- Page 1 DC30A DUST COLLECTOR WITH WALL MOUNTED CONTACT US:BUCKTOOL@FOXMAIL.COM IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety Guidelines MANUAL and Operating Instructions before operating this product.
- Page 2 DC30A TABLE OF CONTENTS Specifications Safety guidelines The parts list Assembly instructions Operating instruction Maintenance Exploded view Parts list Warranty SPECIFICATIONS 120VAC, 60Hz , 1HP Electrical Input 3 Prong Power Plug 6’ Power Cord Length Intake Diameter 4" OD Collection Capacity...
- Page 3 DC30A SAFETY GUIDELINES - DEFINITIONS READ AND UNDERSTAND ALL INSTRUCTIONS Failure to follow all instructions listed in the following pages may result in electric shock, fire, and/or serious injury. WORK AREA Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
- Page 4 DC30A heat, oil, sharp edges, or moving parts. Replace damaged Power Cords immediately. Damaged Power Cords increase the risk of electric shock. 6. When operating a power tool out side, use an outdoor extension cord marked “W-A” or “W”. These extension cords are rated for outdoor use, and reduce the risk of electric shock.
- Page 5 DC30A you must regularly monitor airborne sawdust and maintain the Tool to avoid exceeding dust limits. Each application is unique, and your maintenance schedule must be tailored toyour specific use. 4. Industrial applications must follow OSHA requirements. 5. Use the right tool or attachment for the right job. Do not attempt to force a small tool or attachment to do the work of a larger industrial tool.
- Page 6 DC30A damaged, have it repaired by a service facility before use. If the plug will not fit the outlet, have a proper outlet installed by a qualified electrician. GROUNDED TOOLS TOOLS WITH THREE PRONG PIUGS 3-Prong Plug and Outlet 1. Tools marked with “Grounding Re quired” have a three wire cord and three prong grounding plug.
- Page 7 DC30A Extension Cords 1. Grounded tools require a three wire extension cord. Double Insulated tools can use either a two or three wire extension cord. 2. As the distance from the supply outlet increases, you must use a heavier gauge extension cord.
- Page 8 DC30A TOOL USE AND CARE 1. Use clamps (not included) or other practical ways to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control.
- Page 9 DC30A No. Description Qty. Wall mount bracket ST hex head screw Set screw Set screw Plastic sleeve Lock nut Pain washer Hose 4”hose clamp Dust collection bag Manual...
- Page 10 DC30A WALL MOUNT INSTRUCTIONS CAUTION Verify that the plate is securely attached to the wall before mounting the collector unit to the plate. 1. Mount the plate (1) to the wall by the ST hex head screw (2) Set screw (3) . As shown in Fig1.
- Page 11 DC30A OPERATING INSTRUCTIONS NOTE: For additional information regarding the parts mentioned in the following pages, refer to the Assembly Diagram near the end of the manual. Turn the Power Switch off. Then, plug the Power Cord Plug into the nearest 120 volt, grounded, electrical outlet.
- Page 12 DC30A...
- Page 13 DC30A Package contents Description SIZE Qty. Motor Switch Motor label Washer Philips screw+spring washer+flat washer M6*12 Blower housing cover Washer Base Hex bolt+spring washer+flat washer M6*12 Gasket Hex bolt+flat washer M6*16 Rubber foot Fan spacer Flat washer Hex nut. I type...
- Page 14 DC30A Description SIZE Qty. Plastic molleys+Phillips screws assy. Hex bolt+spring washer+flat washer M8*25 Hex bolt+flat washer M8*20 Collect bag 4" clamp Dust hose Wall Mount Bracket Plastic molleys Cord and plug Plug clip Big flat washer Locking nut...
- Page 15 DC30A ASSEMBLY INSTRUCTIONS NOTE: For additional information regarding the parts mentioned in the following pages, refer to the Assembly Diagram near the end of the manual. 1. Use the screw , lock washer , nuts to assembly the rubber foot on the base.
- Page 16 Skype :bucktool@foxmail.com ONE-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : bucktool@foxmail.com Skype : bucktool@foxmail.com Skype:bucktool@foxmail.com...
