Eagle Tree Systems eLogger V4 Instruction Manual

Document Version 1.1, Model # MPRV4-CONN-100, MPRV4-LEADS-100, and MPRV4-LEADS-150
Thank you for your purchase! This instruction manual will guide you through the
installation and operation of your eLogger.
Please read the entire manual carefully before proceeding. If, after you read
the manual (including the Troubleshooting sections!) you have further questions
or problems, please visit our web support page for additional support options, at
http://www.eagletreesystems.com/Support/support.html. Note that the latest
version of this manual is available in PDF form from the Support page of our
website.
Please also fill out the registration form at the end of this manual if you did not
purchase your eLogger directly from Eagle Tree Systems, so we can send you
important update information.
Key Features
Here are a few of the features of the eLogger:
•
Logs pack current to +/- 100 amps (150 amps with MPRV4-LEADS-150) and voltage from about 5 volts to 80
volts
•
Current is measured with a true Hall Effects Sensor - NOT a power robbing resistance shunt
•
Adjustable logging rate (from 50 samples per second to one sample every 5 minutes)
•
16 times the logging space of the standard eLogger V3, and lossless data compression.
available sensors for about four hours, at 10Hz.
•
All data are logged to permanent memory, which retains the data even when the power is removed
•
Fully compatible with our OSD Pro expander
•
Includes Y cable for throttle position logging
•
Great for bench monitoring of battery charging also!
•
Supports the PowerPanel LCD Display
•
Accepts optional inexpensive sensors for three Temperatures, RPM (brushless, magnetic or optical), Airspeed,
Altitude, GPS, Servo Current, and more
•
Software computes Wattage, mAH, etc. for complete e-flight data.
•
Fully Compatible with Windows 7 (32 and 64 bit), Vista, 98SE, ME, Win2K and XP™
•
Weighs about 0.8 oz (22 grams). Versions with Wire Leads may weigh slightly more.
•
Comes with our state of the art Windows virtual playback display and graphing software
•
Powerful Graphing software has advanced charting features, such as amps vs. volts
•
Internet Updatable firmware - as we add new features or (heaven forbid) have a firmware bug, the update is just a
download away! No need to ship hardware back and forth.
•
Full support for English and Metric units.
•
Software has built in English, German and Chinese languages.
Intended Uses
The eLogger was designed for use in Unmanned Radio Controlled models. It is intended to be used exclusively in model planes,
boats and cars. Using the eLogger for other purposes is not supported. Further, using the eLogger in situations where its use or
failure could result in loss of life, bodily injury or property damage is expressly prohibited. Eagle Tree Systems, LLC, is not
responsible for your use of this product, or for any damages or injuries you may cause or sustain as a result of its usage.
Copyright © 2003-2010 Eagle Tree Systems, LLC
Instruction Manual for the eLogger V4
Typically logs all
