Summary of Contents for Center D02161
- Page 1 INSTALLATION INSTRUCTIONS & WARRANTY LEAFLET D02161.D02162. * Center Quad 4mm Enclosure 800x800x1850 * Center Quad 4mm Enclosure 900x900x1850...
- Page 2 IMPORTANT Please familiarise yourself with the fitting instructions before commencing fitting. 1 Check that you have the tools required 2 Check that the installation site is compatible with size of door supplied 3 Check all the enclosure components 4 Check that the installation kit is complete attempt to install the product unless you can tick DO NOT ALL 4 boxes...
-
Page 3: Box Contents
Box Contents: 1xInstallation Instruction. [1] 2xHorizontal Rails. 8xScrews ST4x35. [2] 6xWall Plugs. [3] 6xScrews ST4x35. [4] 12xScrews Cover Caps. [5] 6xScrews ST3.5x8. [6] 2xWall Posts. [7] 2xFixed Panels. [8] 2xDoor Panels. [9] 4xTop Rollers. [10] 4xBottom Rollers. [11] 4xGlass Clamps. 4xScrews ST3.5x8. -
Page 4: Assembly Drawing
Assembly Drawing [15] [11] [13] [14] [12] [10] Number Description Picture Quantity Can be purchased separately Wolseley Spare Product code Horizontal Rails Wall Plugs Screws ST4x35 Screws Cover Caps D03097 Screws ST3.5x8 Wall Posts Fixed Panels Door Panels Top Rollers D03091 Bottom Rollers Glass Clamps... - Page 5 Adjust The Size SIZE(mm) 800x800 770-790 900x900 870-890...
-
Page 6: Installation Steps
Installation Steps Step 1 The profile must be checked with the spirit level whilst marking. Screw ST4x35 with screw cover Step 2 [11] Glass Clamp Glass Clamp Screw ST3.5x8 Screw M4x35 View from inside Please note installation direction of the glass clamp！... - Page 7 Step 3 View from inside Step 4 Top Roller. Top Roller. Bottom Roller. [10] View from inside...
- Page 8 Step 5 [12] [14] [13] Fixed Panel Door Panel Ensure wall profiles are plumb. Adjust enclosure to be square and level. Wheels should be adjusted to square the doors and ensure smooth running. Step 6...
- Page 9 Step 7 Take extra care not to drill through to exterior side. Max: 3.0mm Screw ST3.5x8 with screw cover Follow the indications on wall profiles to locate the drilling holes View from inside Step 8 [15] View from inside The sealant should be applied to the outside edge.
-
Page 10: Maintenance Information
Safety Information for User & Installer Important information for fitter: Installation information • It is recommended that only approved/qualified plumbers should install the product. • Incorrect installation of the enclosure will invalidate guarantee. Safety information prior to and during installation •... - Page 11 Helpline Should you require any technical help in association with your CENTER 0344 292 7062 products please call with your query. Warranty: Years For detail warranty information, please visit our website: www.wolseley.co.uk Wolseley CV34 6DY www.wolseley.co.uk...
