Healthmark LED Magnifier 4x Instructions For Use

Brand Name of Product
Generic Name of Product
Product Code Number(s)
Intended Use
Range of Applications for Product
Key Specifications of Product
Shipping Conditions &
Requirements
Storage Conditions
Packaging Conditions
Shelf Life
Description of Use (s)
Preparation for Use
Diagrams (drawings, pictures)
Steps for Use of Product
Interpretation of Results
Contraindications of Test Results
Documentation
Special Warnings and Cautions
Disposal
Point of Use
Instructions for Use: LED Magnifier 4x
LED Magnifier 4x
LED Magnifier 4x
MAG-002
A tool to help with visual inspections with three levels of brightness and a 4x magnification
for easy and thorough inspection of items.
Items, including robotic arms, that need up close visual inspection for possible damage or
residual soiling after processing.
●
LED magnifier size- 85x85x60mm
●
4x magnification
●
Lightweight
●
White 4 LED lights
●
Touch activated with 3 levels of brightness
●
On/Off switch
●
Microfiber lens cloth
●
Micro-USB Type C charging cable
●
Integrated battery
Shipping & Storage
Instructions for Using Product
A close-up visual inspection of items, including robotic arms, after reprocessing.
Charge the magnifier before first use.
Connect the charging cord with the lightning connector on the side of the magnifier and
plug the USB end of the charging cord into a USB port or charger.
The dot to the left of the connector will show red while charging and turns green when it is
fully charged. The rechargeable battery has over 300 charges.
1. Turn power switch on and use the touch activated setting (black circle) on top of
the magnifier and select the level of brightness you would like to use.
2. There are three levels of brightness:
First touch- Low- low brightness- Max 8 hours of working time
Second touch- Middle- middle brightness- Max 3 hours of working time
Third touch- High- brightest- Max 1.5 hours of working time
3. Once you have selected the LED light setting, slide an item under the magnifier to
visually inspect for cleanliness or damage through the glass of the magnifier.
●
Turn power off when not in use.
●
Fire hazard. Keep magnifier away from direct sunlight to prevent accidental fire.
●
Do not stare directly at LED lights as this might damage your eyes.
●
Keep the magnifier away from heat sources or direct impact to prevent damage to
the battery.
●
Do not manipulate the magnifier with wet hands.
●
Do not use if broken, may cause injuries.
Reprocessing Instructions
