Summary of Contents for TRX SGM-5E VoIP
- Page 1 SGM-5E VoIP Remote control for two-way radios User guide © TRX S.C. 25.10.2014 TRX S.C. 15-743 Białystok, ul. Wierzbowa 8 Poland tel. 85 662 88 11 fax. 85 662 88 10 trx@trx.pl email: www.trx.pl...
- Page 2 Usage: SGM VOIP remote control allow to remotly operate many two-way radios via Internet or separate TCP/IP links. Remote controlling include two-way communication, screen and all buttons. Minimal transfer needed for SGM5E is 100kb/s. Very important is stable latency(ping). To properly work radio need to have four signals on accessory connector: audio input, audio output, SQELCH signal, TX signal.
- Page 3 LED AND CONNECTORS DESCRIPTION SGM-5ES device. 1 – Power LED 2 – Status LED 3 – LAN communication LED 4 – not used 5 – 12-24V power connector, B, L – logical states(work form battery, low battery) works with for example: GPN-6145B Motorola power supply. 6 –...
- Page 4 CONNECTING SGM-5E (WITH MOTOROLA RADIO) Connecting SGM-5ES wiith Motorola 1 – SGM-5E 12-24V power connector 2, 3 – Connect SGM with radio accessory connector and front panel connector 4 – LAN cable...
- Page 5 - Accessory connector pin8 set for PL Detect Active Level - Low - Accessory connector pin12 set for Caririer Detect Active Level - Low - Accessory connector pin14 set for Per Channel Output Active Level - Low - Channel with PL configuration Per Channel Output checked - Miscellaneous configuration Ingnition Sense cheched Wire connecting SGM5E with Motorola radio.
- Page 6 Settings per Channel for Motorola radios working with PL/DPL channels. Miscellaneous settings for Motorola radios (Ignition Sense and Rx Audio – Filtred Squelched)
- Page 7 Microphone settings for Motorola radios (Accessory Connector Mic. Enable) Channel selection from extended keyboard settings for Motorola radios. (Keypad Enable – Dafault Numeric Keypad Selection - Channel)
- Page 8 CONNECTING SGM5E CLIENT...
- Page 9 CONNECTING VOIP HT DESK MODULE Attention: VOIP HT desk module should be connected to computer after starting ROIP application. Sposób podłączenia pulpitu VoIP HT. Attention: DEEP switch inside external microphone must be set: Settings for switch in MOTOROLA RMN5068A microphone (1-OFF;...
- Page 10 PROPOSED INSTALLATION: RESET TO FABRIC SETTINGS: To restore default settings in SGM5E device push and hold reset button for about 30 seconds till you hear three beeps. CONFIGURATION: Configuration is made from computer. Default IP address is 172.168.0.188 and 5556 (SSL). More details how to configure SGM5E client are in RoIP user guide.
