Page 2: Disclaimer
C2R Technologie, Sarl. (“C2R”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult C2R to determine whether any such changes have been made.
Page 3: Table Of Contents
RS-232 S ERIAL USB PC ..............21 ACINTOSH EYBOARD USB HID ......................21 ) ............22 USB S (COM P ERIAL MULATION CTS/RTS Emulation ..................22 ACK/NAK Mode ...................22 CHAPTER 3 - TERMINAL INTERFACES ........... 23 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 4 ....................42 ELAY ...............43 PECIFIED ELAY ..............43 ANUAL ERIAL RIGGER ODES Manual Trigger .....................43 Serial Trigger ....................44 Read Time-Out .....................44 Manual Trigger, Low Power ...............44 Low Power Time-Out Timer ...............44 Presentation Mode ..................45 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 5 Output Sequence Example ................55 Output Sequence Editor................57 Partial Sequence ..................57 Require Output Sequence ................57 ...................58 ULTIPLE YMBOLS ......................58 ....................58 RINT EIGHT ....................59 IDEO EVERSE ORKING RIENTATION ..................59 CHAPTER 5 - DATA EDITING ..............61 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 6 ......................74 ODABAR 39 ......................76 Code 39 Enabled ..................76 Code 39 Start/Stop Characters ..............77 Code 39 Check Character ................77 Code 39 Message Length ................77 Code 39 Append ..................78 Code 32 Pharmaceutical (PARAF) ............78 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 7 Code 11 Message Length ................85 128 ......................85 Code 128 Enabled ..................86 ISBT 128 Concatenation ................86 Code 128 Message Length ................86 Code 128 Code Page ..................86 GS1-128 ......................87 GS1-128 On/Off ...................87 GS1-128 Message Length ................87 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 8 EAN/JAN-13 Addenda Required ...............94 EAN/JAN-13 Addenda Separator ..............95 ISBN Translate .....................95 EAN/JAN-8 ......................95 EAN/JAN-8 Enabled ..................95 EAN/JAN-8 Check Digit ................96 EAN/JAN-8 Addenda ...................96 EAN/JAN-8 Addenda Required ..............96 EAN/JAN-8 Addenda Separator ..............97 MSI ........................97 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 9 INKED ................... 105 OSTAL YMBOLOGIES ................... 105 OSTAL ODES INEAR ) ............105 4-CB (4-S TATE USTOMER ARCODE ) .................. 105 (UPU 4-S TATE ......................105 OSTNET Postnet Check Digit .................. 106 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 10 ....................114 ZTEC Aztec Code Enabled ................. 114 Aztec Code Message Length ..............114 HINESE ENSIBLE ..............115 Han Xin Code On/Off ................115 Han Xin Code Message Length .............. 115 © 2000-2012 C2R Technologie, Sarl. All rights reserved. 10 10...
Page 11 REEDOM ) ..............136 PPLICATION CHAPTER 11 - SERIAL PROGRAMMING COMMANDS ......138 ....................138 ONVENTIONS ................138 OMMAND YNTAX ..................138 UERY OMMANDS ..........139 ONCATENATION OF ULTIPLE OMMANDS ..................... 139 ESPONSES © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 12 ..............169 NLINE ECHNICAL SSISTANCE ..................169 IMITED ARRANTY INDEX A - SYMBOLOGY CHART ..............170 INDEX B - ASCII CONVERSION CHART ..........172 ..........174 APPING OF RINTED ODES INTEGRATION ....................182 © 2000-2012 C2R Technologie, Sarl. All rights reserved. 12 12...
Page 13: Product Agency Compliance
26 Bis rue du Calvaire 35410 Domloup France C2R, Inc. shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.
Page 14: Led Eye Safety Statement
LED Eye Safety Statement This device has been tested in accordance with IEC60825-1 LED safety, and has been certified to be within the limits of a Class 1 LED device. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 14 14...
Page 15: Chapter 1 - Getting Started
This User’s Guide provides demonstration, installation, and programming instructions for the engine. Product specifications, dimensions, warranty, and customer support information are also included. C2R Technologie bar code engines are factory programmed for the most common terminal and communications settings. If you need to change these settings, programming is accomplished by scanning the bar codes in this guide.
Page 16: Imager Models
True RS232 5 – 24V 30-009 Trigger Input and Good Read Output True RS232 5 – 24V 30-010 Trigger Input and Good Read Output Imager Identification Colibri Version Serial Number © 2000-2012 C2R Technologie, Sarl. All rights reserved. 16 16...
Page 17: Connecting The Scanner
Note: For additional USB programming and technical information,refer to “USB Application Note,” available at www.c2r-technologie.com If using an RS-232 connection, connect the serial interface cable to the scanner and to the matching port on the back of the computer. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 18: Reading Techniques
If the code being scanned is highly reflective (e.g., laminated), it may be necessary to tilt the code +5° to prevent unwanted reflection. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 18 18...
Page 19: Menu Bar Code Security Settings
Colibri serie 6 : User’s guide Menu Bar Code Security Settings C2R scanners are programmed by scanning menu bar codes or by sending serial commands to the scanner. If you want to restrict the ability to scan menu codes, you can use the Menu Bar Code Security settings.
Page 20: Resetting The Factory Defaults
Custom Defaults bar code, then scan Activate Defaults. This resets the scanner to the factory default settings. For C2R only Menu Commands, beginning on list the factory default settings for each of the commands (indicated by an asterisk (*) on the programming pages). © 2000-2012 C2R Technologie, Sarl. All rights reserved. 20 20...
Page 21: Chapter 2 - Getting Connected
USB PC or Macintosh Keyboard Scan one of the following codes to program the scanner for USB PC Keyboard or USB Macintosh Keyboard. Scanning these codes also adds a CR and LF. USB HID © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 22: Usb Serial (Com Port Emulation)
Scan the following code to program the Colibri to emulate a regular RS232-based COM port. If you are using a Microsoft® Windows® PC, you will need to download a driver from the C2R Technologie website (www.c2r-technologie.com ) The driver will use the next available COM port number.
Page 29 Program Keyboard Country barcode below, then scan the numeric barcode(s) for the appropriate country from the inside back cover, then the Save barcode. Program Keyboard Country © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 30: Keyboard Style
These settings override Keyboard Style selections. Note: If your interface is a keyboard wedge, first scan the menu code for Automatic Caps Lock. Otherwise, your ouput may not be as expected. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 30 30...
Page 31: Control Character Output
Windows Mode Prefix/Suffix Off: The scanner sends key combinations for ASCII control characters for values 00-1F, but it does not transmit any prefix or suffix information. Default = Control + ASCII Mode Off. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 32 Numeric Keypad Mode: Sends numeric characters as if entered from a numeric keypad. Default = Off Automatic Direct Connect Mode: This selection can be used if you have an IBM AT style terminal and the system is dropping characters. Default = Off © 2000-2012 C2R Technologie, Sarl. All rights reserved. 32 32...
Page 33: Terminal Id Table
Baud Rate sends the data from the imager to the terminal at the specified rate. The host terminal must be set for the same baud rate as the imager. Default :115 200 1 200 2 400 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 34: Rs-232 Word Length: Data Bits, Stop Bits, And Parity
7 Data, 1 Stop, Parity Even 7 Data, 2 Stop, Parity Even 8 Data, 1 Stop, Parity Even 7 Data, 1 Stop, Parity Odd 7 Data, 2 Stop, Parity Odd © 2000-2012 C2R Technologie, Sarl. All rights reserved. 34 34...
Page 35: Rs-232 Receiver Time-Out
Timeout) for CTS to be asserted by the host. If the delay time expires and CTS is not asserted, the device transmit buffer is cleared and scanning may resume. Default = RTS/CTS Off. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 36 (DC3, hex 13) to the scanner, data transmission stops. To resume transmission, the host sends the XON character (DC1, hex 11). Data transmission continues where it left off when XOFF was sent. Default = XON/XOFF Off. ACK/NAK © 2000-2012 C2R Technologie, Sarl. All rights reserved. 36 36...
Page 37 ACK/NAK again. Turn on the ACK/NAK protocol by scanning the ACK/NAK On bar code below. To turn off the protocol, scan ACK/NAK Off. Default = ACK/NAK Off. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 38: Chapter 4 - Output
Scan the Trigger Click Off code if you don’t wish to hear the click. (This feature has no effect on serial or automatic triggering.) Default = Trigger Click Off. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 38 38...
Page 39: Image Vga
Default = Beeper -Good Read On. Beeper Volume – Good Read The beeper volume codes modify the volume of the beep the scanner emits on a good read. Default = High. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 40: Beeper Pitch - Good Read
Default = Medium. Beeper Pitch – Error The beeper pitch codes modify the pitch (frequency) of the sound the scanner emits when there is a bad read or error. Default = Razz. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 40 40...
Page 41: Beeper Duration - Good Read
LED Good Read Polarity sets the LED signal voltage level to either high (Active Low) or low (Active High). This will affect LED-Good Read setting. If the LED has been disabled, make sure it is not turned on accidentally by a polarity change. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 42: Number Of Beeps - Good Read
Note: Beep Polarity sets the beeper signal voltage level to either high (Active Low) or low (Active High). This will affect Beeper-Good Read settings. If the beeper has been disabled, make sure it is not turned on accidentally by a polarity change. Good Read Delay © 2000-2012 C2R Technologie, Sarl. All rights reserved. 42 42...
Page 43: User-Specified Good Read Delay
Normal mode. Enhanced mode is best used when you require a very fast scan speed and don’t require a long working range. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 44: Serial Trigger
Low Power Time-Out Timer Note: For RS-232 mode only. Scan the Low Power Time-Out bar code to change the time-out duration (in seconds). Then © 2000-2012 C2R Technologie, Sarl. All rights reserved. 44 44...
Page 45: Presentation Mode
(0 - 9,999 ms) from the Programming Chart on the inside the back cover of this manual, then scanning Save. Once the unit has completed this time-out, it will immediately resume scanning. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 46: Presentation Sensitivity
When in Streaming Presentation mode, the scanner’s aimer goes out after a short time, but the scan illumination remains on all the time to continuously search for bar codes. Two modes are available, Normal and Enhanced. Normal mode offers good scan speed and the longest © 2000-2012 C2R Technologie, Sarl. All rights reserved. 46 46...
Page 47: Mobile Phone Read Mode
You can enable Mobile Phone Reading for either a hand held device, or for a hands-free (presentation) application. Note: To turn off Mobil Phone Read Mode, scan a Manual or Serial Trigger Mode bar code. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 48: Hands Free Time-Out
If you want to set your own length for the reread delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 48 48...
Page 49: Led Power Level
To prevent the imager from powering down, set this time-out to 0. Scan the bar code below, then set the time-out by scanning digits (from 0 - 999,999 ms) from the inside back cover, then © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 50: Aimer Delay
25% aimer duty cycle, even when the imager exposure time is at its maximum in dark operating environments. Select Off if you don’t want to use either aimer mode © 2000-2012 C2R Technologie, Sarl. All rights reserved. 50 50...
Page 52 Then scan the percent you want to shift the centering window using digits on the inside back cover of this manual. Scan Save. Default Centering = 40% for Top and Left, 60% for Bottom and Right. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 52 52...
Page 53: Decode Search Mode
When a low priority symbology is presented, the imager ignores it for a set period of time (see Preferred Symbology Time-out) while it searches for the high priority symbology. If a high priority symbology is located during this period, then that data is read immediately. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 54: High Priority Symbology
Save. Default = 500 ms. Preferred Symbology Time-out Preferred Symbology Default Scan the barcode below to set all Preferred Symbology entries to their default values. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 54 54...
Page 55: Output Sequence Overview
5. End Output Sequence Editor Scan F F to enter an Output Sequence for an additional symbology, or Save to save your entries Other Programming Selections •Discard This exits without saving any Output Sequence changes. Output Sequence Example © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 56 <CR> suffix and specific code lengths, you would use the following command line: SEQBLK62001241FF6A001342FF69001243FF The breakdown of the command line is shown below: SEQBLK sequence editor start command 62 code identifier for Code 39 © 2000-2012 C2R Technologie, Sarl. All rights reserved. 56 56...
Page 57: Output Sequence Editor
When the output sequence is Off, the bar code data is output to the host as the imager decodes it. Note: This selection is unavailable when the Multiple Symbols Selection is turned on. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 58: Multiple Symbols
Print Weight is used to adjust the way the imager reads Matrix symbols. If a imager will be seeing consistently heavily printed matrix symbols, then a print weight of 6 may improve the © 2000-2012 C2R Technologie, Sarl. All rights reserved. 58 58...
Page 59: Video Reverse
Some bar codes are direction-sensitive. For example, Kix codes and OCR can misread when scanned sideways or upside down. Use the working orientation settings if your direction- sensitive codes will not usually be presented upright to the scanner. Default = Upright. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 61: Chapter 5 - Data Editing
Step 2. Determine the 2 digit Hex value from the Symbology Chart (included in Appendix A) for the symbology to which you want to apply the prefix or suffix. For example, for Code 128, Code ID is “j” and Hex ID is “6A”. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 62: To Clear One Or All Prefixes Or Suffixes
Step 3. Scan the 2 digit hex value from the Programming Chart inside the back cover of this manual or scan 9, 9 for all symbologies. Your change is automatically saved. To Add a Carriage Return Suffix to all Symbologies © 2000-2012 C2R Technologie, Sarl. All rights reserved. 62 62...
Page 63: Prefix Selections
Prefix Selections Suffix Selections Function Code Transmit When this selection is enabled and function codes are contained within the scanned data, the imager transmits the function code to the terminal. Default = Enable. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 64: Intercharacter, Interfunction, And Intermessage Delays
Next, scan the Character to Trigger Delay bar code, then the 2-digit hex value for the ASCII character that will trigger the delay ASCII Conversion Chart (Codepage 1252). Delay Length Character to Trigger Delay © 2000-2012 C2R Technologie, Sarl. All rights reserved. 64 64...
Page 65: Interfunction Delay
To remove this delay, scan the Intermessage Delay bar code, then set the number of steps to 0. Scan the SAVE bar code using the Programming Chart inside the back cover of this manual. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 66: Chapter 6 - Data Formatting
Refer to Supported Terminals and locate the Terminal ID number for your PC. Scan three numeric bar codes on the inside back cover to program the imager for your terminal ID (you must enter 3 digits). For example, scan 0 0 0 for RS-232. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 66 66...
Page 67: Other Programming Selections
ASCII Conversion Chart (Code Page1252). • F4 Send “xx” character “nn” times (Insert) leaving cursor in current cursor position. Syntax = F4xxnn (xx stands for the hex value for an ASCII code, see ASCII © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 68 B1000454657374 will search backward for the first occurrence of the 4 character string “Test.” Refer to the ASCII Conversion Chart (Code Page 1252) page A-4 for decimal, hex and character codes © 2000-2012 C2R Technologie, Sarl. All rights reserved. 68 68...
Page 69 ED Check to make sure there is a non-numeric ASCII character at the current cursor position. If character is numeric, format is aborted. Syntax = ED. • EF Inserts a delay of up to 49,995 milliseconds (in multiples of 5), starting from the © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 70: Data Format Editor
Data Formatter On, Not Required, Drop Prefix/Suffix Scanned data is modified according to your data format. If a data format is found for a particular symbol, those prefixes and suffixes are not transmitted. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 70 70...
Page 71 If you wish to hear the error tone when a non-matching bar code is found, scan the Data Format Non-Match Error Tone On bar code. Default = Data Format Non-Match Error Tone On. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 72: Alternate Data Formats
You can switch to Data Format 1 for a single trigger pull by scanning the Single Scan-Data Format 1 bar code below. The next bar code that is scanned uses Data Format 1, then reverts back to Data Format 3. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 72 72...
Page 73: Chapter 7 - Symbologies
• GS1 DataBar Expanded • Trioptic Code • GS1 DataBar Limited • UPC-A • GS1 DataBar Omnidirectional • UPC-A/EAN-13 with Extended Coupon Code • GS1 Emulation • UPC-E0 • GS1-128 • UPC-E1 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 74: Linear Symbologies
Save bar codes on the Programming Chart inside the back cover of this manual. The minimum and maximum lengths and the defaults are included with the respective symbologies. Codabar Default Codabar Enabled © 2000-2012 C2R Technologie, Sarl. All rights reserved. 74 74...
Page 75 When Check Character is set to Validate, but Don’t Transmit, the unit will only read Codabar bar codes printed with a check character, but will not transmit the check character with the scanned data. Codabar Concatenation Codabar supports symbol concatenation. When you enable concatenation, the imager looks © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 76: C
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 2-60. Minimum Default = 4, Maximum Default = 60. Code 39 Default Code 39 Enabled © 2000-2012 C2R Technologie, Sarl. All rights reserved. 76 76...
Page 77: Code 39 Start/Stop Characters
Default = No Check Character. Code 39 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 0-48. Minimum © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 78: Code 39 Append
For example: $V will be decoded as the ASCII character SYN, and /C will be decoded as the ASCII character #. Default = On. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 78 78...
Page 79: Code 39 Code Page
(see Code Page Mapping of Printed Bar Codes), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly. Interleaved 2 of 5 Default © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 80: Interleaved 2 Of 5 Enabled
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 80 80...
Page 81: Nec 2 Of 5
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 82: Code 93
(see Code Page Mapping of Printed Bar Codes), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly. Straight 2 of 5 Industrial (three-bar start/stop) Default © 2000-2012 C2R Technologie, Sarl. All rights reserved. 82 82...
Page 83: Straight 2 Of 5 Industrial Enabled
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-48. Minimum Default = 4, Maximum Default = 48. Straight 2 of 5 IATA (two-bar start/stop) Default © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 84: Straight 2 Of 5 Iata Enabled
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-80. Minimum Default = 4, Maximum Default = 80. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 84 84...
Page 85: Code 11
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-80. Minimum Default = 4, Maximum Default = 80. Code 128 Default © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 86: Code 128 Enabled
Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was © 2000-2012 C2R Technologie, Sarl. All rights reserved. 86 86...
Page 87: Gs1-128
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-80. Minimum Default = 1, Maximum Default = 80. Telepen Default © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 88: Telepen Enabled
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-60. Minimum Default = 1, Maximum Default = 60. UPC-A Default UPC-A Enabled © 2000-2012 C2R Technologie, Sarl. All rights reserved. 88 88...
Page 89: Upc-A Check Digit
Default = On. UPC-A Addenda This selection adds 2 or 5 digits to the end of all scanned UPC-A data. Default = Off for both 2 Digit and 5 Digit Addenda. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 90: Upc-A Addenda Required
If you scan the Require Concatenation code, the scanner must see and read the coupon code and extended coupon code in a single read to transmit the data. No data is output unless © 2000-2012 C2R Technologie, Sarl. All rights reserved. 90 90...
Page 91: Upc-E0
If you need to read codes that lead with the 1 number system, use UPC-E1. Default = On. UPC-E0 Expand UPC-E Expand expands the UPC-E code to the 12 digit, UPC-A format. Default = Off. E0 Addenda Required © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 92: Upc-E0 Addenda Separator
The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it. Default = On. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 92 92...
Page 93: Upc-E0 Addenda
Most U.P.C. bar codes lead with the 0 number system. For these codes, use UPC-E0. If you need to read codes that lead with the 1 number system, use the UPC-E1 selection. Default = Off. EAN/JAN-13 Default EAN/JAN-13 Enabled © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 94: Ean/Jan-13 Check Digit
2 Digit and 5 Digit Addenda. EAN/JAN-13 Addenda Required When Addenda Required is set to on, the imager will only read EAN/JAN-13 bar codes that have addenda. Default = Not Required. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 94 94...
Page 95: Ean/Jan-13 Addenda Separator
If you want to enable or disable EAN13 with Extended Coupon Code, refer to UPC- A/EAN-13 with Extended Coupon Code. ISBN Translate This selection causes EAN-13 Book land symbols to be translated into their equivalent ISBN number format. Default = Off. EAN/JAN-8 Default EAN/JAN-8 Enabled © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 96: Ean/Jan-8 Check Digit
2 Digit and 5 Digit Addenda. EAN/JAN-8 Addenda Required When Addenda Required is set to on, the imager will only read EAN/JAN-8 bar codes that have addenda. Default = Not Required. © 2000-2012 C2R Technologie, Sarl. All rights reserved. 96 96...
Page 97: Ean/Jan-8 Addenda Separator
When Check Character is set to Validate Type 10/11, but Don’t Transmit, the unit will only read MSI bar codes printed with the specified type check character(s), but will not transmit the check character(s) with the scanned data. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 98: Msi Message Length
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 4-48. Minimum Default = 4, Maximum Default = 48. GS1 DataBar Omni directional Default © 2000-2012 C2R Technologie, Sarl. All rights reserved. 98 98...
Page 99: Gs1 Databar Omni Directional Enabled
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 4-74. Minimum Default = 4, Maximum Default = 74. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 100: Trioptic Code
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-600. Minimum Default = 1, Maximum Default = 600. © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 101: Codablockf
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-2048. Minimum Default = 1, Maximum Default = 2048. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 102: Stacked Symbologies
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-2750. Minimum Default = 1, Maximum Default = 2750. MicroPDF417 Default MicroPDF417 enabled © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 103: Micropdf417 Message Length
Scan the UPC/EAN Version On bar code to decode EAN•UCC Composite symbols that have a UPC or EAN linear component. (This does not affect EAN•UCC Composite symbols with a UCC/EAN-128 or RSS linear component.) GS1 Composite Code Message Length © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 104: Gs1 Emulation
If the AIM ID is enabled, the value will be the GS1-128 AIM ID, ]C1 (see Symbology Chart on page A-1). If EAN8 to EAN13 Conversion is scanned, all EAN8 bar codes are converted to EAN13 format. © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 105: Tcif Linked Code 39 (Tlc39)
You may enable the ID-tag (UPU 4-State) if you have firmware with a base number of 31205480. Refer to the Show Software Revision for information on determining the firmware revision in your unit. * Off Postnet © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 107: Canadian Post
Kix code can misread when scanned sideways or upside down. Use Working Orientation, if your Kix codes will not usually be presented upright to the scanner. Australian Post Japanese Post China Post (Hong Kong 2 of 5) Default © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 108: China Post Enabled
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 48. © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 109: Postal Codes 2D
Only one 2D postal code selection can be active at a time. If you scan a second 2D postal code selection, the first selection is overwritten. Default = 2D Postal Codes Off. Single 2D Postal Codes © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 111: Planet Code Check Digit
Colibri serie 6 : User’s guide Planet Code Check Digit This selection allows you to specify whether the check digit should be transmitted at the end of Planet Code data. Default = Don’t Transmit. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 112: Postnet Check Digit
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-3500. Minimum Default = 1, Maximum Default = 3500. © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 113: Data Matrix
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-3116. Minimum Default = 1, Maximum Default = 3116. MaxiCode Default MaxiCode Enabled © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 114: Maxicode Message Length
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-3832. Minimum Default = 1, Maximum Default = 3832. © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 115: Chinese Sensible (Han Xin) Code
Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-7833. Minimum Default = 1, Maximum Default = 7833. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 116: Chapter 8 - Imaging Commands
The image snap command has many different modifiers that can be used to change the look of the image in memory. Modifiers always begin with numbers and end with a letter (case insensitive). Any number of modifiers may be appended to the IMGSNP command. For © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 117: Imgsnp Modifiers
Example of Gain at 1G: Example of Gain at 4G: Example of Gain at 8G: D - Delta for Acceptance: This sets the allowable range for the white value setting (see W - © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 118: Image Ship - Imgshp
Image Ship - IMGSHP An image is taken whenever the Image Snap (IMGSNP) command is processed. The last image is always stored in memory. You may “ship” the image by using the IMGSHP command. © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 119: Imgshp Modifiers
D - Pixel Depth: Indicates the number of bits per pixel in the transmitted image (KIM or BMP format only). • 8D 8 bits per pixel, grayscale image (default) • 1D 1 bit per pixel, black and white image © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 120 I - Invert Image: Used to rotate the image around the X or Y axis in fixed mount applications where the imager is mounted upside down. • Invert around the X axis (flips picture upside down) • Invert around the Y axis (flips picture left to right) © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 121 Rotate image 90 degrees to the right • Rotate image 180 degrees (upside down) • Rotate image 90 degrees to the left Example of Image Rotate set to 0ir: Rotate set to 2ir: © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 122 The bottom edge of the shipped image corresponds to row n - 1 of the image in memory. Range: 000 - 480. (Default = all rows) Uncropped Image: Example of Image Crop set to 300R: Crop set to 300L: © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 123 • ship every 2nd pixel, both horizontally and vertically (default) • ship every 3rd pixel, both horizontally and vertically Example of Pixel Ship set to 1S: set to 2S: set to 3S: © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 124 Don’t blur (default) • Blur Example of Blur Image Off (0V): Blur Image On (1V): W - Histogram Ship: A histogram gives a quick picture of the tonal range of an image, or key © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 125: Image Size Compatibility
Signature Capture Optimize If you will be using your scanner to capture signatures frequently, youshould optimize it for this purpose. However, the speed of scanning barcodes may be slowed when this mode is enabled. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 126: Imgbox Modifiers
Note: The IMGBOX command will return a NAK unless a window size (width and height) are specified. See H - Height of Signature Capture Area W - Width of Signature Capture Area. IMGBOX40S0X70Y190W100H1R0F IMGBOX Modifiers © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 128: Chapter 9 - Interface Keys
The following Keyboard Function Code, Hex/ASCII Value, and Full ASCII “CTRL”+ relationships apply to all terminals that can be used with the imager. Refer to enable Control + ASCII mode. Full ASCII “CTRL” Function HEX/ASCII Value Code © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 129 The last five characters in the Full ASCII “CTRL”+ column ( [ \ ] 6 - ), apply to US only. The following chart indicates the equivalents of these five characters for different countries. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 130 Delete CR/Enter CR/Enter Field Exit/New Line Insert Insert Insert Escape Escape Reserved Error Reset Home Home Home Print Print Back Space Back Space Back Space Back Tab Back Tab Backfield/Back Tab Reserved © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 131: Supported Interface Keys (Memorex Telex)
Tab/Field Forward Field Forward Delete Delete Field Exit New Line Insert Insert Clear Erase Error Reset Error Reset Home Reserved Print Print Back Space Back Space Back Tab Back Field Reserved Home © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 132: Supported Interface Keys (Esprit)
New Line New Line New Line Delete New Line New Line New Line Insert Escape Escape Escape Insert Insert Home Print Back Space Back Space Back Space Back Tab Back Tab Back Tab © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 134: Supported Interface Keys (Apple)
Apple Mac/iMac Supported Keys ASCII Reserved Enter/Numpad Enter CAPS ALT make ALT break CNTRL make CNTRL break RETURN APPLE make APPLE break RETURN Ins Help Home Prnt Scrn BACKSPACE LSHIFT TAB BACKSPACE © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 135: Chapter 10 - Utilities
Scan the bar code below to output the scan driver revision. The scan driver controls image capture. Show Software Revision Scan the bar code below to output the current software revision, unit serial number, and other product information. Show Revision Show Data Format © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 136: Resetting The Standard Product Default
Imaging, Decoding, and Formatting. You can enable and disable these groups of apps by scanning that group’s On or Off bar code below. You can also scan the List © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 137 Colibri serie 6 : User’s guide Apps bar code to output a list of all your apps. Note: You must reset your device in order for the apps setting to take effect. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 138: Chapter 11 - Serial Programming Commands
Several special characters can be used to query the device about its settings. What is the default value for the setting(s). What is the device’s current value for the setting(s). What is the range of possible values for the setting(s). (The device’s response © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 139: Concatenation Of Multiple Commands
This response indicates that Codabar Coding Enable (CBRENA) has a range of values from 0 to 1 (off and on). Example: Example #2: What is the default value for Codabar Coding Enable? © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 140: Trigger Commands
Resetting the Custom Defaults If you aren’t sure what programming options are in your imager, or you’ve changed some options and want the factory settings restored, scan the Standard Product Default Settings bar code below. © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 141 Colibri serie 6 : User’s guide The chart on the following pages lists the factory default settings for each of the menu commands (indicated by an asterisk (*) on the programming pages). © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 142: Menu Commands
Keyboard Brazil KBDCTY16 Brazil (MS) KBDCTY59 Bulgaria (Cyrillic) KBDCTY52 Bulgaria (Latin) KBDCTY53 Canada (French legacy) KBDCTY54 Canada (French) KBDCTY18 Canada (Multilingual) KBDCTY55 Croatia KBDCTY32 Czech KBDCTY15 Czech (Programmer) KBDCTY40 Czech (QWERTY) KBDCTY39 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 143 Iceland KBDCTY75 Irish KBDCTY73 Italian (142) KBDCTY56 Italy KBDCTY5 Japan (ASCII) KBDCTY28 Kazakh KBDCTY78 Kyrgyz (Cyrillic) KBDCTY79 Latin America KBDCTY14 Latavia KBDCTY42 Latavia (QWERTY) KBDCTY43 Lithuania KBDCTY44 Lithuania (IBM) KBDCTY45 Macedonia KBDCTY34 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 144 Switzerland (German) KBDCTY6 Tatar KBDCTY85 Turkey F KBDCTY27 Turkey Q KBDCTY24 Ukrainian KBDCTY76 U.K. KBDCTY7 Uzbek (Cyrillic) KBDCTY77 *Regular KBDSTY0 Caps Lock KBDSTY1 Keyboard Style Shift Lock KBDSTY2 Automatic Caps Lock KBDSTY6 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 145 7 Data, 1 Stop, Parity Odd 232WRD6 Data Bits, Stop 7 Data, 2 Stop, Parity Even 232WRD4 Bits, and Parity 7 Data, 2 Stop, Parity None 232WRD1 7 Data, 2 Stop, Parity Odd 232WRD7 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 146 Flow Control, No timeout 232CTS1 Two direction Flow Control 232CTS2 Flow Control with timeout 232CTS3 RS-232 RS232 TimeOut 232DEL### Handshaking *XON/XOFF Off 232XON0 XON/XOFF On 232XON1 *ACK/NAK Off 232ACK0 ACK/NAK On 232ACK1 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 147 Number of Good Read Beeps / Beeps - Good BEPRPT# LED Flashes Read Number of Number of Error Beeps / LED BEPERR# Beeps - Error Flashes Active High BEPINV1 Beep Polarity *Active Low BEPINV0 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 148 *Medium (750 ms) DLYRR750 Reread Delay Long (1000 ms) DLYRRD1000 Extra Long (2000 ms) DLYRRD2000 User-Specified Range 0 - 30,000 ms DLYRRD##### Reread Delay PWRLDC0 LED Power Low (50%) PWRLDC50 Level High (100%) PWRLDC100 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 149 Preferred Symbology Default PRFDFT Output Enter Sequence SEQBLK Sequence Default Sequence SEQDFT Editor Transmit Partial Sequence SEQTTS1 Partial Sequence *Discard Partial Sequence SEQTTS0 Required SEQ_EN2 Require Output On/Not Required SEQ_EN1 Sequence *Off SEQ_EN0 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 150 User Specified Delay Length (0 - 495 ms) DLYCRX## Intercharacter Character to Trigger Delay DLY_XX## Delay Interfunction Range 0 - 495 ms DLYFNC## Delay Intermessage Range 0 - 495 ms DLYMSG## Delay © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 151 Primary Data Format VSAF_0 Single Scan VSAF_1 Data Format VSAF_2 Change VSAF_3 Symbologies ALLENA0 Symbologies ALLENA1 Codabar Default All Codabar Settings CBRDFT CBRENA0 Codabar CBRENA1 Codabar *Don’t Transmit CBRSSX0 Start/Stop Transmit CBRSSX1 Char. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 152 Default All Interleaved 2 of 5 I25DFT Settings I25ENA0 Interleaved 2 of 5 Enable I25ENA1 *No Check Digit. I25CK20 Interleaved 2 of Validate, But Don’t Transmit I25CK21 5 Check Digit Validate, and Transmit I25CK22 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 153 X25ENA0 Matrix 2 of 5 X25ENA1 Matrix 2 of 5 Minimum (1 - 80) *4 X25MIN## Message Maximum (1 - 80) *80 X25MAX## Length Code 11 Default All Code 11 Settings C11DFT © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 154 Original Telepen Output TELOLD1 Telepen Minimum (1 - 60) *1 TELMIN## Message Maximum (1 - 60) *60 TELMAX## Length UPC-A Default All UPC-A Settings UPADFT UPAENA0 UPC-A Enable UPAENA1 UPACKX0 UPC-A Check Digit UPACKX1 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 155 2 Digit Addenda On UPEAD21 *2 Digit Addenda Off UPEAD20 UPC-E0 Addenda 5 Digit Addenda On UPEAD51 *5 Digit Addenda Off UPEAD50 *Off UPEEN10 UPC-E1 UPEEN11 EAN/JAN-13 Default All EAN/ JAN Settings E13DFT © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 156 Required EA8ARQ1 Required EAN/JAN-8 EA8ADS0 Addenda EA8ADS1 Separator Default All MSI Settings MSIDFT *Off MSIENA0 MSIENA1 *Validate Type 10, but Don’t MSICHK0 MSI Check Transmit Character Validate Type 10 and Transmit MSICHK1 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 157 Minimum (1 – 600) *1 CBAMIN#### Message Maximum (1 – 600) *600 CBAMAX#### Length Default CBFDFT Codablock F CBFENA1 *Off CBFENA0 Codablock F Minimum CBFMIN#### Message Maximum CBFMAX#### Length PDF417 Default PDFDFT © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 158 NETENA0 Transmit Check Digit NETCKX1 Postnet Check Digit *Don’t Transmit Check Digit NETCKX0 PLNENA1 Planet Code *Off PLNENA0 Transmit PLNCKX1 Planet Code Check Digit *Don’t Transmit PLNCKX0 BPOENA1 British Post *Off BPOENA0 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 159 Postal 4i On POSTAL9 Postnet On (also see Postnet POSTAL6 Check Digit) Postnet with B and B Fields On POSTAL11 InfoMail On POSTAL2 Combination 2D Postal InfoMail and British Post On POSTAL8 Codes © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 160 Default All QR Code Settings QRCDFT QRCENA1 QR Code QRCENA0 Minimum (1-3500) *1 QRCMIN QR Code Msg. Length Maximum (1-3500) *3500 QRCMAX Data Matrix Default All Data Matrix Settings IDMDFT IDMENA1 Data Matrix IDMENA0 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 161 Frame Rate (0-30) *30 SNPFRM## *Gain - Light SNPGAN1 Gain - Medium SNPGAN2 Gain - Heavy SNPGAN4 Gain - Maximum SNPGAN8 Delta for Acceptance (0-255) *10 SNPDEL### *LED State - Off SNPLED0 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 162 Invert Image around Y axis IMGNVY1 *Fly Spec (Noise Reduction) Off IMGFSP0 Fly Spec (Noise Reduction) On IMGFSP1 Rotate Image 90° right IMGROT1 Rotate Image 180° right IMGROT2 Rotate Image 90° left IMGROT3 © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 163 Ship Every Pixel IMGSUB1 Ship Every 2nd Pixel IMGSUB2 Ship Every 3rd Pixel IMGSUB3 *Document Image Filter Off IMGUSH0 Document Image Filter On (0255) IMGUSH### *Don’t Ship Histogram IMGHST0 Ship Histogram IMGHST1 © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 164: Chapter 12 - Product Specifications & Pin Outs
Rev. A Colibri serie 6 : User’s guide Chapter 12 – Product Specifications & Pin Outs Specifications © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 166: Chapter 13 - Maintenance & Troubleshooting
Inspecting Cords and Connectors Inspect the imager’s interface cable and connector for wear or other signs of damage. A badly worn cable or damaged connector may interfere with imager operation. Contact your C2R Technologie distributor for information about cable replacement.
Page 167 If the imager still can’t read the sample bar codes, scan "All Symbologies". If you aren’t sure what programming options have been set in the imager, or if you want the factory default settings restored, scan Standard Product Default Settings. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 168: Chapter 14 - Customer Support
C2R Technologie provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, return the unit to C2R Technologie (postage paid) with a copy of the dated purchase record attached. Contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product.
Page 169: Online Technical Assistance
(E) repair or service of the product by anyone other than C2R Technologie or its authorized representatives. This warranty shall extend from the time of shipment for the duration published by C2R for the product at the time of purchase ("Warranty Period"). Any defective product must be returned (at purchaser’s expense) during the Warranty Period to C2R factory or authorized service...
Page 170: Index A - Symbology Chart
Interleaved 2 of 5 0, 1, 3 e (0x65) Japanese Post J (0x4A) KIX (Netherlands) Post K (0x4B) Korea Post ? (0x3F) Matrix 2 of 5 m (0x6D) MaxiCode x (0x78) MicroPDF417 R (0x52) © 2000-2012 C2R Technologie, Sarl. All rights reserved.
Page 171 Specification, Symbology Identifiers, for AIM modifier character details. Note: Prefix/Suffix entries for specific symbologies override the universal (All Symbologies, 99) entry. Refer to Data Editing beginning and Data Formatting beginning for information about using Code ID and AIM ID. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 173 Rev. A Colibri serie 6 : User’s guide Note: This table applies to U.S. style keyboards. Certain characters may differ depending on your Country Code/PC regional settings. © 2000-2012 C2R Technologie, Sarl. All rights reserved...
Page 174: Code Page Mapping Of Printed Bar Codes
ISO 2022 11 Swi Swiss Replacement Characters ISO 2022 11 UK British Replacement Characters ISO 2022 11 Dan Danish Replacement Characters ISO 2022 11 Nor Norwegian Replacement Characters ISO 2022 11 Spa Spanish Replacement Characters © 2000-2012 C2R Technologie, Sarl. All rights reserved.

This manual is also suitable for:

30-005 30-006 30-007 30-008 30-009 30-010

C2R Colibri 6 Series User Manual

Disclaimer

Table of Contents

Product Agency Compliance

Fcc Part 15 Subpart B Class a

Led Eye Safety Statement

Chapter 1 - Getting Started

Chapter 2 - Getting Connected

Chapter 3 - Terminal Interfaces

Chapter 4 - Output

Chapter 5 - Data Editing

Chapter 6 - Data Formatting

Chapter 7 - Symbologies

Chapter 8 - Imaging Commands

Chapter 9 - Interface Keys

Chapter 10 - Utilities

Chapter 11 - Serial Programming Commands

Quick Links

Need help?

Questions and answers

Related Manuals for C2R Colibri 6 Series

Summary of Contents for C2R Colibri 6 Series

This manual is also suitable for:

Table of Contents
