exchange server, you can configure settings for both peak and off-peak schedules.
3. Select the PC connection and network connection type, and then press <Connect>. While you are connected to the internet via Internet Sharing, ActiveSync is deactivated. Connect to the internet or your private network To connect to the internet or your network and transfer data, create data and network connections.
Page 35
Set up GPRS connections 1. On the Home screen, press <Start> → <All Programs> → Settings → More... → Connections → GPRS. 2. Press <Menu> → Add to add a new connection. 3. Set the connection information (see "GPRS" for details p.
additional programs Learn to use Games, Java, World Clock, Alarms, D-Day, Calculator, Smart Converter, StopWatch, and Smart Search. Games To play games, 1. On the Home screen, press <Start> → <All Programs> → Games. 2. Select a game from the list and follow the on-screen instructions.
Launch applications 1. On the Home screen, press <Start> → <All Programs> → Games → Java → an application. 2. Press <Menu> to access a list of various options and settings for your application. World Clock With a world clock, you can monitor the time in another city or country.
Alarms Learn to set and control alarms for important events. Set a new alarm 1. On the Home screen, press <Start> → <All Programs> → Organizer → Alarms. 2. Scroll to an empty alarm location and press <Edit>. 3. Set alarm details. 4.
Smart Converter With Smart Converter, you can convert measurements or currencies from one unit to another. To convert currencies, you must first set a base currency and exchange rate. Add currencies and exchange rates The value of the base currency is always 1. You must enter exchange rates for other currencies as they relate to one unit of the base currency.
StopWatch 1. On the Home screen, press <Start> → <All Programs> → Accessories → StopWatch. 2. Press <Start> to begin the stopwatch. 3. Press <Record> to record lap times. 4. When you are finished, press <Stop>. 5. Press <Reset> to clear recorded times.
Settings Learn about your device settings. To access your device settings, On the Home screen, press <Start> → <All Programs> → Settings. To access more setting options, scroll down or select More... Phone Control how your device handles calls with caller ID, call waiting, and other call settings.
Page 42
Phone number: view your phone number Voice mail number: set the voice mail number provided by your service provider Text messages service centre: set the text message service number provided by your service provider Country code: set your country code Dialling code: set your area code •...
Block outgoing calls - Off: set to deactivate call barring - Int’l calls except to home: set to prevent international calls to countries other than your home country - Int’l calls: set to prevent calls to international numbers - All calls: set to prevent all outgoing calls •...
Page 44
Sounds • Ring Tone: set a ringtone for incoming calls • Notification Reminders: set a tone for reminders New email: set a tone for incoming email messages New text message: set a tone for incoming text messages New voice message: set a tone for incoming voice mails New instant message: set a tone for incoming instant messages...
Start Menu Style Change the start menu style. Profiles Change the sound profile (see the Quick Start Guide). Date and Time Control the appearance and behavior of the date and time. • Time zone: set the time zone • Date: set the current date •...
Page 46
• Positive currency: set how you want positive currency displayed • Negative currency: set how you want negative currency displayed Connections Control the Bluetooth wireless feature or USB connection and set up dial-up, GPRS, proxy, and VPN connections so that you can connect to the internet or your private network.
Page 47
Dial-up To set up dial-up connections, press <Menu> → Add to access the following options: • Description: set a name for the dial-up connection • Connects to: set a network type to use to connect to the internet • Phone number: enter your phone number •...
Page 48
• Connects to: set a network type to use to connect to the internet • Proxy (name:port): set a name and port number of a proxy server • Type: set a network type to use to connect to the proxy server •...
Security Set security codes and manage security certificates or security modules. • Device Lock: set a lock code for the device • Enable SIM Lock: set the device use only your SIM or USIM card; When SIM or USIM Lock is enabled, you are not able to use another SIM or USIM card on your device •...
Managed Programs View the history of the program installation. Remove Programs Remove programs you have installed on your device. Scroll to a program and press <Menu> → Remove. Power Management • Battery: view the remaining battery • Backlight time: set the delay before the backlight dims •...
Device Name Set your device’s name. Accessibility • System font size: set the text size on the display • Multipress time out: set the delay when you press a key for entering text • Confirmation time out: set the delay before an unconfirmed action times out •...
troubleshooting If you have trouble with your device, try these procedures before you contact a service professional. While using your device, the following messages may appear: Message Try this to solve the problem: Ensure that the SIM card is SIM Failure installed correctly.
Page 53
• You may be between service areas. You should receive a signal when you enter a service area. You forgot a security, PIN, or PUK code. If you forget or lose this or another code, contact the seller or your service provider. Your display shows white lines.
Page 54
The battery does not charge properly or sometimes your device turns itself off while charging. • Disconnect the device from the charger, remove and reinstall the battery, and try charging again. • The battery terminals may be dirty. Wipe both gold-coloured contacts with a clean, soft cloth and try charging the battery again.
You cannot find a Bluetooth-enabled device. • Ensure that both devices have activated the Bluetooth wireless feature. • Ensure that the distance between the devices is not more than 10 metres and that they are not separated by walls or other obstacles.
Page 56
MICROSOFT SOFTWARE LICENSE TERMS FOR WINDOWS MOBILE 6.1 SOFTWARE Agreement These license terms are an agreement between you and Samsung Electronics Inc. ("Company"). Please read them. They apply to the software included on this device. The software also includes any separate media on which you received the software.
Page 57
attention away from the road while driving can possibly cause an accident or other serious consequence. Even occasional, short diversions of attention can be dangerous if your attention is diverted away from your driving task at a critical time. Company and Microsoft make no representations, warranties or other determinations that ANY use of this software is legal, safe, or in any manner recommended or...
Page 58
c. Speech Recognition. If the software includes speech recognition component(s), you understand that speech recognition is an inherently statistical process and that recognition errors are inherent in the process. Neither Company nor Microsoft or their suppliers shall be liable for any damages arising out of errors in the speech recognition process.
Page 59
• publish the software for others to copy; • rent, lease or lend the software; or • use the software for commercial software hosting services. Except as expressly provided in this agreement, rights to access the software on this device do not give you any right to implement Microsoft patents or other Microsoft intellectual property in software or devices that access this device.
Page 60
uses this information to make the Internet- based services available to you. Windows Mobile Update Feature. • The Windows Mobile Update feature provides you the ability to obtain and install software updates on your device if updates are available. You may choose not to use this feature.
Page 61
5. NOTICES ABOUT THE MPEG-4 VISUAL STANDARD. The software may include MPEG-4 visual decoding technology. This technology is a format for data compression of video information. MPEG LA, L.L.C. requires this notice: USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG 4 VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO (A) DATA OR INFORMATION (i)
Page 62
9. PRODUCT SUPPORT. Contact Company for support options. Refer to the support number provided with the device. 10. LINKS TO THIRD PARTY WEBSITES. If the software provides links to third party websites, those links are provided to you only as a convenience, and the inclusion of any link does not imply an endorsement of the third party website by Microsoft.
Page 63
15. RESTRICTED USE. The Microsoft software was designed for systems that do not require fail-safe performance. You may not use the Microsoft software in any device or system in which a malfunction of the software would result in foreseeable risk of injury or death to any person.
Page 64
18. EXPORT RESTRICTIONS. The software is subject to United States export laws and regulations. You must comply with all domestic and international export laws and regulations that apply to the software. These laws include restrictions on destinations, end users and end use. For additional information, see www.microsoft.com/exporting.
Page 65
index ActiveSync Exchange server, installing, schedule, synchronise, Adobe Flash Lite, see media Adobe Reader LE, alarm setting, stopping, Bluetooth activating, COM port, connecting to other devices, receiving data, sending data, calculator, calendar changing views, creating events, stopping event alarms, certificate, clock changing world clock, setting alarms,...
Page 66
date and time, D-Day, display, Exchange server, see ActiveSync file manager, games, Java, language, media opening files in contents manager, playing Flash files, playing voice clips, recording voice clips, messaging email, multimedia, viewing, messenger chatting, setting up and signing in, Office Mobile Excel workbooks, OneNote,...
