Permitted devices types

The details pertaining to functional safety in this manual relate to the device versions listed below
and are valid as of the specified software and hardware version. Unless otherwise specified, all
subsequent versions can also be used for safety functions. A modification process according to
IEC 61508 is applied for device changes.
Valid device versions for safety-related use:
Ordering feature Designation
010 Approval
020 Connector type
030 Power supply; display
040 Primary output
050 Secondary I/O analog
060 Secondary I/O digital
Ex d/XP
070 Housing
080 Process pressure
090 Electrical connection
110 Measuring range; wire;
diameter
120 Displacer material; type
130 Process seal
140 Process connection
150 Accuracy, approval for
custody transfer
500 Operating languages;
display
540 Application package
570 Service
580 Test; certificate
590 Additional approval
610 Accessory mounted
620 Accessory enclosed
850 Firmware version
895 Marking
1) At least one of the versions listed must be selected.
2) An additional selection of further versions is possible.
Proservo NMS80/81/83
Option
All
All
All
1)
All
E1 4 to 20 mA HART Ex d/XP
H1 4 to 20 mA HART Ex i/IS
1)
All
A1 Ex d/XP, 1x 4 to 20 mA HART, 1x RTD input
A2 Ex d/XP, 2x 4 to 20 mA HART, 2x RTD input
B1 Ex i/IS, 1x 4 to 20 mA HART, 1x RTD input
B2 Ex i/IS, 2x 4 to 20 mA HART, 2x RTD input
1)
All
A1 2x relay + 2x module, discrete
A2 4x relay + 4x module, discrete
A3 6x relay + 6x module, discrete
B2 Modbus RS485 + 2x relay + 2x module, discrete
B3 Modbus RS485 + 4x relay + 4x module, discrete
All except Y
All
All
All except Y
All except Y
All
All
All
All
All
All
All
2)
LA SIL
All
All
If no version is selected here, the latest SIL-enabled SW
is supplied. Alternatively, the following SW version
may be selected: 76____01.02.zz
All
