Summary of Contents for Net1 Vertical Backboard & Goal
- Page 1 C9952 N123205 GM Operations Centre, Trent Lane, Colwick, Nottingham, NET1 is a registered trade mark of Unicorn Products Ltd. © 2018 NG2 4DS United Kingdom...
- Page 3 2) Place the bracket (A) against the wall in the desired position. Check bracket A is square with a spirit level. Mark the four hole positions through the bracket with a marker pen. four expanding bolts (B). from part (B).
- Page 4 of part (A). from part (B).
- Page 5 two nuts and bolts (D). two nuts and bolts from part (D).
- Page 6 Step 4: Securing the rim arm supports 1) Secure the arms (E) to the wall bracket (A) by fixing nuts and bolt (F) through the holes as indicated below. Step 2...
- Page 7 Step 5: Attaching the net 1) Attach the net (G) to the net hooks (H) of the goal. WARNING! To ensure your safety, do not attempt to assemble the basketball system set without reading and following all instructions carefully. Identify and check the parts using the parts list. HANGING FROM THE RIM WILL DAMAGE THE UNIT, VOID THE WARRANTY AND RESULT IN PERSONAL INJURY.
