- Page 1 GM8136/GM8136S EVB U UIDE User Guide Rev.: 1.0 Issue Date: September 2014...
- Page 3 . The information contained in this document does not affect or change Grain Media’s product specification or warranties. Nothing in this document shall operate as an express or implied license or indemnity under the intellectual property rights of G ra in M ed ia or third parties.
-
Page 5: Table Of Contents
IP Cam Demonstration Setup ..................19 Setting GM8136/GM8136S EVB ................20 Setting VLC Media Player in PC Site ..............21 Chapter 4 EVB Firmware Update ....................25 Setting of GM8136/GM8136S EVB ............... 26 Setting of PC Tool ....................26 GM8136/GM8136S EVB User Guide www.grain-media.com... - Page 6 Pin Definition of UART1/RS485 Connector (UART1/RS485 Connector: J10) ....16 Table 2-10. List of Power Switches on EVB ..................17 Table 2-11. List of Push Buttons on EVB ................... 17 Table 2-12. List of LED Indicators on EVB ..................17 GM8136/GM8136S EVB User Guide www.grain-media.com...
- Page 7 Figure 1-1. Block Diagram of GM8136/GM8136S ................2 Figure 1-2. GM8136 EVB Layout ......................3 Figure 1-3. Top View of GM8136 EVB ....................4 Figure 1-4. Top View of GM8136S EVB ....................5 Figure 1-6. ICE Daughter Board ......................6 Figure 1-7.
-
Page 9: Chapter 1 Introduction
Chapter 1 Introduction This chapter contains the following sections: Overview • Features • GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 10: Overview
Overview GM8136/GM8136S EVB provides a cost-effective and easy-development system for integration and verification of the video application at the early development stage. This user guide provides the needed information on using the EVB. Figure 1-1. Block Diagram of GM8136/GM8136S GM8136/GM8136S EVB User Guide... -
Page 11: Figure 1-2. Gm8136 Evb Layout
Figure 1-2. GM8136 EVB Layout GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 12: Figure 1-3. Top View Of Gm8136 Evb
Figure 1-3. Top View of GM8136 EVB GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 13: Figure 1-4. Top View Of Gm8136S Evb
Figure 1-4. Top View of GM8136S EVB GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 14: Figure 1-6. Ice Daughter Board
Figure 1-6. ICE Daughter Board Figure 1-7. RS232 Daughter Board GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 15: Features
Features This EVB contains the following features: DDR3 SDRAM of 2G bits (128 Mx16) for GM8136, 1G bits (128Mx16) for GM8136S • 16M byte SPI Flash memory • ICE connector • CMOS sensor interface connector • Extended I/O connector •... -
Page 17: Chapter 2 System Hardware
Chapter 2 System Hardware This chapter contains the following sections: Description of EVB Connector • Description of Power Switch • Description of Push Buttons • Description of LED Indicators • GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 18: Description Of Evb Connectors
GM8136/GM8136S EVB contains several jumper settings .JP0, JP1 can be found in Switch SW1. JP6, JP7, JP8, JP19 can be found in Switch SW2. When the reset signal changes from low to high, GM8136/GM8136S will latch the logic value of the jumper settings. These latched values will affect the behavior of GM8136/GM8136S. -
Page 19: Table 2-3. Signal Description Of Cpu Ice Connector
ICE data input ICE_DBGRQ External device enters ICE after de-activating the reset. ICE_RTCK Pull low with a 4.7-k resistor ICE_TRSTn Active-low reset signal for the boundary scan logic Pull low with a 4.7-k resistor 3.3-V power Ground GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 20: Cmos Sensor Interface Connector
Pin No. Signal Name DGND DGND I2S_SCLK CAP_RST I2S_FS I2C_SDA I2C_SCL BAYER_CLKOUT BAYER_HS BAYER_VS DGND BAYER_CLK BAYER_D11 BAYER_D10 BAYER_D9 BAYER_D8 BAYER_D7 BAYER_D6 DGND BAYER_D5 BAYER_D4 GPIO0_9 BAYER_D3 BAYER_D2 DGND DGND BAYER_D1 BAYER_D0 GPIO0_14 GPIO0_15 GPIO0_16 GPIO0_17 GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 21: Table 2-5. Pin Definitions Of Series Sensor Interface Connector
Table 2-5. Pin Definitions of Series sensor interface connector Pin No. Signal Name Pin No. Signal Name DGND DGND CAP_RST I2C_SDA I2C_SCL CAP_CLKOUT DGND DGND DGND DGND DGND GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 22: Video Output Interface Connector
Signal Name DGND TV_CLK TV_VS/RGB_VS DGND TV_HS/RGB_HS TV_DAT0/RGB_B3 TV_DAT1/RGB_B4 TV_DAT2/RGB_B5 TV_DAT3/RGB_B6 TV_DAT4/RGB_B7 I2S1_RXD TV_DAT5/RGB_G2 DGND TV_DAT6/RGB_G3 I2S1_SCLK TV_DAT7/RGB_G4 I2S1_FS TV_DAT8/RGB_G5 I2S1_TXD TV_DAT9/RGB_G6 DGND TV_DAT10/RGB_G7 TV_DAT11/RGB_R3 DGND TV_DAT12/RGB_R4 TV_RESET TV_DAT13/RGB_R5 DGND TV_DAT14/RGB_R6 I2C_SDA TV_DAT15/RGB_R7 I2C_SCL DGND DGND GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 23: Extended I/O Connector
Table 2-7. Pin Definition of Extended I/O Connector (J5) Pin No. Signal Name Pin No. Signal Name DGND DGND I2S1_SCLK I2S1_TXD I2S1_FS I2S1_RXD DGND DGND PWM1 PWM0 PWM3 PWM2 DGND DGND I2C_SCL I2C_SDA DGND DGND GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 24: Uart/Rs485 Connector
2.1.6 UART/RS485 Connector The GM8136/GM8136S EVB offers two DIN connectors (J9, J10) for the applications of UART and RS485. Please refer to Table 2-8 and Table 2-9 for the details on the pin definition of the UART and RS485 connectors. -
Page 25: Description Of Power Switch
Description of Push Buttons Table 2-11. List of Push Buttons on EVB Legend Function PB1 ~ PB8 ADC0 keypads Description of LED Indicators Table 2-12. List of LED Indicators on EVB Legend Function LED1 5V Power source indicator GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 27: Ip Cam Demonstration Setup
Chapter 3 IP Cam Demonstration Setup This chapter contains the following sections: Setting GM8136/GM8136S EVB • Setting VLC Media Player in PC • GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 28: Setting Gm8136/Gm8136S Evb
Setup procedure: Step 1: Use the Ethernet cable to connect the GM8136/GM8136S EVB Ethernet port to PC Step 2: Use the RS-232 cable to connect the GM8136/GM8136S EVB UART port to PC. The RS-232 baud rate is 115200. Step 3: Power on the GM8136/GM8136S EVB Step 4: In the PC console, you can see the booting log. -
Page 29: Setting Vlc Media Player In Pc Site
Setting VLC Media Player in PC Site Setup procedure: Step 1: Execute the VLC media player GM8136/GM8136S EVB User Guide www.grain-media.com... - Page 30 Step 2: Select Media Open the network stream GM8136/GM8136S EVB User Guide www.grain-media.com...
- Page 31 Step 3: Fill in the network URL information and other related settings Hint: Edit options: □ rtsp-caching = 200; □:rtsp-tcp “□” means space. Step 4: Now, users can see the video of the IP Cam. GM8136/GM8136S EVB User Guide www.grain-media.com...
-
Page 33: Chapter 4 Evb Firmware Update
Chapter 4 EVB Firmware Update This chapter contains the following sections: Setting of GM8136/GM8136S EVB • Setting of PC Tool • GM8136/GM8136S EVB User Guide www.grain-media.com... -
Page 34: Setting Of Gm8136/Gm8136S Evb
Setting of GM8136/GM8136S EVB Setup procedure: Step 1: Set switch SW2 pin1 to logic low (Short JP6 jumper). GM8136/GM8136S will enter the firmware update mode. If the content of the SPI Flash is empty, users can skip this step. Step 2: Use the USB cable for connecting the GM8136/GM8136S EVB USB port to PC. - Page 35 Step 2: Press the “Advance Setting…” button and specify the following location paths of files. GM8136/GM8136S EVB User Guide www.grain-media.com...
- Page 36 If upgrade is finished successfully, the device information bar will show “100%”. Step 4: Set SW1 pin2 to logic high Step 5: Reboot Step 6: Please refer to Section 3.1 for detailed information of settings of the GM8136/GM8136S EVB. GM8136/GM8136S EVB User Guide www.grain-media.com...
