  • Page 1 ThermiStar L .. SP 01/03/10...

  • Page 2: Table Of Contents

    Index Safety ................................4 General ..................................4 Intended use .................................. 4 Explanation of symbols ..............................5 Personnel requirements ..............................6 Special dangers ................................6 Standards and Regulations ........................9 Standards and Regulations ............................9 Transport, Packaging, Storage ........................ 12 Safety notes for transport............................. 12 Inspection of the delivery .............................
  • Page 3 Index Operation startup ............................57 Safety during startup ..............................57 Inspection before startup ............................. 57 Startup ..................................58 Setting the controller ..............................60 Parameterization ................................. 61 Startup protocol ................................61 Maintenance ............................... 62 Maintenance ................................62 Components relevant to safety ............................ 63 Work activities to be performed ...........................

  • Page 4: Safety

    1. Safety ThermiStar L .. SP 01/03/10 Safety General The assembly, startup and maintenance instructions are addressed to technicians of professional heating companies. Contains important information for safe handling of the device. Compliance with all specified safety information and handling instructions is the prerequisite for safe working.

  • Page 5: Explanation Of Symbols

    1. Safety ThermiStar L .. SP 01/03/10 Explanation of symbols This sections provides an overview of all important safety aspects for optimal personal protection as well as for safe and troublefree operation. The handling instructions and safety notes specified in these instructions must be followed to prevent accidents, personal injuries and property damages.

  • Page 6: Personnel Requirements

    1. Safety ThermiStar L .. SP 01/03/10 Personnel requirements WARNING! Danger to life if not sufficiently qualified! Improper handling leads to considerable personal injuries and property damages. Therefore: - Assembly, startup and maintenance work, repairs or modifications of the set fuel amounts may only be done by a heating and/or air conditioning pro- fessional.
  • Page 7 1. Safety ThermiStar L .. SP 01/03/10 Electrical current DANGER! Danger of life through electric current! Touching live parts presents an immediate danger to life. Damages to the insulation or individual components can present a danger to life. Therefore: - In case of damaged insulation, immediately cut off the power supply and initiate the repair.
  • Page 8 1. Safety ThermiStar L .. SP 01/03/10 CAUTION! Risk of injury due to refrigerant! Refrigerant is corrosive and causes cold burns upon contact with skin. Therefore: - Wear chemical-resistant protective gloves when handling refrigerant at any time. - Wear protective glasses to avoid contact with eyes.

  • Page 9: Standards And Regulations

    2. Standards and Regulations ThermiStar L .. SP 01/03/10 Standards and Regulations Standards and Regulations The following standards and regulations must be observed with the installation and operation of the heating system. Standards Publication Standards Title date Heating systems in buildings, safety DIN EN 06.2003...
  • Page 10 2. Standards and Regulations ThermiStar L .. SP 01/03/10 Stipulations The erection and operation of the heating system requires compliance with the technical building supervision rules as well as other legal stipulations of the individual countries. Publication Stipulations Title date...
  • Page 11 2. Standards and Regulations ThermiStar L .. SP 01/03/10 Additional Standards / Regulations for Switzerland Assembly, startup and maintenance may only be performed by certified installation companies. Work on electrical system components may only be performed by a licensed electrician.

  • Page 12: Transport, Packaging, Storage

    3. Transport, Packaging, Storage ThermiStar L .. SP 01/03/10 Transport, Packaging, Storage Safety notes for transport CAUTION! Damage through improper transport! Significant property damage may be incurred by improper transport. Therefore: - Be careful when unloading packaging items upon delivery as well as during in-plant transport and obey the symbols on the packaging.

  • Page 13: Notes On Storage

    3. Transport, Packaging, Storage ThermiStar L .. SP 01/03/10 Notes on storage The shaft of the boiler pump may seize during extended storage. This is not a defect. Please see the chapter "Pump control" on page Error! Bookmark not defined..

  • Page 14: General

    RVS 61.843 and control unit AVS 37.294 Heating circulation pump (up to L 28) Connector for additional electric heater 6.0 kW From ThermiStar L 10 SP with soft-start control Module for thawing the split evaporator via hot-gas bypass con- trols...
  • Page 15 4. General ThermiStar L .. SP 01/03/10 Control unit QAA 78 94.88147-5021 Radio-controlled control unit optional use as control unit, service unit or room unit. Setting of all parameters in the RVS controller, range of radio connection approx. 30 m Radio module AVS 13.399/201...

  • Page 16: Technical Data

    5. Technical Data ThermiStar L .. SP 01/03/10 Technical Data Dimensions and connection ratings Connections at rear wall of heat pump Sk09-6200-121 Stand: 06.11.09 Sk09-6200-023_a Stand: 06.11.09 Fig. 1:Connections at rear wall of heat pump L05 to L15 Fig. 2:Connections at rear wall of heat pump L19 to L41...
  • Page 17 5. Technical Data ThermiStar L .. SP 01/03/10 Erection measurements and dimensions, split evaporator for ThermiStar L .. SP Fig. 3: Erection measurements and dimensions, split evaporator for ThermiStar L .. SP Legend for Fig. 3: ThermiStar … SP Abbr.

  • Page 18: Type Plate

    5. Technical Data ThermiStar L .. SP 01/03/10 Type plate Fig. 4: Sample type plate...
  • Page 19 5. Technical Data ThermiStar L .. SP 01/03/10 Legend for Fig. 4: Abbr. Meaning Type Part number / Item number Country of destination Serial number Refrigerant Refrigerant capacity Output A2/W35 Output B0/W35 Output W10/W35 Output W7/W35 Rated thermal output max. positive operating pressure max.

  • Page 20: Technical Data

    5. Technical Data ThermiStar L .. SP 01/03/10 Technical data Air/water heat pumps* Thermistar L 05 SP to L 41 SP ThermiStar L .. 05 SP 07 SP 10 SP 13 SP 15 SP 19 SP 28 SP 34 SP 41 SP...
  • Page 21 5. Technical Data ThermiStar L .. SP 01/03/10...

  • Page 22: Electrical Data

    5. Technical Data ThermiStar L .. SP 01/03/10 Electrical data Wiring diagram for ThermiStar L 05 SP - L 07 SP with expansion set up to 7 kW Sk09-6200-018_c Stand: 09.02.2010 Fig. 5: Wiring diagram for ThermiStar L 05 SP - L 07 SP with expansion set up to 7 kW...
  • Page 23 5. Technical Data ThermiStar L .. SP 01/03/10 Legend for Fig. 5: Abbr. Meaning Abbr. Meaning Refrigerant temperature liquid - When using fault current circuit breakers, Condensor pump observe separate neutral leads for normal Performance limit and special tariff! Motor...
  • Page 24 5. Technical Data ThermiStar L .. SP 01/03/10 Wiring diagram for ThermiStar L 10 SP - L 19 SP with expansion set 10-20 kW Sk09-6200-019_c Stand: 09.02.2010 Fig. 6: Wiring diagram for ThermiStar L 10 SP - L 19 SP with expansion set 10-20 kW...
  • Page 25 5. Technical Data ThermiStar L .. SP 01/03/10 Legend for Fig. 6: Abbr. Meaning Abbr. Meaning Performance limit - When using fault current circuit breakers, observe separate neutral leads for normal Motor and special tariff! Condenser motor - Observe identical phase potential of the...
  • Page 26 5. Technical Data ThermiStar L .. SP 01/03/10 Wiring diagram for ThermiStar L 28 SP - L 41 SP with expansion set >25 kW Sk09-6200-020_c Stand: 09.02.2010 Fig. 7: Wiring diagram for ThermiStar L 28 SP - L 41 SP with expansion set >25 kW...
  • Page 27 5. Technical Data ThermiStar L .. SP 01/03/10 Legend for Fig. 7: Abbr. Meaning Abbr. Meaning Refrigerant temperature liquid - When using fault current circuit breakers, observe separate neutral leads for normal Condensor pump and special tariff! Performance limit - Observe identical phase potential of the...
  • Page 28 5. Technical Data ThermiStar L .. SP 01/03/10 Sensor positions 49.0 42.2 42.3 48.1 48.0 Fig. 8: Sensor positions Legend for Fig. 8: Descrip- terminal Meaning tion RVS 61 Temperature sensor Sensor heat pump flow 42.2 Sensor heat pump return 42.3...
  • Page 29 5. Technical Data ThermiStar L .. SP 01/03/10 Legend for Fig. 9: Abbr. Meaning Abbr. Meaning Outside temperature sensor Multifunctional sensor input 4 MFE4 connector k, terminals M, B9 (functions see MFE1) connector x, terminals M, BX4 Service tool OCI 700...
  • Page 30 5. Technical Data ThermiStar L .. SP 01/03/10 Electrical controller data Rated voltage AC 230 V (± 10%) Rated frequency 50/60 Hz Max. power consumption 11 VA Input (Controller) Fuse protection of supply lines max. 10 AT Wire gauge 1 wire: 1.0 mm - 1.5 mm...
  • Page 31 5. Technical Data ThermiStar L .. SP 01/03/10 2-wire connection, not interchangeable Max. line length Basic unit - peripheral unit 200 m Max. total line length 400 m (Max. cable capacity: 60 nF) Min. wire gauge 0.5 mm Interfaces Cu cable 1.5 mm2, 2-wire, not interchangeable...

  • Page 32: Assembly

    6. Assembly ThermiStar L .. SP 01/03/10 Assembly Safety during assembly WARNING! Risk of injury due to improper assembly! Improper assembly leads to serious personal injuries and property damages. Therefore: - The assembly and startup must be performed by an authorized heating and/or air conditioning profes- sional.
  • Page 33 6. Assembly ThermiStar L .. SP 01/03/10 WARNING! Risk of life through fire! Easily flammable materials or liquids can catch fire. Therefore: - Do not use or store explosive or easily flammable substances (i.e. fuel, paints, paper, wood) in the area where the device is installed.

  • Page 34: Assembly Tools

    6. Assembly ThermiStar L .. SP 01/03/10 Assembly tools The assembly and maintenance of the heating system requires standard tools from the field of heating installations, cooling installa- tion technology, as well as water systems installations. Assembly information CAUTION! Environmental damage through substances...
  • Page 35 6. Assembly ThermiStar L .. SP 01/03/10 Refrigerant The safety datasheet concerning refrigerant R 410A is available for download at www.mhg.de\Download\Sicherheitsdatenblätter. NOTE! In case of emergencies, ring the telephone number below: +44(0)208 762 83 22 [CareChem 24] (Europe) WARNING! Danger of life through lack of oxygen! Vapors of the refrigerant R 410A are heavier than air and may cause suffocation by displacing oxygen.
  • Page 36 6. Assembly ThermiStar L .. SP 01/03/10 Welding work NOTE! If any welding work is scheduled on the refrigerant line, a protective gas (i.e. nitrogen) will need to be passed through the pipe in order to prevent scale formation. Scale and other contamination can impair the proper operation of the device leading to disor- ders.
  • Page 37 6. Assembly ThermiStar L .. SP 01/03/10 CAUTION! Environmental damage due to improper assembly of the refrigerant line! Refrigerant and compressor oil can leak! Therefore: - Only use tools recommended for work on cooling devices: Bending pliers, pipe cutters, countersink...
  • Page 38 6. Assembly ThermiStar L .. SP 01/03/10 NOTE! Ball valves must remain shut (delivery condition)! Fig. 10: Connection split evaporator Legend for Fig. 10: Abbr. Meaning Fluid line Suction gas line Hot-gas line Sensor cable heat source evaporation...
  • Page 39 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 11: Sensor cable heat source intake...
  • Page 40 6. Assembly ThermiStar L .. SP 01/03/10 Installation of the heat pump The heat pump is delivered standing on a wooden pallet. Remove the foil/packaging and install the heating pump in accor- dance with the following steps. Fig. 12: Heating pump without enclosure Fig.
  • Page 41 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 14: Pre-assemble the enclosure ass seen in the image prior to installing the hydraulic and cooling lines. CAUTION! Water damage through condensation or humidity in the air! Extremely low temperatures at the refrigerant lines lead to condensation or humidity in the air and can cause water damage.
  • Page 42 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 15: Place the counter nut into the insulation and screw in the cable gland.
  • Page 43 6. Assembly ThermiStar L .. SP 01/03/10 Connection of split evaporator with heat pump CAUTION! Risk of injury due to refrigerant! Refrigerant is corrosive and causes cold burns upon contact with skin. Therefore: - Wear chemical-resistant protective gloves when handling refrigerant at any time.
  • Page 44 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 16: Heat pump connections Legend for Fig. 16: Abbr. Meaning Fluid line Suction gas line Hot-gas line Evacuate the suction, liquid and hot-gas lines. Connect the devices to the Schrader valves for evacuation (see Fig. 10).

  • Page 45: Hydraulic Connection

    6. Assembly ThermiStar L .. SP 01/03/10 Hydraulic connection Requirements on the heating water To prevent corrosion damages in the heating system, heating water in potable quality must be used under consideration of the requirements according to VDI guideline 2035 "Preventing damages in warm water heating systems".

  • Page 46: Electrical Connection

    6. Assembly ThermiStar L .. SP 01/03/10 Electrical connection DANGER! Danger of life through electric current! Contact with live components represents a risk to life. Activated electrical components can perform uncontrolled movements and cause serious injuries. Therefore: - Make sure that all electrical parts are without current.
  • Page 47 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 19: Electrical connection Legend for terminal diagram electrics board: The electrical connection is made according to the wiring diagram in chapter 5.4. The circuit protection in the distributor (meter cabinet) must be made with a 3-pole power circuit breaker (C-characteristics) according to the output ratings of the heat pump.
  • Page 48 6. Assembly ThermiStar L .. SP 01/03/10 Highly reliable spring clips are used as connection terminals. The clips are opened with the appropriate included tool (e.g. small screw driver) which is inserted in the respective square opening and is then moved in the direction away from the lead intake opening.
  • Page 49 6. Assembly ThermiStar L .. SP 01/03/10 Connection terminals ventilator(s) 0-10V PWM 0-10V PWM 0-10V PWM 0-10V PWM 4-20mA 4-20mA 4-20mA +20V +20V +20V +10V +10V +10V 0-10V PWM 0-10V PWM 0-10V PWM (L1) (L1) (L1) (L2) (L2) (L2) (L3)
  • Page 50 6. Assembly ThermiStar L .. SP 01/03/10 Enclosure assembly Fig. 22: Snap the catches of the side panel of the enclosure into the rear panel. Fig. 23: Fix side panels on the rear panel of the enclosure.
  • Page 51 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 24: Insert the spring plates in the side enclosures. Fig. 25: Snap the front panel onto the catches of the side panel.
  • Page 52 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 26: Screw the closing journals into the lid of the enclosure. Fig. 27: Position the lid. Fig. 28: Insert the bracket.
  • Page 53 6. Assembly ThermiStar L .. SP 01/03/10 Fig. 29: Screw in the upper wing nut of the bracket. Fig. 30: Screw in the lower wing nut of the bracket. Fig. 31: Reach through the opening of the bracket to remove the...
  • Page 54 6. Assembly ThermiStar L .. SP 01/03/10 Motor control unitRSHL 4818 for ThermiStar L 10 bis L 19 Fig. 32: Operational diagram RSHL 4818 Legend for Fig. 32: Abbr. Meaning LED indication Push button Setting to 1 Current settings Multiplier/Current Limit...
  • Page 55 6. Assembly ThermiStar L .. SP 01/03/10 Status LED in- dications Flashing Green Power OFF Not available Power ON Yellow Idle / Setup Ramping* Bypass ON Internal overheat Motor overheat alarm* alarm Phase sequence Not available Phase loss alarm alarm*...
  • Page 56 6. Assembly ThermiStar L .. SP 01/03/10 Motor control unitRSHR 4025 for ThermiStar L 28 Fig. 33: Operational diagram RSHR 4025 Legend for Fig. 33: Abbr. Meaning Set warm-up time to value 1 Set cool-off time to value 0 Set warm-up torque to 25%...

  • Page 57: Operation Startup

    7. Operation startup ThermiStar L .. SP 01/03/10 Operation startup Safety during startup WARNING! Risk of injury due to improper operation! Improper operation leads to serious personal injuries or property damages. Therefore: - Installation and assembly must be performed by a heating systems dealer.

  • Page 58: Startup

    7. Operation startup ThermiStar L .. SP 01/03/10 Startup NOTE! The customer / owner of the system must be present when starting up the system. A startup protocol must be established on site. NOTE! For operators of equipment containing 3 kg or more...
  • Page 59 7. Operation startup ThermiStar L .. SP 01/03/10 Pump control Circulating pump control Unscrew pump stopper and turn pump shaft as illustrated below. Screw pump stopper back in Caution: Collect drops Fig. 34: Remove pump stopper Switching on the device Once the proper installation verification and testing has been com- pleted, the power can be switched on.

  • Page 60: Setting The Controller

    7. Operation startup ThermiStar L .. SP 01/03/10 Setting the controller Control unit AVS 37 Fig. 35: Control unit AVS 37 Legend for Fig. 35: Abbr. Meaning Select drinking water mode Service connector for BSB data BUS Exit settings Select heating mode...

  • Page 61: Parameterization

    7. Operation startup ThermiStar L .. SP 01/03/10 Parameterization At this point, MHG refers to the Assembly-Operation-Maintenance manual RVS 61.843 / AVS 37.. / QAA 75.. / QAA 78.. (Part No. 98.18803-6105) The factory parameters can be taken from the table on the pages 86-87.

  • Page 62: Maintenance

    8. Maintenance ThermiStar L .. SP 01/03/10 Maintenance Maintenance NOTE! The respective regulations and guidelines of the country of destination must be complied with! NOTE! Depending on the refrigerant dosage, the system op- erator must have the system inspected at least every 12 months.

  • Page 63: Components Relevant To Safety

    8. Maintenance ThermiStar L .. SP 01/03/10 Components relevant to safety To ensure the long-term availability and safety of heat generators and components and to meet the requirements of the EU guideline 2002/91/EG, the following components must be replaced after they have reached the nominal service life, specified by the manufacturer in terms of time or switching cycles.

  • Page 64: Work Activities To Be Performed

    8. Maintenance ThermiStar L .. SP 01/03/10 Work activities to be performed CAUTION! Risk of injury due to refrigerant! Refrigerant is corrosive and causes cold burns upon contact with skin. Therefore: - Wear chemical-resistant protective gloves when handling refrigerant at any time.
  • Page 65 8. Maintenance ThermiStar L .. SP 01/03/10 Confirm the work activities performed in the following maintenance protocol with an X or a . Maintenance activities Description Done Document amount and type of refrigerant used Document any amounts of refrigerant refills...
  • Page 66 8. Maintenance ThermiStar L .. SP 01/03/10 Disassembly of the control unit NOTE! Loosen the catches with a screwdriver. Ensure that the catches are not broken off when dismantling the control unit. Fig. 36: Insert a screw driver according to the above illustration...
  • Page 67 8. Maintenance ThermiStar L .. SP 01/03/10 Fig. 38: Remove the control unit from the bracket. Fig. 39: Reach the control unit through the opening of the bracket an d store inside.

  • Page 68: Spare Part Drawing And Legend

    8. Maintenance ThermiStar L .. SP 01/03/10 Spare part drawing and legend Fig. 40:...

  • Page 69: Troubleshooting

    9. Troubleshooting ThermiStar L .. SP 01/03/10 Troubleshooting Troubleshooting Faults and their removal If while the heat pump is running the heat discharge is suddenly interrupted (e.g. by a stopped heating circulation pump or closed valves), the high pressure safety limiter in the heat pump may be triggered (due to the thermal inertia of the system).
  • Page 70 9. Troubleshooting ThermiStar L .. SP 01/03/10 Troubleshooting Fault Cause Remedy Defect on input Ventilator(s) is/are not running Check fuse, check relay side Check control signal 0-10 V (LP fault) Condenser dirty/iced over Clean condenser, initiate thawing; check temperatures on condenser...
  • Page 71 9. Troubleshooting ThermiStar L .. SP 01/03/10 Fault Cause Remedy Failure of a phase Check supply line of 3-phase current Fault in compres- sor motor, com- Mechanical failure due to lack of lubrication Request factory service pressor overload Winding protection defective...

  • Page 72: Warranty

    10. Warranty ThermiStar L .. SP 01/03/10 Warranty 10.1 Warranty Limit of liability All specifications and information in these installation instructions were compiled under consideration of the applicable standards and regulations, the state of technology as well as our experience and insights of many years.
  • Page 73 10. Warranty ThermiStar L .. SP 01/03/10 Warranty The ThermiStar heat pump by MHG renders its perfect function only when installed and started professionally. Warranty conditions of MHG can be taken from the warranty certificate. Spart parts NOTE! Use only original MHG spare parts in case of...
  • Page 74 10. Warranty ThermiStar L .. SP 01/03/10 2. Wearing parts Wearing parts are such parts which must be replaced several times within the scope of service life while the product is used as intended (e.g. during maintenance). 3. Auxiliary materials Auxiliary materials are required with the repair and maintenance of devices.

  • Page 75: Manufacturer Certificate / Eu Design Conformity Declaration

    10. Warranty ThermiStar L .. SP 01/03/10 10.2 Manufacturer Certificate / EU Design Conformity Declaration Manufacturer Certificate Buchholz, 27.05.2009 MHG Heiztechnik GmbH hereby certifies the following for the heat pumps listed below: The heat pumps are equipped with different safety circuit devices for pressure limitation in the refrigerant cycle in compliance with DIN 32733.
  • Page 76 10. Warranty ThermiStar L .. SP 01/03/10 EU Design Conformity Declaration According to EG Machine Guideline Buchholz, 27.05.2009 MHG Heiztechnik GmbH hereby declares that the ThermiStar heat pumps comply with the following EU guidelines and standards: EU Guideline Standard Machine guideline...

  • Page 77: Proof Of Service

    ThermiStar L .. SP 01/03/10 10.3 Proof of Service Maintenance protocol Heat Pump ThermiStar L .. SP / LZ .. SP Customer: Maintenance contract/Customer No.: The following work was carried out on your heating system in the context of your yearly maintenance:...
  • Page 78 10. Warranty ThermiStar L .. SP 01/03/10 1. Maintenance 2. Maintenance Amount of Amount of refrigerant refrigerant refilled refilled Amount of Amount of refrigerant refrigerant retrieved retrieved Electric meter Electric meter reading reading Heat meter Heat meter reading reading Leak-tightness...
  • Page 79 10. Warranty ThermiStar L .. SP 01/03/10 3. Maintenance 4. Maintenance Amount of Amount of refrigerant refrigerant refilled refilled Amount of Amount of refrigerant refrigerant retrieved retrieved Electric meter Electric meter reading reading Heat meter Heat meter reading reading Leak-tightness...
  • Page 80 10. Warranty ThermiStar L .. SP 01/03/10 5. Maintenance 6. Maintenance Amount of Amount of refrigerant refrigerant refilled refilled Amount of Amount of refrigerant refrigerant retrieved retrieved Electric meter Electric meter reading reading Heat meter Heat meter reading reading Leak-tightness...
  • Page 81 10. Warranty ThermiStar L .. SP 01/03/10 7. Maintenance 7. Maintenance Amount of Amount of refrigerant refrigerant refilled refilled Amount of Amount of refrigerant refrigerant retrieved retrieved Electric meter Electric meter reading reading Heat meter Heat meter reading reading Leak-tightness...

  • Page 82: Hydraulic Diagrams

    11.1 Hydraulic diagrams NOTE! The hydraulic scheme serves as an installation suggestion (without claim to completeness). Addi- tional parts required must be provided by the customer/contractor. Air/Water heat pump ThermiStar L with change-over valve heating/warm water 41.0 43.0 64.0 42.2 22.0...
  • Page 83 11. Hydraulic diagrams ThermiStar L .. SP 01/03/10 Components Component Type Part number Remark 98.30000-6324 L 05 SP L 07 SP 98.30000-6326 L 10 SP Included in scope of delivery: 98.30000-6328 L 13 SP Controller RVS 61.843 98.30000-6330 MHG ThermiStar L L 15 SP 98.30000-6332...
  • Page 84 42.2 22.0 43.0 48.0 42.3 49.0 48.1 Fig. 42: Sk09-6200/022 Air/Water heat pump ThermiStar L with change-over valve heating/warm water and buffer reservoir Legend for Fig. 42: Abbr. Meaning Abbr. Meaning Ventilator 1 Filter 22.0 Sensor outside 1 (terminal B9) Fluid line 41.0...
  • Page 85 11. Hydraulic diagrams ThermiStar L .. SP 01/03/10 Components Component Type Part number Remark 98.30000-6324 L 05 SP L 07 SP 98.30000-6326 L 10 SP Included in scope of delivery: 98.30000-6328 L 13 SP Controller RVS 61.843 98.30000-6330 MHG ThermiStar L L 15 SP 98.30000-6332...
  • Page 86 11. Hydraulic diagrams ThermiStar L .. SP 01/03/10 Factory parameterization Setting value Control User Function / Default value L 19 - L 34 - line level L 05 - 15 561-566 Timer setting 4 Monday 05:00 – 21:00 561-566 Timer setting 4 Tuesday 05:00 –...
  • Page 87 11. Hydraulic diagrams ThermiStar L .. SP 01/03/10 Setting value Control User Function / Default value L 19 - L 34 - line level L 05 - 15 Sensor input BX2 None ¦ Buffer reservoir sensor B4 ¦ Buffer reservoir sensor B41 ¦...
  • Page 88 Your notes ThermiStar L .. SP 01/03/10...
  • Page 89 Your notes ThermiStar L .. SP 01/03/10...
  • Page 90 Your notes ThermiStar L .. SP 01/03/10...

  • Page 91: Index

    Hot surfaces ................ 7 Wearing parts.............. 63, 74 Welding work ..............36 Wiring diagram for ThermiStar L 05 SP – L 07 SP .... 22 Wiring diagram for ThermiStar L 10 SP - L 19 SP .... 24 Installation clearances ............33 Wiring diagram for ThermiStar L 28 SP - L 41 SP ....
